Brand - Shuttle
BrandPartCode - PFB-NS02A031
Category - PCs/Workstations
Certificates - Certification - CE, FCC, BSMI, RCM, VCCI
Certificates - Compliance certificates - RoHS
Design - Cable lock slot - Yes
Design - Cable lock slot type - Kensington
Design - Chassis type - Nettop
Design - Housing material - Plastic
Design - Product colour - Black
Design - VESA mounting - Yes
Design - Volume - 0.577 L
Display - Display included - No
EAN - 887993601526
Graphics - Discrete graphics card - No
Graphics - Discrete graphics card model - Not available
Graphics - Graphics card Open GL support - Yes
Graphics - On-board graphics card - Yes
Gross Weight Kg - 1,2
GTIN - 887993601526
GTIN - 0887993601526
Logistics data - Harmonized System (HS) code - 84715000
LongDesc - 0.5-litre fanless PC with Android supports HDMI 2.0 The Shuttle XPC nano NS02AV2 is one of the most affordable models Shuttle's product family of Mini PCs has on offer. It not only convinces by its stunning looks and reliable long-term performance alone, it also comes with an integrated Octa-Core ARM processor and pre-installed Android operating system. Featuring HDMI 2.0, 4x USB 2.0, Gigabit-LAN, WLAN-ac and a built-in card reader, they easily connect to diverse peripheral devices for different kinds of application. This product is particularly intended for digital signage and Thin Client applications.
LongProductName - Rockchip RK3368, 2GB DDR3L-SDRAM, 16GB eMMC, LAN, WLAN, Bluetooth, Android 8.1
LongSummaryDescription - Shuttle XPC nano NS02AV2. Processor family: Rockchip, Processor model: RK3368. Internal memory: 2 GB, Internal memory type: DDR3L-SDRAM. Total storage capacity: 16 GB, Storage media: eMMC, Card reader integrated. Wi-Fi. Operating system installed: Android 8.1. Power supply: 24 W. Chassis type: Nettop. Product type: Mini PC. Weight: 270 g. Product colour: Black
Manufacturer Code - NS02AV2
Manufacturer Name - Shuttle
Memory - Internal memory - 2 GB
Memory - Internal memory type - DDR3L-SDRAM
Memory - Maximum internal memory - 2 GB
Network - Bluetooth - Yes
Network - Bluetooth version - 5.0
Network - Cabling technology - 10/100/1000Base-T(X)
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 10,100,1000 Mbit/s
Network - Top Wi-Fi standard - Wi-Fi 5 (802.11ac)
Network - Wake-on-LAN ready - Yes
Network - Wi-Fi - Yes
Network - Wi-Fi standards - 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Packaging content - VESA mount included - Yes
Performance - Password protection - Yes
Performance - Product type - Mini PC
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 2.0
Ports & interfaces - Line-out - Yes
Ports & interfaces - USB 2.0 ports quantity - 4
Power - Power supply - 24 W
Power - Power supply input frequency - 50 - 60 Hz
Power - Power supply input voltage - 100 - 240 V
Processor - Processor boost frequency - 1.5 GHz
Processor - Processor cores - 8
Processor - Processor family - Rockchip
Processor - Processor manufacturer - Rockchip
Processor - Processor model - RK3368
ProductName - NS02AV2
Short description - Shuttle Barebone NS02AV2 Black (Rockchip RK3368)
ShortSummaryDescription - Shuttle XPC nano NS02AV2, Rockchip, RK3368, 2 GB, DDR3L-SDRAM, 16 GB, Android 8.1
Software - Operating system installed - Android 8.1
Storage - Card reader integrated - Yes
Storage - Compatible memory cards - SD, SDHC, SDXC
Storage - Optical drive type - No
Storage - Storage media - eMMC
Storage - Total storage capacity - 16 GB
Sustainability - Sustainability certificates - ErP
Title - Shuttle XPC nano NS02AV2 Rockchip RK3368 2 GB DDR3L-SDRAM 16 GB eMMC Android 8.1 Nettop Mini PC Black
URL - https://www.shuttle.eu/en/products/nano/ns02av2
WarrantyInfo -
Weight & dimensions - Depth - 141 mm
Weight & dimensions - Height - 29 mm
Weight & dimensions - Package weight - 650 g
Weight & dimensions - Weight - 270 g
Weight & dimensions - Width - 141 mm
