Cougar STC500, 500W, 80PLUS

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
ID: 1155300 Product code: STC500
Goods are not available at the moment We do not accept orders for the delivery of this product. We do not have information as to when this product will be available. Our suppliers currently do not provide information about possible delivery times of the product and the possible price when it is on sale again.

TopPC.fi website provides information about this product for information only, so that customers can see the product and compare it to the products available for sale now.

Warranty: 2 years (Warranty for business entities 1 year)
Main product parameters All parameters
  • Producer: Cougar
  • Power output: 500W
  • 80 PLUS certification: 80 PLUS (White)
  • Fan size: 120 mm
  • Modular cables: Nav
  • Processor plug-in: 1 x 8-pin(4+4) EPS
  • PCI-E: 2 X 6+2pin
Similar Products
This product Cougar STC500, 500W, 80PLUS
Seasonic Prime Fanless PX, 500W, 80PLUS Platinum
Recommended XPG PROBE, 700W, 80PLUS Bronze
Recommended XPG PROBE, 600W, 80PLUS Bronze
Recommended Gigabyte GP-P550SS, 550W, 80PLUS Silver
Show similar specs. Hide similar specs.
42.06 €
176.31 €
56.75 €
45.59 €
42.38 €
Basic information
Cybenetics Efficiency certification Nav Nav Nav Nav Nav
Cybenetics Noise level certification Nav Nav Nav Nav Nav
Power supply type ATX ATX ATX ATX ATX
Power output 500W 500W 700W 600W 550W
80 PLUS certification 80 PLUS (White) 80 PLUS Platinum 80 PLUS Bronze 80 PLUS Bronze 80 PLUS Silver
Total amperage (+12V) 38A 41A 54A 46A
Fan size 120 mm Fanless 120 mm 120 mm 120 mm
Functionality
Cable colour Raiba Melna Melna Melna Melna
Lighting Nav Nav Nav Nav Nav
Color Melna Melna Melna Melna Melna
Modular cables Nav Fully-Modular Nav Nav Nav
Ports and equipment
PCI-E 5.0/5.1 Nav Nav Nav Nav Nav
Processor plug-in 1 x 8-pin(4+4) EPS 2 x 8-pin(4+4) EPS 2 x 8-pin(4+4) EPS 1 x 8-pin(4+4) EPS 1 x 8-pin(4+4) EPS
Motherboard power 20+4pin 20+4pin 20+4pin 20+4pin 20+4pin
PCI-E 2 X 6+2pin 2 X 6+2pin 2 X 6+2pin 2 X 6+2pin 2 X 6+2pin
SATA cconnectors 5 Eight Core 5 5 5
4pin Molex 2 3 2 2 3
Description

Available for purchase is a power supply produced by Cougar with a power output of 500W. The product has been awarded an 80 PLUS (White) energy efficiency certificate.

120 mm fans, with which this power supply unit is equipped, will ensure industry standard quiet operation. For especially quiet power supply unit operation, we recommend purchasing a 135 mm or 145 mm diameter fan.

80 PLUS (White) energy efficiency certificate, which this power supply unit has received, guarantees at least 80% efficiency. In other words, for every 100 W of energy the power supply unit gets from the electrical grid, at least 80 W goes to your computer components, while the remaining 20 W is lost as heat.

The color of this power supply is Melna. The cable color is Raiba and they are flat.

This is a power supply that complies with ATX 2.0 requirements. The power supply has only 6-pin and 8-pin connectors, which can handle only 75 W and 150 W of power, respectively. Modern graphics cards' high power needs exceed the capabilities of ATX 2.0 connectors. When building a system with a very powerful GPU, such as an RTX 4070, you will need an ATX 3.* standard power supply.

This power supply has no removable cables and all cables are attached to the power supply. It has a simple design, but it works just as well as a power supply with modular cables.

