Eaton 3P900UI, 900VA 540W, IEC

Accessories included - UPS 2 × IEC-IEC cables USB cable Quick start guide Safety instructions
ACoutletsquantity - 4 AC outlet(s)
ACoutlettypes - C3 coupler
Active power - 540 W
Apparent power - 900 VA
ARTIKEL1 - EATON 3P ELLIPSE 900 USB IEC
ARTIKEL2 - .
AutomaticVoltageRegulationAVR -
Battery -
Batterycapacity - 9 Ah
Battery capacity - 9 Ah
Batterytechnology -
Batteryvoltage - 12 V
Breite - 0
Cablesincluded - USB cable
Chassis type - Tower
Color - Black
Data Act - Link
Depth - 235 mm
Description - Eaton 3P Ellipse UPS USB IEC Power: 900 VA, 540 W Input: C14 Outlets: 3 × C13 (surge protection + battery backup), 1 × C13 (surge protection only) USB charging Form factor: Tower Eaton 3P Ellipse The 3P Ellipse UPS is the latest addition to Eatons power protection portfolio. Its elegant, attractive design and near-silent operation make this compact UPS a great solution for both home users and small businesses. With up to 12% more power compared to its predecessor (Ellipse ECO), it can support a wider range of devices-from home AV and Hi-Fi systems to advanced gaming PCs. No additional adapters are required: devices can be connected directly to FR or Schuko outlets on the UPS, which is a significant improvement over models equipped only with IEC sockets. Optional cloud connectivity via the CLOUD-PS card enables remote monitoring. This transforms the 3P into a cloud-connected UPS, allowing real-time status and notifications through a mobile app or web browser-particularly useful for business environments. Built-in surge protection Compliant with the IEC 61643-11 standard Cloud connectivity (optional) Real-time status and alerts via mobile app or web browser using CLOUD-PS card Mobile device charging USB-A and USB-C ports on the front panel Automatic computer shutdown Supported via UPS Companion software Up to 12% more power Compared to previous Ellipse ECO models
Design -
Designation - CE+WEEE
dimension depth - 140 mm
dimension height - 330 mm
Dimensions - 235 x 263 x 81 mm
dimension weight - 5000 g
dimension width - 290 mm
Displaytype - LED
ean - 3553340621376
EANCode - 3553340621376
Efficiency - 97%
Environment requirements - Temperature range: 0°C to 40°C (32°F to 104°F) Relative humidity: 0%-95% (non-condensing)
Features -
Filters / protection - Overdischarge
Filters / protection - Surge
Formfactor - Tower
Gewicht - 5.03
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
guarantee - 36
guarantee_type - external
Heatdissipation -
Height - 263 mm
HERSTELLER - EATON
HighLights -
Hoehe - 0
Hotswapbattery -
HSTNUMMER - 3P900UI
I/O connectors - 1 x USB (Type B)
I/O connectors - 1 x USB (Type C)
I/O connectors - 1 x USB 2.0
Inputfrequency - 46/70 Hz
Inputoperationvoltagemax - 284 V
Inputoperationvoltagemin - 161 V
Input power ports - IEC-C14
Laenge - 0
LongDesc -
ManufDatasheet -
name - UPS 3P Ellipse 900 USB IEC 3P900UI
Networkcardslot -
No. of batteries - 1
Noiselevel - 25 dB
Numberofbatterycells -
Numberofinputphases - 1
Numberofoutputphases - 1
Number of phases input - 1 (230V)
Operatingaltitude -
OperatingrelativehumidityHH -
OperatingtemperatureTT - 0 - 40 °C
Operationalconditions -
Other features - Output outlets: 3 × C13 (surge protection + battery backup) 1 × C13 (surge protection only)
Outputfrequency - 50/60 Hz
Outputoperationvoltagemax - 284 V
Outputoperationvoltagemin - 161 V
Outputpower - 540 W
Outputpowercapacity - 0.9 kVA
Output power ports - 4 x IEC-C13
Packagingcontent -
Portsinterfaces -
Powerfactor -
Powerplug -
ProdDesc - Eaton 3P Ellipse 900 USB IEC
producer - Eaton
Productcolour - Black
Productcondition - Original
ProductHighLights -

• Convenient extra-flat design for easy installation in any office environment
• High performance surge-protection device compliant with IEC 61643-11 standard
• 4 outlets to connect your PC + peripherals

ProductPicture - https://www.tdbaltic.ee/images/products/EATON/3P900UI_1.jpg
ProductPicture1 - https://www.tdbaltic.ee/images/products/EATON/3P900UI_2.jpg
ProductPicture2 - https://www.tdbaltic.ee/images/products/EATON/3P900UI_3.jpg
ProductPicture3 - https://www.tdbaltic.ee/images/products/EATON/3P900UI_4.jpg
ProductPicture4 - https://www.tdbaltic.ee/images/products/EATON/3P900UI_5.jpg
ProductPicture5 - https://www.tdbaltic.ee/images/products/EATON/3P900UI_6.jpg
Quickinstallationguide - Yes
Rackmountkit -
RS232ports -
Serialinterface -
Serialinterfacetype -
Serialportsquantity -
Special functions - Replaceable batteries Automatic battery test Cold start capability
Stck_Kart - 9998
Stck_Pal - 0
Storno - Y
Typicalbackuptimeathalfload -
UPS Architecture - off-line (standby)
UPStopology - Standby (Offline)
USBport - Yes
USBporttype - USB Type A/USB Type-C
vendpn - 3P900UI
Voltage - 12 V
Warranty - 36 months
Warrantyandmisc -
Waveform - Stepwise
Weight - 3.9 kg
Weight - 4.4 kg
Weightdimensions -
Width - 81 mm
