Zalman TeraMax II SE, 1000W, 80PLUS Gold, ATX 3.1, PCIe 5.1

-
Posti parcel machineWithin 1-2 working days6.99 €
-
Delivery with Posti courier mailWithin 1-2 working days10.99 €
- Producer: Zalman
- Power output: 1000W
- 80 PLUS certification: 80 PLUS Gold
- Fan size: 120 mm
- Modular cables: Fully-Modular
- Processor plug-in: 2 x 8-pin(4+4) EPS
- PCI-E: 4 X 6+2pin
This Zalman brand power supply unit has an 80 PLUS Gold energy efficiency certificate and a power output of 1000W.
1000W power supply unit will satisfy the requirements of the best gaming computer. There will be enough power for an overclocked high-end processor, multiple high-class graphic cards, a wide water-cooling system, and multiple hard drives.
This power supply unit is equipped with a 120 mm fan, which is the industry standard for ensuring quiet operation in average computers. If you want an especially quiet unit, look for one with a fan diameter of 135 mm or 140 mm.
The power supply has received the 80 PLUS Gold energy efficiency certificate, which guarantees at least 90% efficiency at 50% load. This means that for every 100W of power received from the electrical grid, at least 90W is delivered to your computer components, and the remaining 10W is lost as heat.
The color of this power supply is Melna. The cable color is Melna and they are flat.
This power supply's noise level is 25-30 dB and it has a Cybenetics A - noise level certificate.
This power supply unit has fully-modular cables (Fully-modular) – you can connect and disconnect all the included cables as needed, reducing clutter and improving ventilation. This will be useful for those with a partially transparent computer case and for whom the aesthetic factor is particularly important.
Accessories included -
ATX version - 3.1
Certificates 80+ - 80 PLUS Gold
Description - Cybenetics ETA PLATINUM
Model TMX II SE 1000W posiada certyfikat ETA PLATINUM, co oznacza, że jego gwarantowana typowa sprawność wynosi 91%.
Cybenetics LAMBDA
Oceniana jest nie tylko sprawność zasilaczy, ale również generowany przez nie hałas. Zasilacz TMXII SE 1000W posiada klasę Lambda dla certyfikowanego cichego zasilacza.
Zgodność z Intel ATX 3.1 Guide
Budżet mocy PCIe AIC i zasilacza wykorzystany do szczytowego wzrostu mocy (Dopuszcza do 200% maksymalnej mocy znamionowej)
Wymagania dotyczące sprawności przy niskim obciążeniu (Wysoka sprawność przy niskim obciążeniu)
Gotowy na PCIe 5.1 i 12V-2X6!
Kompatybilny z ATX 3.1
W 100% gotowy na procesory Intel i AMD
Gotowy na PCIe 5.1
Obsługuje dedykowane 16-pinowe złącze PCIe 5.1 dla najnowszych kart graficznych
Pozłacane złącze
Stabilne zasilanie dzięki zastosowaniu pozłacanego złącza z niskimi stratami mocy
Wyższa wydajność i oszczędność energii Certyfikat 80 PLUS GOLD
Certyfikat 80 PLUS Gold gwarantuje sprawność na poziomie 88%, 90% i 87% przy obciążeniu 20%, 50% i 100%, co znacząco zmniejsza całkowite zużycie energii w systemie. Wyższa wydajność zasilacza oznacza mniejszy upływ prądu, a co za tym idzie mniej ciepła, hałasów o wysokiej częstotliwości i hałasu wentylatora.\
W pełni modułowy zasilacz
W pełni modułowa konstrukcja minimalizuje rezystancję i spadki napięcia na przewodach oraz obniża impedancję, co dodatkowo zwiększa efektywność energetyczną, łącząc tylko przewody Twój system musi zapewnić płynny przepływ powietrza aby zapewnić chłodzenie.
Designation - CE+WEEE
dimension depth - 130 mm
dimension height - 205 mm
Dimensions - 140 x 150 x 86 mm
dimension weight - 2520 g
dimension width - 300 mm
ean - 8800263650453
Fan - 12 cm
Filters / protection - Circuit
Filters / protection - Current too high
Filters / protection - Overload
Filters / protection - Surge
Filters / protection - Thermal
Filters / protection - Voltage drop
Floppy power connectors - 1
Form Factor - ATX
guarantee - 24
guarantee_type - normal
MB power connector - 20 + 4 pin
Modular power supply - Yes
MOLEX power connectors - 0
name - ZALMAN ZM1000-TMX2SE TERAMAX 1000W 80+ GOLD
Number of connectors PATA - 0
Number of power connectors 12VHPWR - 1
Number of power connectors PCI-E 16-pin Gen 5 - 0
Number of power supply connector 4+4-pin 12V - 2
Number of power supply connector 4-pin 12V - 0
Number of power supply connectors PCI-E 6 +2 pin - 4
Number of USB 10p connectors - 0
Other features -
PCI-E 6-pin power connectors - 0
PCI-E 8-pin power connectors - 0
PFC - Active
Power supply - 1000 W
producer - Zalman
SATA power connectors - 3
vendpn - ZM1000-TMX2SE
Weight - 2.8 kg
