Eaton 9SX1000IR, 1000VA 900W, IEC 2U

Accessories included - 2 IEC10A output wires (1.8 m), Rack mounting kit, 1 USB cable (1.8 m), 1 serial cable (1.8 m), Short instruction manual, Safety instructions.
ACoutletsquantity - 7 AC outlet(s)
AC outlets quantity Ports & interfaces - 7 AC outlet(s)
ACoutlettypes - C13 coupler, C14 coupler
AC outlet types Ports & interfaces - C13 coupler, C14 coupler
Active power - 900 W
Apparent power - 1000 VA
ARTIKEL1 - EATON 9SX 1000I RACK2U
ARTIKEL2 - IN
AutomaticVoltageRegulationAVR -
Battery -
Batterycapacity -
Batterytechnology -
Batteryvoltage -
Breite - 0.55
Cablesincluded -
Category Code - UPW
Certification Certificates - IEC/EN 62040 -2 , FCC B, CISPR22 B, CE /CB report (TUV) / cULus / EAC / RCM / BIS / KCC
Charging time - 56 min
Chassis type - Rack
Code - 9SX1000IR
Color - Black
Depth - 438 mm
Depth Weight & dimensions - 438 mm
Description - Double conversion UPS online, 2U Rackmount, 1000 VA / 900 W, multilingual LCD display, energy meter, 6 IEC 10 A sockets (2 manageable groups), optional management board slot, USB and serial ports, potential-free contacts, RPO connector , power management software compatible with the virtual environment, batteries replaceable during operation, long emergency response time with four optional EBM modules, all accessories for mounting in the rack Rack in the set.
Design -
Designation - CE+WEEE
dimension depth - 545 mm
dimension height - 235 mm
Dimensions - 86,5 x 438 x 438 mm
dimension weight - 21200 g
dimension width - 575 mm
Displaytype - LCD
Display type Design - LCD
EAN - 743172090959
ean - 743172090959
EANCode - 0743172090959
Efficiency -
Environment requirements - Temperature during operation: 0-40°C Noise level: 41 dB
Features -
Filters / protection - Overdischarge
Formfactor - Rackmount
Form factor Design - Rackmount
Gewicht - 21.12
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
guarantee - 24
guarantee_type - external
Heatdissipation -
Height - 86.5 mm
Height Weight & dimensions - 86.5 mm
HERSTELLER - EATON
HighLights -
Hoehe - 0.24
Hotswapbattery -
HSTNUMMER - 9SX1000IR
I/O connectors - 1 x RS-232 (COM)
I/O connectors - 1 x USB 2.0
Inputfrequency - 40 - 70 Hz
Input frequency Features - 40 - 70 Hz
Input operation voltage (max) Features - 276 V
Input operation voltage (min) Features - 190 V
Inputoperationvoltagemax - 276 V
Inputoperationvoltagemin - 190 V
Input power ports - IEC-C14
Laenge - 0.58
Link - https://www.eaton.com/lt/lt-lt/skuPage.9SX1000IR.html
LongDesc -
ManufDatasheet -
Maximum current Features - 10 A
Name - Eaton | UPS | 9SX1000IR | 1000 VA | 900 W
name - UPS 9SX 1000i Rack2U LCD/USB/RS232
Networkcardslot -
Noiselevel - 41 dB
Noise level Features - 41 dB
Numberofbatterycells -
Numberofinputphases -
Numberofoutputphases -
Number of phases input - 1 (230V)
Operatingaltitude -
OperatingrelativehumidityHH -
Operating temperature (T-T) Operational conditions - 0 - 40 °C
OperatingtemperatureTT - 0 - 40 °C
Operationalconditions -
Other features - 1 mini-terminal block for remote power off (configurable) 1 block of mini-terminals to the output relay 1 socket for the optional communication module
Other features > Special features - Form factor: Rack; Rack size: 2U
Outputfrequency - 50/60 Hz
Output frequency Features - 50/60 Hz
Outputoperationvoltagemax -
Outputoperationvoltagemin -
Outputpower - 900 W
Outputpowercapacity - 1 kVA
Output power capacity Features - 1 kVA
Output power Features - 900 W
Output power ports - 6 x IEC-C13
Package features > Classification of battery - CL126:NE:2016-12-09
Package features > Composition of battery - CL127:KT:2016-12-09
Package features > Embeeded battery - Yes
Package features > Gross depth (mm) - 570.00 mm
Package features > Gross height (mm) - 240.00 mm
Package features > Gross width (mm) - 548.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 12 pc(s)
Package features > Paper/Pasteboard - 4800.00 g
Package features > Plastic (No PET) - 700.00 g
Package features > Tare weight (kg) - 5.50 kg
Package features > TI weight (kg) - 0.50 kg
Package features > Type of battery - Accumulator
Package features > Volume (m3) - 0.07 m³
Package features > WEE classification - CL109:4:2017-04-01
Package features > WEEE tax - Yes
Packagingcontent -
Performance > Capacity - 1000 VA
Performance > UPS topology - On line
Portsinterfaces -
Powerfactor -
Powerplug - C14 coupler
Power plug Ports & interfaces - C14 coupler
ProdDesc - Eaton 9SX 1000i Rack2U
producer - Eaton
Producer product family - UPS
Producer product name - 9SX1000IR
Productcolour - Black
Product colour Design - Black
Productcondition - Original
ProductHighLights -

