Synology Kamera TC500

Accessories included - TC500 main unit Installation guide RJ-45 connector cap Screw packaging
Audio - Audio formats supported - G.711
Audio - Built-in microphone - Yes
Camera - Camera shutter speed - 1/16000s~1/30
Camera - Lens viewing angle, diagonal - 132°
Camera - Lens viewing angle, horizontal - 110°
Camera - Lens viewing angle, vertical - 56°
Camera design - Other
Category 1 - Netzwerk
Category 2 - Netzwerkkameras
Category Code - FNC
Certificates - FCC CB IC CE UKCA BSMI VCCI RCM KC JATE REACH WEEE ROHS NDAA TAA
Code - TC500
Color - White
Colour - White
Connectors - microSD
Connectors - RJ-45
Description - TC500 AI-Powered Camera for Integrated Smart Surveillance Inconspicuous ceiling-mounted cameras perfect for indoor surveillance at any angle. • Crisp Video, Night and Day 5 MP sensor with wide-angle lens, recording at 30 FPS, and high-power IR LED for 30 meters of night vision • Edge AI Detection and Search On-camera AI powers people and vehicle detection, intrusion detection, and Instant Search • No Device License Required Camera requires no Surveillance Station Device License or activation • Failover Edge Recording Supports failover recording onto microSD, in case of network failure • Security and Compliance Suitable for sensitive applications thanks to HTTPS/ SRTP support and US NDAA/TAA compliance
Description - TC500 camera AI camera for integrated intelligent surveillance Synology cameras are designed to integrate with Surveillance Station1, providing exceptional ease of use with quick and simple setup, bulk configuration, and hassle-free firmware updates. They feature camera-based AI technology that streamlines Surveillance Station deployment with intelligent features. The TC500 is a versatile, IP67-rated, 5MP wide-angle camera powered by artificial intelligence for indoor and outdoor use. With a high resolution of 2880x1620 at 30 fps (FPS), a wide viewing angle of 110° horizontally and the ability to record images at night, the TC500 model will capture all the details you need. Clear image, day and night 5 MP matrix with a wide-angle lens, recording at 30 fps (FPS) and a high-power infrared LED that provides the ability to record images at night with a range of 30 meters. Edge detection and search based on artificial intelligence The artificial intelligence technology in the camera allows you to detect people and vehicles, detect intrusions and use the Instant Search function. No device license required The camera does not require a Surveillance Station license or activation. Emergency recording directly in the camera Supports emergency recording to microSD card in case of network failure. Security and compliance Suitable for sensitive applications thanks to HTTPS/SRTP support and compliance with the US NDAA/TAA standard. Capture quality A detailed, wide-angle field of view provides protection for large areas, day and night. High resolution 5 MP (2880×1620) with 16:9 aspect ratio ensures clear and detailed videos A wide 110° horizontal viewing angle allows for comprehensive coverage of large areas and reduces the need for multiple cameras Large F1.8 aperture and multi-exposure HDR mode ensure good low-light performance without overexposing brighter areas A high-power infrared LED ensures clear images at night with a range of up to 30 meters Smart video features Camera-based AI features enable monitoring with intelligent analysis. People and vehicle detection distinguishes people and vehicles from other moving objects with high accuracy Intrusion detection identifies people and vehicles and sends alerts when a virtual boundary is crossed in a designated direction Instant Search allows you to quickly search for people, vehicles and past traffic in a given area Pair with Synology DVA models for more intelligent analysis such as facial recognition, license plate recognition and people counting Streamlining and integration Integration with Surveillance Station streamlines deployment and maintenance1. The quick and simple process of installing one or multiple cameras using Surveillance Station or DS cam speeds up deployment No purchase or activation of a surveillance device license is required