Basic information
Cybenetics Efficiency certification : Nav
Cybenetics Noise level certification : Nav
Power supply type : ATX
Power output 500W
The capacity of the power supply unit in watts. A higher capacity means higher stability of the computer operation. The recommended capacity of the power supply unit of a modern average computer is 500 W and above. If you use several HDDs, a powerful video card and processor it is recommended to buy a power supply unit with the capacity 600 W or above.
80 PLUS certification : 80 PLUS (White)
Total amperage (+12V) : 38A
Fan size : 120 mm
Functionality
Cable colour : Raiba
Lighting : Nav
Color : Melna
Modular cables : Nav
Ports and equipment
PCI-E 5.0/5.1 : Nav
Processor plug-in : 1 x 8-pin(4+4) EPS
Motherboard power : 20+4pin
PCI-E : 2 X 6+2pin
SATA cconnectors : 5
4pin Molex : 2
More detailed specification
+3.3V - 16 Ampērs (55 Vats)
+5V - 16 Ampērs (55 Vats)
+5VSB - 2.5 Ampērs
+12V - 38 Ampērs (456 Vats)
-12V - 0.3 Ampērs
4-pin Peripheral Power Connector - 2
4/8-pin +12V Power Connector - 1
6/8-pin PCI Express Connector - 2
20+4-pin Main Connector - 1
Aizsardzība pret ķēdēm - Pārspriegums Undervoltage Temperatūras pārslodze Short Circuit Protection Over Power
Barošanas adaptera un barošanas avota funkcijas - Active PFCLow noise
Barošanas ierīces atrašanās vieta - Plug-in-module
Barošanas ierīces tips - Power Supply
EAN kods - 4710483774317
Efficiency - 86procenti
Fan Diameter - 120 milimetrs
Fans Installed Quantity - 1
Gabali iepakojumā - 1
Garantija Produkti atgriežami - Jā
Garantijas apstiprināšanas kritēriji - Sērijas numurs
Garantijas termiņš (mēnesis) - 24 mēnesis(-i)
Ieejas spriegums - AC 200-240 volts
Iekļauti aksesuāri - Ātrā lietošanas pamācība
Iepakojuma svars Brutto (kg) - 1.76 kilograms
Iepakojuma svars Netto (kg) - 0.28 kilograms
Iepakojuma tips - Kaste
Iepakojums kastē - 9
Image - https://content.it4profit.com/pimg/s/resize/900x900x900x900/240119150028948286.jpg
Image - https://content.it4profit.com/pimg/s/resize/900x900x900x900/240119150028991351.jpg
Image - https://content.it4profit.com/pimg/s/resize/900x900x900x900/240119150029038324.jpg
Input Frequency - 50 Hercs
Kastes svars Brutto (kg) - 18.4 kilograms
Maksimālais darba mitrums - 85 procenti
Maksimālais nedarba mitrums - 95 procenti
Maksimālā darba vides temperatūra - 40 Celsija grāds
Maksimālā izejas jauda - 500 Vats
Maksimālā nedarbojošās apkārtējās vides temperatūra - 70 Celsija grāds
Mazumtirdzniecības iepakojuma neto svars Plastmasa - 0.03 kilograms
Mazumtirdzniecības iepakojums Neto svars Kartona kārba - 0.25 kilograms
Minimālais darba gaisa mitrums - 20 procenti
Minimālais neekspluatācijas gaisa mitrums - 5 procenti
Minimālā darba vides temperatūra - 10 Celsija grāds
Minimālā nedarbojošās apkārtējās vides temperatūra - -40 Celsija grāds
ProductCard - https://content.it4profit.com/itshop/itemcard_cs.jsp?ITEM=240117074000035621&THEME=asbis&LANG=lv
ProductCategory - Kabeļi
ProductCode - STC500
ProductDescription - COUGAR STC500 PSU, 80 plus White, 500W
ProductType - Power Supply Unit
S-ATA Connector - 5
Vendor - COUGAR GAMING
Ārējā krāsa - Melna
42.06 €
