Bluetooth - Yes
Bluetooth version - 5.4
Brand - Lenovo
BrandPartCode - 13AC002DMX
Built-in speakers - Yes
Category - PCs/Workstations
Certificates - Certification - ENERGY STAR 9.0
ErP Lot 3
RoHS compliant
TCO Certified, generation 10
Connections - DisplayPort
Connections - Ethernet (RJ-45)
Connections - HDMI
Connections - USB-A
Connections - USB-C
Dedicated video memory (GB) - Uses system memory
Description - LENOVO M90Q TINY G6 U7-265T/32GB/1TB/W11P/3P
Design - Cable lock slot - Yes
Design - Cable lock slot type - Kensington
Design - Chassis type - Mini PC
Design - Placement supported - Horizontal/Vertical
Design - Product colour - Black
Design - VESA mounting - Yes
Design - Volume - 1 L
Dimensions W x D x H, mm - 179 x 182.9 x 36.5
Display - Display included - No
DisplayPorts quantity - 2
Ethernet LAN (RJ-45) ports quantity - 1
Graphic adapter - Intel Graphics
Graphics - Discrete graphics card - No
Graphics - Discrete graphics card model - Not available
Graphics - On-board GPU manufacturer - Intel
Graphics - On-board graphics card - Yes
Graphics - On-board graphics card family - Intel Graphics
Graphics - On-board graphics card model - Intel Graphics
Green certifications - Energy Star 9.0
Green certifications - ErP
Green certifications - RoHS compliant
Green certifications - TCO 10.0
GTIN - 0199271898475
GTIN - 199271898475
HDMI ports quantity - 1
Height - 240.000000
Integrated Memory Card Reader - No
Intel HyperThreading - NO
Intel Smart Cache, MB - 30
Intel Turbo Boost, GHz - 5.30
Intel Virtualization technology - VT-x / VT-d / VT-rp
Intel vPro - Yes
Internal memory - 32 GB
Internal memory type - DDR5
Length - 532.000000
LongDesc - BIG POWER IN A TINY FORMSmarter AI for Any SituationBuilt to provide power in small spaces, the ThinkCentre M90q Gen 6 Tiny PC delivers industry-leading AI-driven performance and unparalleled productivity — all in a sleek, modern design. It boasts functionality, security, manageability, expandability, and durability, tapping into limitless potential. Leverage your capabilities without compromise.REDEFINE AI WORKFLOWS WITH BLAZING PRECISIONIT Manageability With AI-Driven PerformancePowered by Intel® Core™ Ultra processors, the ThinkCentre M90q Gen 6 Tiny PC features an integrated NPU along with Intel vPro® for security and IT manageability. Lenovo AI Now drives AI acceleration, while the AI Turbo Engine optimizes performance by allocating X Processing Unit (XPU) workloads. Plus, up to optional WiFi 7 ensures blazing-fast connectivity.COMPACT POWER, INFINITE POTENTIALCustomizable ProductivityEnjoy unmatched productivity with faster USB speeds, connect to up to four displays, and power through tasks with vast memory and expandable storage. With multiple ports and an optional USB-C® (Thunderbolt™ 4) port, expand possibilities further. Bundle the ThinkCentre M90q Gen 6 Tiny PC with Tiny-in-One (TIO) monitor for smarter, cost-effective upgrades.A SUITE OF ADVANCED PROTECTIONSNo-Compromise SecurityThis secured-core PC (L3) features ThinkShield security, encompassing hardware and software solutions. Get additional safeguards with self-healing BIOS, dTPM chip, a Kensington Security Slot™, and Smart USB Protection. Choose Intel vPro® security for advanced threat protection, while securing your data and business with ThinkCentre Customization.PEAK PERFORMANCE IN THE TOUGHEST CONDITIONSSafe, Durable & Efficient 24/7This PC uses the US Department of Defense MIL-STD-810H for a balance of reliability and durability. With TÜV anti-dust, low surface, and shock-resistance certifications, it stands strong in tough environments, while ensuring safety through IEC Electrical Safety and Electromagnetic certifications, offering first-class manageability for any workspace.CREDIBILITY & COLLABORATIONSustainabilityOur goal is to provide smarter technology that builds a brighter, more sustainable future for our customers, communities, and the planet. That's why we pursue industry leading labels and certifications that demonstrate our commitment to sustainability in product design. Together, we can build a smarter future for all.Specifications may vary depending upon region / model.
