ARTIKEL1 - SX-15G 15IN 1280X1024
ARTIKEL2 - 24/7 BNC S-VIDO CCTV MODE
Brand - AG Neovo
BrandPartCode - SX5G0011E0100
Breite - 0
Category - Surveillance Monitors
Design - Certification - CB, FCC
Design - LED indicators - Yes
Design - Mounting type - Freestanding/Wall-mounted
Design - Product colour - Black
Design - Product type - CCTV monitor
Design - Tilt adjustment - Yes
Design - Tilt angle - 20°
Design - Tilt angle range - 0 - 20°
Display - Anti-glare screen - Yes
Display - Display aspect ratio - 4:3
Display - Display brightness - 300 cd/m²
Display - Display diagonal - 38.1 cm (15")
Display - Display number of colours - 16.2 million colours
Display - Display resolution - 1024 x 768 pixels
Display - Display type - TFT
Display - Glass thickness - 3 mm
Display - Horizontal scan range - 24 - 83 kHz
Display - NTSC coverage (typical) - 72%
Display - Panel type - VA
Display - Pixel pitch - 0.297 x 0.297 mm
Display - Response time - 5 ms
Display - RGB colour space - NTSC
Display - Vertical scan range - 50 - 75 Hz
Display - Viewing angle, horizontal - 176°
Display - Viewing angle, vertical - 176°
EANCode - 4710739595857
GRUPPE1 - Displays
GRUPPE2 - Lcd Monitor
GTIN - 4710739595857
HERSTELLER - AG NEOVO TECHNOLOGY
Hoehe - 0
HSTNUMMER - SX5GA011E0100
Laenge - 0
LongDesc - The SX-Series features commercial-grade security monitors specifically for CCTV video monitoring and surveillance. It is equipped with analog and digital connectivity as well as DisplayPort, VGA, BNC input and output for video looping and HDMI input. Built to meet the rigorous demands of 24/7 operations, SX-Series can display high performance and stable image quality with AG Neovo’s Anti-Burn-in™ technology, preventing image ghosting and ensuring professionals view the present video footage. Coupled with NeoV™ Optical Glass and metal casing, the display is shielded from incidental damage and impact to withstand in critical environments. For those professionals who still use the security cameras with a 4:3 aspect ratio, SX-Series security monitors offer great options to meet security demands.4:3 Aspect Ratio Monitor for Video SurveillanceThe aspect ratio of the security cameras is critical to match the aspect ratio of the monitors. Except for 16:9 aspect ratio is ideal for HD resolution on widescreen monitor, a 4:3 aspect ratio monitor can perfectly display analog video signals to conform to NTSC and PAL standards without distorting and stretching images.Commercial-grade Security MonitorRobust Design for Critical SurveillanceA professional security monitor is designed to use in a challenging and high impact environment for 24/7 use. The SX-Series monitor screens fit with NeoV™ Optical Hard Glass encased in a durable metal shell to prevent most types of damages, like scratching and high-velocity impact damage, and water and dust resistance in tough environments.LCD Ghost Image Prevention for 24/7 OperationSince the surveillance monitors are running for 24/7 operation, the monitors keep displaying the same and still images, where an uninterrupted image displayed for a long period of time results in permanent discoloration of the display panel, causing permanent “Ghost Images” (also known as image sticking and burn-in effect). To counter the effects of LCD burn-in or “ghosting”, AG Neovo’s security & surveillance monitor utilises propriety Anti-Burn-in™ technology. This technology has been tested and proven to prevent image burn-in and assure an extended life-span for the display.Versatile Connectivity with BNC and HDMI InputsThe SX-Series supports both analog and digital video input sources for connection to various video surveillance equipment, including DisplayPort, HDMI, DVI, VGA, S-Video, and Composite (BNC). With Its built-in BNC input/output, users enable to connect security cameras to the monitor directly for instant monitoring, testing and utilize the BNC loop out feature to feed the videos to DVR system or other devices while there is some cable limitation between analog cameras and monitors in a specific deployment. The BNC monitor is compatible with NTSC and PAL video standards, and it can automatically detect the video format and switch to NTSC or PAL standard. For better configuration, it is also equipped with an HDMI connector, allowing receiving digital input sources.Image EnhancementSuper ResolutionWith better improving the clarity of security footage in real time, SX-Series’ Super Resolution technology upscales and enhances the images to present more image detail in layered texture horizontally and vertically. It essentially makes an image with a higher resolution in a more natural way.CCTV ModeThe CCTV Mode can maximize image clarity in the scenario of low light surveillance footage. With this pre-configured CCTV mode, users can quickly fine tune their security solutions on the proven values adjustment of Backlight, Black level, Sharpness, Saturation, GAMMA, Noise Reduction and Super Resolution, etc., which saves them more time on testing and readjusting while proceeding on-site installation.Night ModeWhile applying to critical surveillance, such as sailing in the dark seas, users have higher requirements for their monitors’ image clarity in low-light environments. The Night Mode features dimming the Backlight Level in dark environments and remaining the clear viewing with high visibility for reliable navigation.Easy to Clean and DisinfectMost of the monitors or displays are hard to clean and disinfect because of the common household bleach, alcohol, or other ammonia-made cleaning products that may damage the screen surface. The cleaning products with stronger effects will destroy the screen’s anti-reflective or anti-glare coatings, causing the clouding effect problems. The SX-Series security monitors with NeoV™ Optical Hard Glass Screen can withstand ammonia, alcohol, bleach, and cleaning products with high PH levels, making them easily cleaned and disinfected with water, alcohol, and other cleaning solutions.PID Command & Ctrl for RS232 System IntegrationPID Command & Ctrl software helps integrators easily control and integrate AG Neovo security & surveillance displays via LAN or RS232 connections. Users can quickly find command codes for programming into external control systems for remote management, OSD-related settings, and easy control on deployed displays on its simple and intuitive interface.
