Bluetooth - No
Brand - Lenovo
BrandPartCode - 12TA000XMX
Category - PCs/Workstations
Certificates - Certification - ErP Lot 3
MIL-STD-810H
Certificates - Compliance certificates - RoHS
Connections - Audio (3.5mm)
Connections - DisplayPort
Connections - Ethernet (RJ-45)
Connections - HDMI
Connections - Serial (RS-232)
Connections - USB-A
Connections - USB-C
Dedicated video memory (GB) - Uses system memory
Description - LENOVO M75S SFF G5 R5-8500G/16GB/512SSD/DVDVRW/RS232/W11P/3OS
Design - Cable lock slot - Yes
Design - Cable lock slot type - Kensington
Design - Chassis type - SFF
Design - Colour name - Black
Design - Placement supported - Horizontal/Vertical
Design - Product colour - Black
Design - Volume - 8.2 L
Dimensions W x D x H, mm - 92.5 x 297.7 x 339.5
Display - Display included - No
DisplayPorts quantity - 2
Ethernet LAN (RJ-45) ports quantity - 1
Graphic adapter - AMD Radeon 740M
Graphics - Discrete graphics card - No
Graphics - Discrete graphics card model - Not available
Graphics - On-board GPU manufacturer - AMD
Graphics - On-board graphics card - Yes
Graphics - On-board graphics card family - AMD Radeon
Graphics - On-board graphics card model - AMD Radeon 740M
Green certifications - Energy Star 8.0
Green certifications - EPEAT Gold
Green certifications - ErP
Green certifications - GREENGUARD
Green certifications - RoHS compliant
Green certifications - TCO 9.0
GTIN - 0198154643485
GTIN - 198154643485
HDMI ports quantity - 1
Height - 195.000000
Integrated Memory Card Reader - Yes
Internal memory - 16 GB
Internal memory type - DDR5
L3 cache, MB - 16
Length - 530.000000
LongDesc - AI-Accelerated Features Boost BusinessTake your performance to a whole new level with AI-accelerated features optimizing business. The ThinkCentre M75s Gen 5 small form factor (SFF) PC boosts and allocates power when needed, as you check every task off your daily to-do list. Plus, the device remains cool, quiet, and efficient, thanks to the AI-driven fan control.More Productivity. More Success.Small in form, yet huge on productivity, the ThinkCentre M75s Gen 5 SFF carries the power of the AMD Ryzen™ PRO processor. With ample memory and storage, it’s built to multitask right from crunching numbers, and managing data, to editing and creating multimedia projects. Perform even better with superfast integrated AMD Radeon™ graphics.A Slew of Security FeaturesEnjoy maximum security with ThinkShield — a combination of hardware and software solutions, including discrete Trusted Platform Module (dTPM) 2.0 to safeguard data, and BIOS-based Smart USB protection to prevent unauthorized access via peripherals. Also, keep physical theft at bay with chassis e-locks and the Kensington Nano Security Slot™.Innovative Device CollaborationWhile a host of ports and slots connects to multiple peripherals, the optional Smart Cable does so to different devices — even a laptop or tablet. It also helps to share computer control, data, and screen projection between systems. Moreover, the ThinkCentre M75s Gen 5 SFF is easy to deploy from both a software and hardware standpoint.Durability Meets ReliabilityWe use the US Department of Defense's MIL-STD 810H to create a balance of reliability and durability for our devices. Meeting or exceeding 12 standards and 17 procedures, the M75s Gen 5 desktop PC is engineered to run in extreme conditions — harsh variables like Arctic wilderness, desert dust storms, extreme temps, pressure, humidity, vibration, and more.Recycled Plastics & Energy-Saving CertificationsThis device uses post-consumer content (PCC) — 85% recycled acrylonitrile butadiene styrene plastics plastics in the chassis. The packaging has 60% PCC, and 30% ocean-bound plastic in the thermal shell and bag, with a Forest Stewardship Council® (FSC) certified carton. Plus, ENERGY STAR® 8.0 and TCO 9.0 certifications minimize energy costs.
