Startech ACTIVE OPTICAL HDMI 2.1 CABLE .

ARTIKEL1 - ACTIVE OPTICAL HDMI 2.1 CABLE
ARTIKEL2 - .
Brand - StarTech.com
BrandPartCode - 8K-A-100F-HDMI-CABLE
Breite - 0
Category - HDMI Cables
EANCode - 0065030907897
Features - Audio Return Channel (ARC) - Yes
Features - AWG wire size - 28/30
Features - Cable jacket material - Polyvinyl chloride (PVC)
Features - Cable length - 30.4 m
Features - Cable rating - CMP
Features - Cable shielding - Aluminum mylar foil
Features - Cable type - Round cable
Features - Colour depth - 12 bit
Features - Connector 1 - HDMI Type A (Standard)
Features - Connector 1 form factor - Straight
Features - Connector 1 gender - Male
Features - Connector 2 - HDMI Type A (Standard)
Features - Connector 2 form factor - Straight
Features - Connector 2 gender - Male
Features - Connector contacts plating - Gold
Features - Data transfer rate - 48 Gbit/s
Features - HDCP - Yes
Features - HDCP version - 2.3
Features - High Dynamic Range (HDR) supported - Yes
Features - High Dynamic Range (HDR) technology - High Dynamic Range 10+ (HDR10 Plus)
Features - Maximum refresh rate - 120 Hz
Features - Product colour - Black, Silver
Features - Supported digital audio channels (uncompressed) - 7.1, 32
Features - Supported graphics resolutions - 4096 x 2160, 7680 x 4320
Features - Unidirectional - Yes
GRUPPE1 - Cables
GRUPPE2 - AUDIO / VIDEO CABLE
GTIN - 0065030907897
GTIN - 065030907897
HERSTELLER - STARTECH
Hoehe - 0
HSTNUMMER - 8K-A-100F-HDMI-CABLE
Laenge - 0
Logistics data - Master (outer) case height - 265 mm
Logistics data - Master (outer) case length - 425 mm
Logistics data - Master (outer) case width - 465 mm
Logistics data - Products per master (outer) case - 20 pc(s)
LongDesc - Reliably connect high-bandwidth HDMI 2.1 devices through plenum spacesRoute this Ultra High Speed HDMI 2.1 Hybrid Active Optical Cable (AOC) through office plenum spaces for long distance transmission of 8K 60Hz video and high quality audio.Hybrid AOC ConstructionThe HDMI 2.1 AOC incorporates a hybrid construction consisting of fiber optic cores and copper conductors. This enables the offloading of low-bandwidth signals (EDID/HDCP/eARC) to maintain high-bandwidth transmission of 8K 60Hz video over fiber. The fiber optic inner cores and shielded copper conductors greatly reduce EMI for optimal signal quality across longer distances.Full-Featured HDMI 2.1The 8K HDMI Fiber Optic Cable supports full HDMI 2.1 specifications:• High Bit Rate 3 (HBR3) supports up to 48Gbps bandwidth for higher refresh rates• High Dynamic Range (HDR10+) with 12-bit processing for higher contrast ratio and vibrant, cinematic picture quality• Enhanced Audio Return Channel (eARC) for uncompressed 7.1 and 32-channel audio• Display Stream Compression 1.2a (DSC) for maximum resolution output• Forward Error Correction to manage data transmission errors• High-Bandwidth Digital Content Protection (HDCP 2.3) for a secure connection between source and displayFlexible Plenum-Rated CablingThis Plenum-Rated HDMI 2.1 Cable features a CMP-rated cable jacket with low-smoke and flame characteristics. It is ideal for use in plenum spaces in buildings (e.g., ceilings and in-wall installations). The optical fiber core is reinforced with Aramid strands for tensile strength, and is rated to withstand over 6,000 bending cycles at 120 degrees. This protects the cable from damage when routing through tight spaces requiring multiple bends.The 4.6mm (0.18in) cable outer diameter is flexible and slimmer than typical passive HDMI cables, making it suitable for installation in space-constrained environments.Please Note : This cable is unidirectional and must be installed in a specific direction. Please refer to the SOURCE and DISPLAY labels on the HDMI connectors to ensure that each end corresponds with the correct hardware.The StarTech.com Advantage
LongProductName - StarTech.com 100ft (30.4m) HDMI 2.1 Hybrid Active Optical Cable (AOC), CMP Plenum, 8K60Hz, Ultra High Speed HDMI 2.1/2.0 Cord
LongSummaryDescription - StarTech.com 100ft (30.4m) HDMI 2.1 Hybrid Active Optical Cable (AOC), CMP, Plenum Rated, 8K Ultra High Speed HDMI 2.1/2.0 Fiber Optic Cable, 48Gbps, 8K 60Hz/4K 120Hz, HDR10+/FRL/TMDS/eARC. Cable length: 30.4 m, Connector 1: HDMI Type A (Standard), Connector 1 gender: Male, Connector 2: HDMI Type A (Standard), Connector 2 gender: Male, Connector contacts plating: Gold, Data transfer rate: 48 Gbit/s, Audio Return Channel (ARC), Product colour: Black, Silver
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 45 °C
Operational conditions - Storage temperature (T-T) - -10 - 70 °C
Packaging data - Package depth - 220 mm
Packaging data - Package height - 38 mm
Packaging data - Package weight - 900 g
Packaging data - Package width - 235 mm
Packaging data - Quantity per pack - 1 pc(s)
ProductName - 100ft (30.4m) HDMI 2.1 Hybrid Active Optical Cable (AOC), CMP, Plenum Rated, 8K Ultra High Speed HDMI 2.1/2.0 Fiber Optic Cable, 48Gbps, 8K 60Hz/4K 120Hz, HDR10+/FRL/TMDS/eARC
ShortSummaryDescription - StarTech.com 100ft (30.4m) HDMI 2.1 Hybrid Active Optical Cable (AOC), CMP, Plenum Rated, 8K Ultra High Speed HDMI 2.1/2.0 Fiber Optic Cable, 48Gbps, 8K 60Hz/4K 120Hz, HDR10+/FRL/TMDS/eARC, 30.4 m, HDMI Type A (Standard), HDMI Type A (Standard), 48 Gbit/s, Audio Return Channel (ARC), Black, Silver
Stck_Kart - 9998
Stck_Pal - 0
Storno - Y
Title - StarTech.com 100ft (30.4m) HDMI 2.1 Hybrid Active Optical Cable (AOC), CMP, Plenum Rated, 8K Ultra High Speed HDMI 2.1/2.0 Fiber Optic Cable, 48Gbps, 8K 60Hz/4K 120Hz, HDR10+/FRL/TMDS/eARC
URL - https://www.startech.com/en-us/8K-A-100F-HDMI-CABLE
WarrantyInfo - 2 Years
Weight & dimensions - Cable diameter - 4.6 mm