LongProductName - Commercial-grade security monitor, 15" LED-Backlit TFT LCD (VA), 1024 x 768, 300 cd/m2, 4:3, DisplayPort, HDMI, DVI, VGA, S-Video, Composite (2 x BNC) In / Out, RS-232, Audio In / Out, 24/7
LongSummaryDescription - AG Neovo SX-15G. Product type: CCTV monitor, Mounting type: Freestanding/Wall-mounted, Product colour: Black. Display diagonal: 38.1 cm (15"), Display resolution: 1024 x 768 pixels, Display type: TFT. Speaker power: 2 W, Panel mounting interface: 75 x 75,100 x 100 mm, Cable lock slot type: Kensington. Power source type: DC, Power supply type: External, Power consumption (typical): 13 W. Weight: 4.8 kg, Height: 315 mm, Depth: 53.5 mm
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 95%
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Packaging content - AC adapter included - Yes
Packaging content - Cables included - AC, Audio, VGA
Packaging content - Quantity - 1
Packaging content - Quick start guide - Yes
Performance - Built-in speaker(s) - Yes
Performance - Cable lock slot - Yes
Performance - Cable lock slot type - Kensington
Performance - Number of built-in speakers - 2
Performance - Panel mounting interface - 75 x 75,100 x 100 mm
Performance - Speaker power - 2 W
Performance - VESA mounting - Yes
Ports & interfaces - 3.5 mm (1/8-inch) in - Yes
Ports & interfaces - Composite video in - 1
Ports & interfaces - Composite video out - 1
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - DVI-D ports quantity - 1
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 1.4
Ports & interfaces - USB 2.0 ports quantity - 1
Ports & interfaces - USB port - Yes
Ports & interfaces - VGA (D-Sub) ports quantity - 1
Power - AC adapter output current - 1.5 A
Power - AC adapter output voltage - 12 V
Power - Power consumption (off) - 0.3 W
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (typical) - 13 W
Power - Power source type - DC
Power - Power supply type - External
ProductName - SX-15G
ShortSummaryDescription - AG Neovo SX-15G, CCTV monitor, Freestanding/Wall-mounted, Black, 20°, 0 - 20°, CB, FCC
Stck_Kart - 9998
Stck_Pal - 0
Storno - Y
Technical details - Compliance certificates - CE, REACH, RoHS, WEEE
Technical details - Sustainability compliance - Yes
Title - AG Neovo SX-15G CCTV monitor 38.1 cm (15") 1024 x 768 pixels
URL - https://displays.agneovo.com/gl/products/sx-series-advanced/16064-sx-15g
WarrantyInfo -
Weight & dimensions - Depth - 53.5 mm
Weight & dimensions - Depth (with stand) - 155 mm
Weight & dimensions - Height - 315 mm
Weight & dimensions - Height (with stand) - 359 mm
Weight & dimensions - Package depth - 199 mm
Weight & dimensions - Package height - 460 mm
Weight & dimensions - Package weight - 6.8 kg
Weight & dimensions - Package width - 470 mm
Weight & dimensions - Weight - 4.8 kg
Weight & dimensions - Weight (with stand) - 4.4 kg
Weight & dimensions - Width - 380 mm
Weight & dimensions - Width (with stand) - 380 mm
DVI is a digital standard and ensures high image quality, however, thanks to the big size of the plug and the inability of the standard to develop further due to a few technical restrictions this type of connection is gradually losing its popularity to modern HDMI and DisplayPort standards.