LongProductName - AMD Ryzen 5 8500G (16MB Cache, 3.5GHz), 16GB DDR5-SDRAM, 512GB SSD, DVD±RW, AMD Radeon 740M, LAN, Windows 11 Pro 64-bit
LongSummaryDescription - Lenovo ThinkCentre M75s. Processor frequency: 3.5 GHz, Processor family: AMD Ryzen™ 5, Processor model: 8500G. Internal memory: 16 GB, Internal memory type: DDR5-SDRAM, Memory clock speed: 5200 MHz. Total storage capacity: 512 GB, Storage media: SSD, Optical drive type: DVD±RW. On-board graphics card model: AMD Radeon 740M. Operating system installed: Windows 11 Pro, Operating system architecture: 64-bit. Power supply: 260 W. Chassis type: SFF. Product type: PC
Manufacturer - Lenovo
Manufacturer's estimate: Product life cycle used in emission assessments, years - 4
Manufacturer?s estimate: Manufacturing-related CO2 emissions, kg - 314.7
Manufacturer?s estimate: Product life cycle CO2 emissions, kg - 479
ManufacturerPartNumber - 12TA000XMX
Maximum internal memory, GB - 64 GB
Memory - Internal memory - 16 GB
Memory - Internal memory type - DDR5-SDRAM
Memory - Maximum internal memory - 64 GB
Memory - Memory channels - Dual-channel
Memory - Memory clock speed - 5200 MHz
Memory - Memory layout (slots x size) - 1 x 16 GB
Memory - Memory slots - 2x DIMM
Memory clock speed, MHz - 5200
Memory slots - 2
Memory slots (available) - 2
Motherboard chipset - AMD PRO665
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 100,1000 Mbit/s
Network - Wi-Fi - No
Operating system provided - Windows 11 Pro
Operational conditions - Non-operating altitude - 0 - 12192 m
Operational conditions - Operating altitude - 0 - 3048 m
Operational conditions - Operating relative humidity (H-H) - 20 - 80%
Operational conditions - Operating temperature (T-T) - 5 - 35 °C
Operational conditions - Storage relative humidity (H-H) - 10 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 60 °C
Optical drive - Yes
Packaging content - Keyboard connectivity - Wired
Packaging content - Keyboard included - Yes
Packaging content - Mouse connectivity - Wired
Packaging content - Mouse included - Yes
PCI Express x1 - 1
PCI Express x16 - 1
Performance - Audio chip - Realtek ALC623-CG
Performance - Audio system - High Definition Audio
Performance - Built-in speaker(s) - Yes
Performance - Motherboard chipset - AMD PRO 665
Performance - Number of speakers - 1
Performance - Password protection - Yes
Performance - Password protection type - HDD, Power on, Supervisor
Performance - Product type - PC
Performance - Trusted Platform Module (TPM) - Yes
Performance - Trusted Platform Module (TPM) version - 2.0
PeriodofWarranty -
Ports & interfaces - Combo headphone/mic port - Yes
Ports & interfaces - DisplayPorts quantity - 2
Ports & interfaces - DisplayPort version - 1.4a
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 2.1
Ports & interfaces - Line-out - Yes
Ports & interfaces - Microphone in - Yes
Ports & interfaces - Serial ports quantity - 1
Ports & interfaces - USB 2.0 ports quantity - 4
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 4
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity - 1
Power - Power supply - 260 W
Power - Power supply input frequency - 50/60 Hz
Power - Power supply input voltage - 100 - 240 V
Power supply, W - 290
Processor - Number of processors installed - 1
Processor - Processor boost frequency - 5 GHz
Processor - Processor cache - 16 MB
Processor - Processor cache type - L3
Processor - Processor cores - 6
Processor - Processor family - AMD Ryzen™ 5
Processor - Processor frequency - 3.5 GHz
Processor - Processor generation - AMD Ryzen 8000 Series
Processor - Processor manufacturer - AMD
Processor - Processor model - 8500G
Processor - Processor threads - 12
Processor clock speed, GHz - 3.50
Processor family - AMD Ryzen 5
Processor manufacturer - AMD
Processor model - AMD Ryzen 5 8500G (Max. 5.0GHz, 16MB, 6C)
Processor number of cores - 6
ProductName - M75s
RAID controller - No
ShortSummaryDescription - Lenovo ThinkCentre M75s, 3.5 GHz, AMD Ryzen™ 5, 16 GB, 512 GB, DVD±RW, Windows 11 Pro
Software - Operating system architecture - 64-bit
Software - Operating system installed - Windows 11 Pro
Software - Operating system language - English, Swedish, Finnish, Danish, Norwegian
Solid State Disk drive type - M.2 PCIe NVMe
Storage - Card reader integrated - Yes
Storage - Number of SSDs installed - 1
Storage - Number of storage drives installed - 1
Storage - NVMe - Yes
Storage - Optical drive type - DVD±RW
Storage - SSD capacity - 512 GB
Storage - SSD form factor - M.2
Storage - SSD interface - PCI Express 4.0
Storage - Storage media - SSD
Storage - Total SSDs capacity - 512 GB
Storage - Total storage capacity - 512 GB
Sustainability - Sustainability certificates - GREENGUARD, TCO, ENERGY STAR, EPEAT Gold
Title - Lenovo ThinkCentre M75s AMD Ryzen™ 5 8500G 16 GB DDR5-SDRAM 512 GB SSD Windows 11 Pro SFF PC Black
Total storage capacity - 512 GB SSD
URL - https://www.lenovo.com/gb/en/p/desktops/thinkcentre/m-series-sff/thinkcentre-m75s-gen-5-amd-sff/len102c0050?srsltid=AfmBOoqZmMUuwxfK1ctrVATgfWvaUwwYKdzSGDpx8sbgQRZa9iL6ebws
USB-A (USB 2.0) ports quantity - 4
USB-A (USB 3.2) ports quantity - 4
USB-C (USB 3.2) ports quantity - 1
WarrantyInfo - 1-year, Onsite + 3Y Onsite upgrade from 1Y Onsite, CO2 Offset 0.5 ton (2nd Generation Carbon Offset Projects)
Weight - 6.710000
Weight & dimensions - Depth - 297.7 mm
Weight & dimensions - Height - 339.5 mm
Weight & dimensions - Package depth - 395 mm
Weight & dimensions - Package height - 530 mm
Weight & dimensions - Package weight - 7.5 kg
Weight & dimensions - Package width - 195 mm
Weight & dimensions - Weight - 4.6 kg
Weight & dimensions - Width - 92.5 mm
Weight, g - 4600
Width - 395.000000
Wireles LAN (WLAN) - No
