Brand - GIGABYTE
BrandPartCode - GB-BNIP-N100
Category - PC/Workstation Barebones
Category 1 - PC-Systeme
Category 2 - Mini-PC Barebones
Design - Cable lock slot - Yes
Design - Cable lock slot type - Kensington
Design - On/off switch - Yes
Design - Panel mounting interface - 75 x 75,100 x 100 mm
Design - Product colour - Black
Design - Product type - Mini PC barebone
Design - VESA mounting - Yes
EAN - 4719331602055
Expansion slots - PCI slots - 3
Graphics - Graphics card family - Intel
Graphics - On-board graphics card - Yes
Graphics - On-board graphics card model - Intel® UHD Graphics
GTIN - 4719331602055
LongDesc - Experience the merging of real and virtual worlds with our refreshing and impressive design.The product boasts a sleek and contemporary grid design on its exterior, creating a fresh and minimalist impression. The intricately patterned surface produces a pleasing interplay of light, shadow, reflection, and refraction from different angles, for an overall pleasant aesthetic. This design not only enhances the product's visual appeal, but also symbolizes the numerous possibilities of integrating and merging virtual and real elements within this compact mini-PC.Intel® Processor and Intel® Core™ i3 N-Series Processors deliver the performance you need at an affordable price to allow you to connect, learn, and play anywhere. The new Intel “Gracemont” CPU microarchitecture built on the latest Intel 7 process features up to 8 efficient cores (“E-cores”), enabling easy, responsive, streamlined experiences. You can scale up to BRIX BNi3 series (Intel® Core™ i3-N305) with an Intel Core i3 N-series platform for a 3.8 GHz turbo frequency and enable Intel® Wi-Fi 6E (Gig+), next-gen Intel® UHD Graphics, enhanced Image Processing Unit (IPU 6) to enjoy a balance of performance and value for the essential BRIX that’s right for you. With the above technologies, users can experience faster browsing and better productivity to accomplish more. Intel N-series processors harness power and efficiency to support learning, streaming and productivity at an affordable cost.PerformanceIntel® Processor and Intel® Core i3 N-Series Processor is much more powerful than the prior generation. The all-new Intel 7nm manufacturing process and E-core (Efficient Core) architecture, users can benefit not only from the performance boost, but also compute with greater power efficiency. Overall, generational performance improvements are easily 30% or more.USB Type-C ConnectorThe USB Type-C™ is a new reversible connector that comes with a variety of useful features, including support for USB 3.2 gen2, which provides transfer speeds of up to 10 Gb/s.Dual M.2 Storage SupportsIt can support dual M.2 SSDs (2x2280) based on PCI-e/SATA technology. Users can install two M.2 SSDs for faster boot-up and application loading, as well as a double-capacity HDD for all kinds of media content, files, and documents without any space limitations.
LongProductName - Intel N N100 (6MB Cache), Intel UHD Graphics, LAN, WLAN
LongSummaryDescription - GIGABYTE GB-BNIP-N100. Product type: Mini PC barebone. Processor socket: BGA 1264. Supported memory types: DDR4-SDRAM, Number of memory slots: 1, Maximum internal memory: 32 GB. Supported storage drive types: SSD, Storage drive interface: PCI Express, Serial ATA. Ethernet LAN (RJ-45) ports: 1. Power supply: 65 W
Manufacturer - Gigabyte
Memory - Internal memory installed - No
Memory - Maximum internal memory - 32 GB
Memory - Memory slots type - SO-DIMM
Memory - Number of memory slots - 1
Memory - Supported memory clock speeds - 3200 MHz
Memory - Supported memory types - DDR4-SDRAM
MPN - GB-BNIP-N100
Name - Gigabyte Brix GB-BNIP-N100 Barebone (Intel N100 CPU 4C/4T)
Network - Ethernet LAN - Yes
Network - LAN controller - Intel I226-V
Network - Top Wi-Fi standard - Wi-Fi 6 (802.11ax)
Network - Wi-Fi - Yes
Operational conditions - Operating temperature (T-T) - 0 - 35 °C
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Performance - Processor socket - BGA 1264
Ports & interfaces - Combo headphone/mic port - Yes
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - DisplayPorts quantity - 1
Ports & interfaces - DisplayPort version - 1.4
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - HDMI ports quantity - 2
Ports & interfaces - HDMI version - 2.1
Ports & interfaces - USB 2.0 ports quantity - 3
Ports & interfaces - USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity - 3
Ports & interfaces - USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity - 1
Power - AC adapter output current - 3.42 A
Power - AC adapter output voltage - 19 V
Power - AC input voltage - 100 - 240 V
Power - Power supply - 65 W
Processor - Built-in processor - Yes
Processor - Processor boost frequency - 3.4 GHz
Processor - Processor cache - 6 MB
Processor - Processor cache type - Smart Cache
Processor - Processor cores - 4
Processor - Processor family - Intel® N
Processor - Processor manufacturer - Intel
Processor - Processor model - N100
Processor - Processor threads - 4
Processor - Thermal Design Power (TDP) - 6 W
ProductName - GB-BNIP-N100
ShortSummaryDescription - GIGABYTE GB-BNIP-N100, Mini PC barebone, BGA 1264, DDR4-SDRAM, PCI Express, Serial ATA, Ethernet LAN, 65 W
Software - Windows operating systems supported - Windows 11
Storage - SSD form factor - M.2
Storage - Storage drive interface - PCI Express, Serial ATA
Storage - Storage drives installed - No
Storage - Storage drive sizes supported - M.2
Storage - Supported storage drive types - SSD
Title - GIGABYTE GB-BNIP-N100 PC/workstation barebone Black BGA 1264
URL - https://www.gigabyte.com/ua/Mini-PcBarebone/GB-BNIP-N200-rev-10
WarrantyInfo -
Weight - 1.307
Weight & dimensions - Depth - 116.8 mm
Weight & dimensions - Height - 28.5 mm
Weight & dimensions - Width - 163.5 mm
