Audio - Audio chip - Realtek ALC897Q-CG
Audio - Audio system - High Definition Audio
Audio - Number of speakers - 1
Bluetooth - Yes
Bluetooth version - 5.3
Brand - Lenovo
BrandPartCode - 12V8000CMX
Cable lock slot - Yes
Category - PCs/Workstations
Certificates - Certification - ErP Lot 3
MIL-STD-810H
Certificates - Compliance certificates - RoHS
Connections - Audio (3.5mm)
Connections - DisplayPort
Connections - Ethernet (RJ-45)
Connections - HDMI
Connections - Serial (RS-232)
Connections - USB-A
Connections - USB-C
Dedicated video memory (GB) - Uses system memory
Description - LENOVO M90S SFF G5 I7-14700/32GB/1TB/RS232/W11P/3P
Design - Cable lock slot - Yes
Design - Cable lock slot type - Kensington
Design - Chassis type - SFF
Design - Colour name - Black
Design - Placement supported - Vertical
Design - Product colour - Black
Design - Volume - 8.2 L
Dimensions W x D x H, mm - 92.5 x 297.7 x 339.5
Display - Display included - No
DisplayPorts quantity - 2
Ethernet LAN (RJ-45) ports quantity - 1
Graphic adapter - Intel UHD Graphics 770
Graphics - Discrete graphics card - No
Graphics - Discrete graphics card model - Not available
Graphics - On-board GPU manufacturer - Intel
Graphics - On-board graphics card - Yes
Graphics - On-board graphics card family - Intel® UHD Graphics
Graphics - On-board graphics card model - Intel UHD Graphics 770
Graphics adapter family - Intel UHD Graphics
GTIN - 0198154431006
GTIN - 198154431006
HDMI ports quantity - 1
Height - 195.000000
Intel HyperThreading - Yes
Intel Virtualization technology - VT-x / VT-d / VT-rp
Intel vPro - No
Internal memory - 32 GB
Internal memory type - DDR5
Keyboard - Keyboard connectivity - Wired
Length - 530.000000
LongDesc - Peak Processing PerformanceNo program is too intricate, and no file is too massive to hinder the Lenovo ThinkCentre M90s Gen 5 (Intel) small form factor (SFF) from operating at the speed of human imagination. With cutting-edge Intel vPro® Enterprise technology and Intel® Core™ processors, this desktop delivers real-world, top-notch performance for business needs.Confidently SecuredLenovo ThinkShield offers thorough security, combining hardware and software to protect your data. The discrete Trusted Platform Module (dTPM) chip encrypts passwords and data, while BIOS-based Smart USB Protection prevents unauthorized access through peripherals. Leveraging the Intel vPro® platform, this device enhances data and asset security.Expandable FlexibilityThe Smart Cable offers cutting-edge device collaboration through convenient USB-A and USB-C® connections, accommodating all your peripherals, including laptops and tablets. Seamlessly share device control, data, and screen projection between devices with this intelligent feature, supporting high-speed USB-C® data transfers.Environmentally AwareThis small form factor PC was crafted with a strong emphasis on recycling. Our commitment to sustainability is evident in the integration of recycled post-consumer content (PCC) into various components. The packaging is thoughtfully designed using a combination of recycled and sustainably sourced materials.
LongProductName - Intel Core i7-14700 (33MB Cache), 32GB DDR5-SDRAM, 1000GB SSD, Intel UHD Graphics 770, LAN, WLAN, Bluetooth, Windows 11 Pro
LongSummaryDescription - Lenovo ThinkCentre 12V80006FR. Processor family: Intel® Core™ i7, Processor model: i7-14700. Internal memory: 32 GB, Internal memory type: DDR5-SDRAM, Memory clock speed: 4400 MHz. Total storage capacity: 1 TB, Storage media: SSD. On-board graphics card model: Intel UHD Graphics 770. Wi-Fi. Operating system installed: Windows 11 Pro. Power supply: 310 W. Chassis type: SFF. Product type: PC. Weight: 5.3 kg. Product colour: Black
Manufacturer - Lenovo
Manufacturer's estimate: Product life cycle used in emission assessments, years - 4
Manufacturer?s estimate: Manufacturing-related CO2 emissions, kg - 346.2
Manufacturer?s estimate: Product life cycle CO2 emissions, kg - 491
ManufacturerPartNumber - 12V8000CMX
Maximum internal memory, GB - 128 GB
Memory - Internal memory - 32 GB
Memory - Internal memory type - DDR5-SDRAM
Memory - Maximum internal memory - 128 GB
Memory - Memory channels - Dual-channel
Memory - Memory clock speed - 4400 MHz
Memory - Memory layout (slots x size) - 2 x 16 GB
Memory - Memory slots - 4x DIMM
Memory clock speed, MHz - 4400
Motherboard chipset - Intel Q670
Network - Antenna type - 2x2
Network - Bluetooth - Yes
Network - Bluetooth version - 5.3
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 100,1000 Mbit/s
Network - Top Wi-Fi standard - Wi-Fi 6E (802.11ax)
Network - Wi-Fi - Yes
