ASRock Phantom Gaming, 1300W, ATX 3.1, 80PLUS Gold, PCIe 5.1
-
Posti parcel machineWithin 1-2 working days6.99 €
-
Post OfficeWithin 1-2 working days6.99 €
-
Delivery with Posti courier mailWithin 1-2 working days10.99 €
- Producer: Asrock
- Power output: 1300W
- 80 PLUS certification: 80 PLUS Gold
- Fan size: 135 mm
- Modular cables: Fully-Modular
- Processor plug-in: 2 x 8-pin(4+4) EPS
- PCI-E: 6 x 6+2pin
This Asrock brand power supply unit has an 80 PLUS Gold energy efficiency certificate and a power output of 1300W.
Thanks to the large 135 mm cooling fan diameter, this power supply is much quieter than average. The fan has a larger blade area, which provides the necessary airflow at lower fan speeds, thereby reducing the overall noise and vibration levels to a minimum.
80 PLUS Gold energy efficiency certificate received by this power supply guarantees at least 90% efficiency at 50% load. In other words, for every 100 W of energy the power supply receives from the power grid, at least 90 W goes to your computer components, and the remaining 10 W is lost as heat.
The color of the power supply is Melna. It is equipped with flat cables, whose color is Melna.
The noise level of this power supply is 20-25 dB and it has a Cybenetics A noise level certificate.
Thanks to the fact that this power supply has modular cables, you can add hard drives, video cards, and other components as needed, using the various cables included in the package. This way, there are fewer wires in the computer, which improves ventilation and appearance (especially useful for those who choose a partially transparent case).
Accessories included -
Category 1 - Netzteile
Certificates 80+ - 80 PLUS Gold
Description -
Design - Cooling type - Active
Design - Fan diameter - 13.5 cm
Design - Number of fans - 1 fan(s)
Design - On/off fan switch - Yes
Design - On/off switch - Yes
Design - Product colour - Black
Designation - CE+WEEE
dimensionalWeight - 1847
dimension depth - 130 mm
dimension height - 315 mm
Dimensions - 86 x 150 x 180 mm
dimension weight - 4410 g
dimension width - 235 mm
ean - 4710483948633
EAN - 4710483948633
Fan - 13.5 cm
Filters / protection - Circuit
Filters / protection - Current too high
Filters / protection - Overload
Filters / protection - Surge
Filters / protection - Thermal
Filters / protection - Voltage drop
Floppy power connectors - 0
guarantee - 120
guarantee_type - normal
Manufacturer - ASRock
MB power connector - 24 pin
Modular power supply - Yes
MOLEX power connectors - 3
MPN - 90-UXP130-GFEAAB
Name - 1300W ASRock Phantom Gaming PG-1300G 1300W ATX 80+ Gold black retail
name - Power supply PG-1300G 1300W 80PLUS GOLD full modular
Number of connectors PATA - 0
Number of power connectors 12VHPWR - 2
Number of power connectors PCI-E 16-pin Gen 5 - 0
Number of power supply connector 4+4-pin 12V - 2
Number of power supply connector 4-pin 12V - 0
Number of power supply connectors PCI-E 6 +2 pin - 6
Number of USB 10p connectors - 0
Other features -
Packaging content - Cables included - CPU, PATA, PCIe, Peripheral (Molex), Peripheral (Molex) to SATA 3.3, SATA
PCI-E 6-pin power connectors - 0
PCI-E 8-pin power connectors - 0
Performance - 80 PLUS certification - 80 PLUS Gold
Performance - ATX version - 3.1
Performance - Bearing technology - FDB
Performance - Mean time between failures (MTBF) - 100000 h
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
PFC - Active
Ports & interfaces - Cabling type - Fully-Modular
Ports & interfaces - CPU power cable length - 65 cm
Ports & interfaces - CPU power connector (4+4 pin) - Yes
Ports & interfaces - Motherboard power cable length - 60 cm
Ports & interfaces - Motherboard power connector - 20+4 pin ATX
Ports & interfaces - Number of EPS connectors - 2
Ports & interfaces - Number of SATA power connectors - 9
Ports & interfaces - PCI Express power cable length - 67.5 cm
Ports & interfaces - PCI Express power connectors (6+2 pin) - 6
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 3
Ports & interfaces - SATA power cable length - 100
Ports & interfaces - SATA power cable length - 450
Power - Power protection features - Over current
Power - Power protection features - Overheating
Power - Power protection features - Overload
Power - Power protection features - Over voltage
Power - Power protection features - Short circuit
Power - Power protection features - Under voltage
Power - Total power - 1300 W
Power supply - 1300 W
producer - ASRock
producerCode - 90-UXP130-GFEAAB
productName - Asrock Phantom Gaming PG-1300G power supply unit 1300 W 20+4 pin ATX ATX Black
productSize - Normal
Safety warning - Warnings - Avoid contact of the product with water or other liquids.
Safety warning - Warnings - Do not open the case - risk of electric shock.
Safety warning - Warnings - The product is not suitable for disposal with municipal waste - dispose of in accordance with local regulations.
SATA power connectors - 9
sizeX - 312
sizeY - 235
sizeZ - 126
vendpn - PG-1300G
warrantyLength - 120
warrantyType - G
Weight - 4.43
weight - 4720
Weight & dimensions - Depth - 150 mm
Weight & dimensions - Height - 86 mm
Weight & dimensions - Width - 150 mm
