Club3D CLUB 3D USB TYPE C 3.1 GEN 1 TO RJ45 2.5GB ETHERNET ADAPTER

Brand - CLUB3D
BrandPartCode - CAC-1520
Category - Laptop Docks & Port Replicators
Category Code - IOC
Description - USB 3.2 Gen1 Type C to RJ45 2.5Gbps Adapter CAC-1520 - The Club 3D USB 3.2 Gen1 Type C to RJ45 2.5Gbps Ethernet Adapter. It enables a Fast Ethernet network connection capability for desktops, notebooks or ultrabooks with a standard USB 3.2 Gen 1 Type C port. This adapter is the best solution for latest devices without an onboard Ethernet port. Its the perfect accessory for your travels in addition its USB powered so no need for external power adapter. • Supports USB 3.2 Gen 1 Type C Port and 2.5Gbps RJ45 output • Supports 10M/100M/1G/2.5G Bandwidth • Supports twisted pair crossover detection and auto-correction • USB Bus power (No external Power Needed) • Supports USB3.2 Gen1, USB 2.0 and USB 1.1 ( When using lower USB versions the ethernet speed will be affected ) • Supports WOL (Wake-On-Lan) Full Duplex Flow (10M / 100M / 1G / 2.5G Rate) Auto Negotiation • Supports Windows 8/Windows 10/ Mac OsX 10.6 to 10.13 Note : Driver Software installation is required • Power Consumption : 4.75V ~ 5.25V • Normal Operating power : < 80mA 10M < 130mA 100M GTIN - 0841615101443
GTIN - 841615101443
GTIN - 8719214471248
Logistics data - Harmonized System (HS) code - 8544 4290
LongDesc - CAC-1520 - The Club 3D USB 3.2 Gen1 Type C to RJ45 2.5Gbps Ethernet Adapter. It enables a Fast Ethernet network connection capability for desktops, notebooks or ultrabooks with a standard USB 3.2 Gen 1 Type C port.This adapter is the best solution for latest devices without an onboard Ethernet port.Its the perfect accessory for your travels in addition its USB powered so no need for external power adapter.
LongProductName - USB 3.1 Gen1 Type C to RJ45 2.5Gbps
LongSummaryDescription - CLUB3D USB 3.2 Gen1 Type C to RJ45 2.5Gbps Adapter. Connectivity technology: Wired, Host interface: USB 3.2 Gen 1 (3.1 Gen 1) Type-C. Ethernet LAN data rates: 10,100,1000,2500 Mbit/s. Product colour: Black, Certification: ROHS, FCC, and CE EMI requirements. Power source type: USB, Power connector: USB Type-C. Width: 35 mm, Depth: 240 mm, Height: 15 mm
Model - CAC-1520
Network - Ethernet LAN - Yes
Network - Ethernet LAN (RJ-45) ports - 1
Network - Ethernet LAN data rates - 10,100,1000,2500 Mbit/s
Packaging composition - Paper/cardboard packaging weight - 56 g
Packaging composition - Plastic packaging weight - 3 g
Packaging composition - Total paper/cardboard packaging weight - 0 g
Packaging composition - Total plastic packaging weight - 0 g
Packaging data - Package depth - 95 mm
Packaging data - Package height - 35 mm
Packaging data - Package weight - 86 g
Packaging data - Package width - 260 mm
Packaging data - Quantity per pack - 1 pc(s)
Performance - Card reader integrated - No
Performance - Certification - ROHS, FCC, and CE EMI requirements
Performance - Product colour - Black
Ports & interfaces - Connectivity technology - Wired
Ports & interfaces - Host interface - USB 3.2 Gen 1 (3.1 Gen 1) Type-C
Ports & interfaces - Microphone in - No
Power - Power connector - USB Type-C
Power - Power source type - USB
ProductName - USB 3.2 Gen1 Type C to RJ45 2.5Gbps Adapter
Product Net Weight - 0.034 kg
Product Type - Adapter
RJ45 Input/Output connectors - 1
ShortSummaryDescription - CLUB3D USB 3.2 Gen1 Type C to RJ45 2.5Gbps Adapter, Wired, USB 3.2 Gen 1 (3.1 Gen 1) Type-C, 10,100,1000,2500 Mbit/s, Black, ROHS, FCC, and CE EMI requirements, USB
Software - Windows operating systems supported - Yes
Title - CLUB3D USB 3.2 Gen1 Type C to RJ45 2.5Gbps Adapter
Unit Box Height - 0.295
Unit Box Length - 0.095
Unit Box Width - 0.035
Unit Calculated Volume - 0.0009809 cubm
Unit Calculated Weight - 0.08 kg
Units per Pallet - 0
Units per Shipping Box - 1
URL -
USB-C Input/Output connectors - 1
Vendor Homepage - www.club-3d.com/en/detail/2468/usb_3.2_gen1_type_c_to_rj45_2.5gbps_adapter/
Warranty - 24 months
WarrantyInfo -
Weight & dimensions - Depth - 240 mm
Weight & dimensions - Height - 15 mm
Weight & dimensions - Weight - 34 g
Weight & dimensions - Width - 35 mm