Camera customization and maintenance features are available directly in Surveillance Station or DS cam Continuous firmware updates provide new features and security improvements and can be deployed in bulk, with or without internet access Emergency storage in edge devices increases system reliability by automatically switching to microSD card recording in the event of a network failure Security and privacy protection Thanks to integrated security, you protect your material, from recording to archiving. Support for HTTPS and SRTP protocols enables encryption of network and video transfers, authentication and integrity protection Storing data on Synology devices gives users full ownership of their recordings Privacy masking can be irreversibly applied to footage or applied to live view to cover sensitive areas View a list of connected devices for individual cameras and stay safe by disconnecting or blocking unrecognized devices NDAA and TAA compliance meets U.S. government procurement regulations Synology's long-term firmware support includes security patches and updates
Design - Form factor - Turret
Design - IK code - IK10
Design - International Protection (IP) code - IP67
Design - Mounting type - Ceiling
Design - Product colour - White
Design > Chassis type - Turret
Designation - CE+WEEE
dimensionalWeight - 590
dimension depth - 133 mm
dimension height - 125 mm
Dimensions - 97 x 88 mm
Dimensions - Ø97 x 88 mm
dimension weight - 615 g
dimension width - 180 mm
EAN - 4711174725106
ean - 4711174725106
Electronic Shutter Speed - 1/16000s~1/30s
Environment - Outdoor
Environment requirements - Operating temperature (IR off): -30°C to 50°C (-22°F to 122°F) Operating temperature (infrared on): -30°C to 40°C (-22°F to 104°F) Operating relative humidity: 5% to 95% relative humidity (non-condensing) Storage temperature: -40°C to 60°C (-40°F to 140°F) Storage relative humidity: 5% to 95% relative humidity (non-condensing)
Features > Colour of product - White
Features > Package content - Main Unit x1; Installation guide x1; Screw pack x1; RJ45 cap cover x1
Focal Length - 2.8 mm
Frames per second - 30
Gross Weight Kg - 0,6
guarantee - 36
guarantee_type - normal
Image sensor - Optical sensor size - 25.4 / 2.7 mm (1 / 2.7")
IR Illumination - Yes
Lens - Focal length: 2.8 mm Aperture: F1.8 Shutter speed: 1/16000 s~1/30 s DORI: D: 60 m, O: 24 m, R: 12 m, I: 6 m
Lens system - Lens diameter - 2.8 mm
Lens system - Maximum aperture number - 1.8
Lens system - Number of lenses - 1
Lens system > Lens type - 2.8 mm
Link - https://www.synology.com/en-global/products/camera-500#features
Management, monitoring, configuration -
Manufacturer - Synology
Manufacturer Code - TC500
Manufacturer Name - Synology
Memory > Memory slots - MicroSD (up to 128 GB)
Memory card reader - Yes
Memory standard - SDHC
Memory standard - SDXC
Microphone - Built-in
Microphone - Yes
Model - TC500
Motion detection - Yes
MPN - TC500
name - IP Camera TC500 IP67 1/2,7 cala 850nm 2,8mm F1.8 850nm RJ45 Turret IK10 3Y
Name - Synology TC500 Security camera
Name - Synology | Camera | TC500 | Turret | 5 MP | 2.8 mm | H.264/H.265 | MicroSD (up to 128 GB)
Network - Bluetooth - No
Network - Ethernet interface type - Fast Ethernet
Network - Ethernet LAN - Yes
Network - Wi-Fi - No
Network Camera Type - HDTV/Megapixel/Outdoor
Networking > Power over Ethernet (PoE) - PoE (802.3af)
Network protocols -
Night mode - Yes
Night vision - Infra-red wavelength - 850 nm
Night vision - LED type - IR
Night vision - Night vision - Yes
Night vision - Night vision distance - 30 m
Operating temperature range - -30°C to 50°C
Operational conditions - Operating relative humidity (H-H) - 5 - 95%
Operational conditions - Operating temperature (T-T) - -30 - 50 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 95%
Operational conditions - Storage temperature (T-T) - -40 - 60 °C
Operational conditions > Operating temperature (T-T) - -30–50 °C
Other features - Impact resistance: IK10 Image recording at night: up to 30 meters Infrared LED wavelength: 850 nm HDR mode with multiple exposure 3DNR 2DNR
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 216.00 mm
Package features > Gross height (mm) - 203.00 mm