LongProductName - Intel Core Ultra 7 265T (30MB Cache), 32GB DDR5-SDRAM, 1000GB SSD, Intel Graphics, LAN, WLAN, Bluetooth, Windows 11 Pro 64-bit
LongSummaryDescription - Lenovo ThinkCentre M90q Gen 6. Processor family: Intel Core Ultra 7, Processor model: 265T. Internal memory: 32 GB, Internal memory type: DDR5-SDRAM, Memory clock speed: 5600 MHz. Total storage capacity: 1 TB, Storage media: SSD. On-board graphics card model: Intel Graphics. Operating system installed: Windows 11 Pro, Operating system architecture: 64-bit. Power supply: 135 W. Chassis type: Mini PC. Product type: Mini PC. Weight: 1.34 kg. Product colour: Black
Manufacturer - Lenovo
Manufacturer's estimate: Product life cycle used in emission assessments, years - 4
Manufacturer?s estimate: Manufacturing-related CO2 emissions, kg - 234.3
Manufacturer?s estimate: Product life cycle CO2 emissions, kg - 317
ManufacturerPartNumber - 13AC002DMX
Maximum internal memory, GB - 64 GB
Memory - Internal memory - 32 GB
Memory - Internal memory type - DDR5-SDRAM
Memory - Maximum internal memory - 64 GB
Memory - Memory channels - Dual-channel
Memory - Memory clock speed - 5600 MHz
Memory - Memory layout (slots x size) - 2 x 16 GB
Memory - Memory slots - 2x SO-DIMM
Memory clock speed, MHz - 5600
Memory slots - 2
Memory slots (available) - 2
Motherboard chipset - Intel Q870
Network - Antenna type - 2x2
Network - Bluetooth - Yes
Network - Bluetooth version - 5.4
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 100,1000 Mbit/s
Network - Top Wi-Fi standard - Wi-Fi 7 (802.11be)
Network - Wi-Fi - Yes
Network - Wi-Fi standards - Wi-Fi 7 (802.11be)
Network - WLAN controller manufacturer - Intel
Network - WLAN controller model - Intel Wi-Fi 7 BE200
Neural processor unit (NPU) - AI software frameworks supported by NPU - DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Neural processor unit (NPU) - GPU performance up to - 8 TOPs
Neural processor unit (NPU) - Neural processor unit (NPU) - Intel AI Boost
Neural processor unit (NPU) - NPU performance up to - 13 TOPs
Neural processor unit (NPU) - Sparsity support - Yes
Neural processor unit (NPU) - Total processor performance up to - 33 TOPs
Neural processor unit (NPU) - Windows Studio effects support - Yes
NPU - Yes
Number of efficient-cores - 12
Number of performance-cores - 8
Operating system provided - Windows 11 Pro
Operational conditions - Non-operating altitude - 0 - 12192 m
Operational conditions - Operating altitude - 0 - 3048 m
Operational conditions - Operating relative humidity (H-H) - 20 - 80%
Operational conditions - Operating temperature (T-T) - 5 - 35 °C
Operational conditions - Storage relative humidity (H-H) - 10 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 60 °C
Optical drive - No
Packaging content - Keyboard connectivity - Wireless
Packaging content - Keyboard included - Yes
Packaging content - Mouse connectivity - Wireless
Packaging content - Mouse included - Yes
Performance - Audio chip - Realtek ALC233VB
Performance - Audio system - High Definition Audio
Performance - Motherboard chipset - Intel Q870
Performance - Number of speakers - 1
Performance - Password protection - Yes
Performance - Password protection type - BIOS, Power on
Performance - Product type - Mini PC
Performance - Trusted Platform Module (TPM) - Yes