Network - Wi-Fi standards - Wi-Fi 6E (802.11ax)
Network - WLAN controller manufacturer - Intel
Network - WLAN controller model - Intel Wi-Fi 6E AX211
Number of efficient-cores - 12
Number of performance-cores - 8
Operating system provided - Windows 11 Pro
Operational conditions - Non-operating altitude - 0 - 12192 m
Operational conditions - Operating altitude - 0 - 3048 m
Operational conditions - Operating relative humidity (H-H) - 20 - 80%
Operational conditions - Operating temperature (T-T) - 5 - 35 °C
Operational conditions - Storage relative humidity (H-H) - 10 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 60 °C
Optical drive - No
Packaging content - Keyboard included - Yes
Packaging content - Mouse connectivity - Wired
Packaging content - Mouse included - Yes
Packaging data - Package depth - 395 mm
Packaging data - Package height - 530 mm
Packaging data - Package weight - 7.6 kg
Packaging data - Package width - 195 mm
Performance - Built-in speaker(s) - Yes
Performance - Motherboard chipset - Intel Q670
Performance - Password protection - Yes
Performance - Password protection type - BIOS, HDD, Power on
Performance - Product type - PC
Performance - Trusted Platform Module (TPM) - Yes
Performance - Trusted Platform Module (TPM) version - 2.0
PeriodofWarranty -
Ports & interfaces - Combo headphone/mic port - Yes
Ports & interfaces - DisplayPorts quantity - 2
Ports & interfaces - DisplayPort version - 1.4a
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 2.1
Ports & interfaces - Line-out - Yes
Ports & interfaces - Microphone in - Yes
Ports & interfaces - Serial ports quantity - 1
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 6
Ports & interfaces - USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity - 2
Ports & interfaces - USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity - 1
Power - Power supply - 310 W
Power - Power supply input frequency - 50/60 Hz
Power - Power supply input voltage - 100 - 240 V
Power supply, W - 310
Processor - Efficient-core base frequency - 1.5 GHz
Processor - Efficient-core Max Turbo Frequency - 4.2 GHz
Processor - Efficient cores - 12
Processor - Maximum turbo power - 219 W
Processor - Number of processors installed - 1
Processor - Performance-core base frequency - 2.1 GHz
Processor - Performance-core Max Turbo Frequency - 5.3 GHz
Processor - Performance cores - 8
Processor - Processor base power - 65 W
Processor - Processor boost frequency - 5.4 GHz
Processor - Processor cache - 33 MB
Processor - Processor cache type - Smart Cache
Processor - Processor cores - 20
Processor - Processor family - Intel® Core™ i7
Processor - Processor generation - Intel® Core™ i7 (14th gen)
Processor - Processor manufacturer - Intel
Processor - Processor model - i7-14700
Processor - Processor threads - 28
Processor clock speed, GHz - 5.40
Processor family - Intel Core i7
Processor manufacturer - Intel
Processor model - Intel Core i7-14700 (Max. 5.40GHz, 20C, 33MB)
Processor number of cores - 20
ProductName - 12V80006FR
RAID controller - No
RS-232 ports quantity - 1
ShortSummaryDescription - Lenovo ThinkCentre 12V80006FR, Intel® Core™ i7, i7-14700, 32 GB, DDR5-SDRAM, 1 TB, Windows 11 Pro
Software - Operating system installed - Windows 11 Pro
Software - Operating system language - English, Swedish, Finnish, Danish, Norwegian
Solid State Disk drive type - M.2 PCIe NVMe
Storage - Card reader integrated - No
Storage - Number of SSDs installed - 1
Storage - Number of storage drives installed - 1
Storage - NVMe - Yes
Storage - Optical drive type - No
Storage - SSD capacity - 1 TB
Storage - SSD form factor - M.2
Storage - SSD interface - PCI Express 4.0
Storage - Storage media - SSD
Storage - Total SSDs capacity - 1 TB
Storage - Total storage capacity - 1 TB
Sustainability - Sustainability certificates - GREENGUARD, TCO
Title - Lenovo ThinkCentre 12V80006FR Intel® Core™ i7 i7-14700 32 GB DDR5-SDRAM 1 TB SSD Windows 11 Pro SFF PC Black
Total storage capacity - 1 TB SSD
Trusted Platform Module (TPM) version - 2.0
URL - https://www.lenovo.com/gb/en/p/desktops/thinkcentre/m-series-sff/thinkcentre-m90s-gen-5-intel-sff/len102c0047
USB-A (USB 3.2) ports quantity - 8
USB-C (USB 3.2) ports quantity - 1
WarrantyInfo - 3-year, Onsite + 3Y Premier Support TC DT/AIO WHB (CPN), CO2 Offset 0.5 ton (2nd Generation Carbon Offset Projects)
Weight - 6.490000
Weight & dimensions - Depth - 297.7 mm
Weight & dimensions - Height - 339.5 mm
Weight & dimensions - Weight - 5.3 kg
Weight & dimensions - Width - 92.5 mm
Weight, g - 5300
Width - 395.000000
Wireles LAN (WLAN) - Yes
WLAN antennas - 2x2
WLAN type - Wi-Fi 6E