Package features > Gross width (mm) - 145.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 272 pc(s)
Package features > Paper/Pasteboard - 170.00 g
Package features > Plastic (No PET) - 30.00 g
Package features > Tare weight (kg) - 0.20 kg
Package features > Volume (m3) - 0.01 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
Packaging content - Number of cameras - 1
PDF - https://www.blobs.lt/products/0/7/1/6/0/4/adc24137a2e681f5a021995bf747c908/original.pdf
Performance - Connectivity technology - Wired
Performance - Day/night mode - Yes
Performance - Placement supported - Indoor & outdoor
Performance - Type - IP security camera
Performance > Built-in microphone - Yes
Performance > Video compression formats - H.264/H.265
Picture quality > Camera type - Indoor/Outdoor
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Power - DC output voltage - 12
Power - Power consumption (typical) - 4.8 W
Power - Power source type - DC, PoE
Power > Power - 12V DC: 4.8 W W
Power consumption - 4.8 Watts
Power options - PoE
Power supply - PoE (802.3af) or 12V DC
producer - Synology
producerCode - TC500
productName - Synology TC500 security camera Turret IP security camera Indoor & outdoor 2880 x 1620 pixels Ceiling
Product Net Weight - 0.387 kg
productSize - Normal
Protection class - IP67
Resolution - 5 Mega Pixel
Resolution - 2880 x 1620
Safety warning - Warnings - Avoid direct contact with water to prevent electrical damage.
Safety warning - Warnings - Ensure that the product is properly installed and protected against falling.
Safety warning - Warnings - The product contains electronic components; do not dispose of with the normal household waste.
Security - Call management IP filter HTTPS encryption SRTP connection Automatic locking Tagged firmware
Security - Human and vehicle targets classification - Yes
Security - Video motion detection - Yes
Sensor - 1/2.7"
Sensor size - 1/2.7" CMOS
Short description - Synology Kamera TC500
sizeX - 175
sizeY - 135
sizeZ - 125
Speakers built-in - No
Special functions - Picture settings: Brightness, contrast, saturation, sharpness, white balance, High Dynamic Range (HDR), 3D/2D noise reduction, exposure control, 50/60 Hz flicker reduction, day/night mode, overlay, privacy masking Event analysis: Person and vehicle detection (including crowd detection and detection of suspicious objects in specific areas), intrusion detection, motion detection, tampering detection, sound detection Instant Search: People, vehicle, traffic Video orientation: Rotate (0°, 90°, 180°, 270°), flip, mirror
Storage - Built-in HDD - No
Storage - Card reader integrated - Yes
Storage - Compatible memory cards - SD
Storage - Maximum memory card size - 128 GB
System Requirements -
Technical details > Gross weight - 0.59 kg
Technical details > Net weight - 0.39 kg
Technical details > Other features - Crisp Video, Night and Day; Edge AI Detection and Search; No Device License Required; Failover Edge Recording; Security and Compliance
Technical details > Producer - Synology
Technical details > Producer product family - Camera
Technical details > Producer product name - TC500
Technical details > Sensors - 1/2.7"
Two-way transmission - No
type - fixed dome camera
Unit Box Height - 0.126
Unit Box Length - 0.178
Unit Box Width - 0.133
Unit Calculated Volume - 0.004013 cubm
Unit Calculated Weight - 0.72 kg
Units per Shipping Box - 10
Vendor Homepage - www.synology.com/en-global/products/camera-500
vendpn - TC500
Video - Flip & mirror - Yes
Video - Maximum resolution - 2880 x 1620 pixels
Video - Noise reduction - Yes
Video - Noise reduction technology - 2D noise reduction, 3D noise reduction
Video - Total megapixels - 5 MP
Video - Video compression formats - H.264
Video - Video compression formats - H.265
Video > Maximum video resolution - 2880x1620 pixels
Video > Max IR distance - 30m
Video > Megapixel - 5 MP
Viewing angle, horizontal - 110 °
Viewing angle, vertical - 56 °
Warranty - 36
Warranty - 36 month(s)
Warranty - 36 months
warrantyLength - 36
warrantyType - F
Weight - 0.616
Weight - 387 g
weight - 620
Weight & dimensions - Diameter - 9.7 cm
Weight & dimensions - Height - 88 mm
Weight & dimensions - Weight - 387 g
Wireless communication - No