Performance - Trusted Platform Module (TPM) version - 2.0
PeriodofWarranty -
Ports & interfaces - Combo headphone/mic port - Yes
Ports & interfaces - DisplayPorts quantity - 2
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 2.1
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 1
Ports & interfaces - USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity - 5
Ports & interfaces - USB 3.2 Gen 2x2 Type-C ports quantity - 1
Power - Power supply - 135 W
Power - Power supply input frequency - 50/60 Hz
Power - Power supply input voltage - 100 - 240 V
Power supply, W - 135
Processor - Efficient-core base frequency - 1.2 GHz
Processor - Efficient-core Max Turbo Frequency - 4.6 GHz
Processor - Efficient cores - 12
Processor - Maximum turbo power - 112 W
Processor - Number of processors installed - 1
Processor - Performance-core base frequency - 1.5 GHz
Processor - Performance-core Max Turbo Frequency - 5.2 GHz
Processor - Performance cores - 8
Processor - Processor base power - 35 W
Processor - Processor boost frequency - 5.3 GHz
Processor - Processor cache - 30 MB
Processor - Processor cache type - Smart Cache
Processor - Processor cores - 20
Processor - Processor family - Intel Core Ultra 7
Processor - Processor generation - Intel Core Ultra (Series 2)
Processor - Processor manufacturer - Intel
Processor - Processor model - 265T
Processor - Processor threads - 20
Processor family - Intel Core Ultra 7
Processor manufacturer - Intel
Processor model - Intel Core Ultra 7 265T (Max. 5.30GHz, 30M, 20C)
Processor number of cores - 20
ProductName - ThinkCentre M90q Gen 6
RAID controller - No
ShortSummaryDescription - Lenovo ThinkCentre M90q Gen 6, Intel Core Ultra 7, 265T, 32 GB, 1 TB, Windows 11 Pro, 64-bit
Software - Operating system architecture - 64-bit
Software - Operating system installed - Windows 11 Pro
Software - Operating system language - English, Swedish, Finnish, Danish, Norwegian
Solid State Disk drive type - M.2 PCIe NVMe
Storage - Card reader integrated - No
Storage - M.2 SSD size - 2280 (22 x 80 mm)
Storage - Number of SSDs installed - 1
Storage - Number of storage drives installed - 1
Storage - NVMe - Yes
Storage - Optical drive type - No
Storage - SSD capacity - 1 TB
Storage - SSD form factor - M.2
Storage - SSD interface - PCI Express 4.0
Storage - Storage media - SSD
Storage - Total SSDs capacity - 1 TB
Storage - Total storage capacity - 1 TB
Title - Lenovo ThinkCentre M90q Gen 6 Intel Core Ultra 7 265T 32 GB DDR5-SDRAM 1 TB SSD Windows 11 Pro Mini PC Black
Total storage capacity - 1 TB SSD
Trusted Platform Module (TPM) version - 2.0
URL - https://www.lenovo.com/gb/en/p/desktops/thinkcentre/m-series-tiny/thinkcentre-m90q-gen-6-intel-tiny-pc/len102c0065?orgRef=https%253A%252F%252Fwww.google.com%252F&srsltid=AfmBOorRIQ9ndmAch2-NWG-vwyZ2_WpRF5z3X5EIGvPcgpBsDffQpmRF
USB-A (USB 3.2) ports quantity - 6
USB-C (USB 3.2) ports quantity - 1
WarrantyInfo - 3-year, Onsite; 3Y Premier Support TC DT/AIO WHB (CPN), CO2 Offset 0.5 ton (2nd Generation Carbon Offset Projects)
Weight - 3.600000
Weight & dimensions - Depth - 182.9 mm
Weight & dimensions - Height - 36.5 mm
Weight & dimensions - Weight - 1.34 kg
Weight & dimensions - Width - 179 mm
Weight, g - 1340
Width - 130.000000
Wireles LAN (WLAN) - Yes
WLAN antennas - 2x2
WLAN type - Intel Wi-Fi 7 BE200