• Double-conversion (Online)
• 1 kVA 900 W
• 7 AC outlet(s)
• Rackmount Black

ProductPicture - https://www.tdbaltic.ee/images/products/EATON/9SX1000IR_1.jpg
ProductPicture1 -
ProductPicture2 -
ProductPicture3 -
ProductPicture4 -
ProductPicture5 -
Quickinstallationguide -
Rack capacity Design - 2U
Rackmountkit -
RS232ports -
Safety Safety regulation & standards - IEC/EN 62040-1, UL 1778, CSA 22.2
Serialinterface - Yes
Serial interface Ports & interfaces - Yes
Serialinterfacetype - RS-232
Serial interface type Ports & interfaces - RS-232
Serialportsquantity -
Software -
Special functions -
Stck_Kart - 1
Stck_Pal - 2
Storno - N
Summary - Eaton 9SX. UPS topology: Double-conversion (Online), Output power capacity: 1 kVA, Output power: 900 W. AC outlet types: C13 coupler, C14 coupler, Power plug: C14 coupler, AC outlets quantity: 7 AC outlet(s). Form factor: Rackmount, Product colour: Black, Rack capacity: 2U. Certification: IEC/EN 62040 -2 , FCC B, CISPR22 B, CE /CB report (TUV) / cULus / EAC / RCM / BIS / KCC. Safety: IEC/EN 62040-1, UL 1778, CSA 22.2
Technical details > Capacity - 900 W
Technical details > Functions - Auto shutdown function
Technical details > Gross weight - 21.20 kg
Technical details > Net weight - 15.70 kg
Technical details > Producer - Eaton
Typicalbackuptimeathalfload -
Unit Box Height - 0.24
Unit Box Length - 0.57
Unit Box Width - 0.55
Unit Calculated Volume - 0.07524 cubm
Unit Calculated Weight - 15.7 kg
Units per Shipping Box - 1
UPS Architecture - on-line double conversion
UPStopology - Double-conversion (Online)
UPS topology Features - Double-conversion (Online)
USB 2.0 ports quantity Ports & interfaces - 1
USBport - Yes
USB port Ports & interfaces - Yes
USBporttype -
Vendor Homepage - https://www.eaton.com/gb/en-gb/skuPage.9SX1000IR.html
vendpn - 9SX1000IR
Video -
Voltage - 230 V
Warranty - 12 months
Warranty - 24
Warranty - 24 month(s)
Warranty - 24 months
Warrantyandmisc -
Waveform -
Weight - 15.7 kg
Weight - 15.7 kg
Weightdimensions -
Weight Weight & dimensions - 15.7 kg
Width - 438 mm
Width Weight & dimensions - 438 mm
