Silverstone SX500-LG, 500W, 80PLUS Gold

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
ID: 639536 Product code: SST-SX500-LG v2.1
Goods are not available at the moment We do not accept orders for the delivery of this product. We do not have information as to when this product will be available. Our suppliers currently do not provide information about possible delivery times of the product and the possible price when it is on sale again.

TopPC.fi website provides information about this product for information only, so that customers can see the product and compare it to the products available for sale now.

Warranty: 2 years (Warranty for business entities 1 year)
Main product parameters All parameters
  • Producer: Silverstone
  • Power output: 500W
  • 80 PLUS certification: 80 PLUS Gold
  • Fan size: 120 mm
  • Modular cables: Fully-Modular
  • Processor plug-in: 2 x 8-pin(4+4) EPS
  • PCI-E: 2 X 6+2pin
Similar Products
This product Silverstone SX500-LG, 500W, 80PLUS Gold
Silverstone EX500-B, 500W, 80PLUS Bronze
Silverstone SX450-B, 450W, 80PLUS Bronze
Silverstone SX700-LPT, 700W, 80PLUS Platinum
Silverstone SX800-LTI, 800W, 80PLUS Titanium
Show similar specs. Hide similar specs.
117.51 €
92.64 €
88.20 €
176.17 €
225.59 €
Basic information
Cybenetics Efficiency certification There isn't There isn't There isn't There isn't Cybenetics Titanium
Cybenetics Noise level certification There isn't There isn't There isn't Cybenetics Standard ++ Cybenetics Standard +
Power supply type SFX-L SFX SFX SFX-L SFX-L
Power output 500W 500W 450W 700W 800W
80 PLUS certification 80 PLUS Gold 80 PLUS Bronze 80 PLUS Bronze 80 PLUS Platinum 80 PLUS Titanium
Total amperage (+12V) 40A 41.66A 37.5A 58.4A 66A
Fan size 120 mm 92 mm 80 mm 120 mm 120 mm
Functionality
Cable colour Black Black Black Black Black
Lighting None None None None None
Color Black Black Black Black Black
Modular cables Fully-Modular None None Fully-Modular Fully-Modular
Ports and equipment
PCI-E 5.0/5.1 There is no There is no There is no There is no There is no
Processor plug-in 2 x 8-pin(4+4) EPS 2 x 8-pin(4+4) EPS 1 x 8-pin(4+4) EPS 2 x 8-pin(4+4) EPS 2 x 8-pin(4+4) EPS
Motherboard power 20+4-pin 20+4-pin 20+4-pin 20+4-pin 20+4-pin
PCI-E 2 X 6+2pin 2 X 6+2pin 2 X 6+2pin 4 X 6+2pin 4 X 6+2pin
SATA cconnectors 3 3 3 9 12
4pin Molex 2 2 2 3 3
Description

Available for purchase is a power supply produced by Silverstone with a power output of 500W. The product has been awarded an 80 PLUS Gold energy efficiency certificate.

120 mm fans, with which this power supply unit is equipped, will ensure industry standard quiet operation. For especially quiet power supply unit operation, we recommend purchasing a 135 mm or 145 mm diameter fan.

The power supply has received the 80 PLUS Gold energy efficiency certificate, which guarantees at least 90% efficiency at 50% load. This means that for every 100W of power received from the electrical grid, at least 90W is delivered to your computer components, and the remaining 10W is lost as heat.

The color of this power supply is Melna. The cable color is Melna and they are flat.

This power supply unit has been assigned the ATX 2.0 standard. This means that the unit is equipped only with 6-pin and 8-pin connectors, providing 75W and 150W power respectively. It's important to note that this unit will be compatible with RTX 4070 and more powerful cards, but you will need to use the 2x8-pin to 16-pin 12VHPWR adapter included with the graphics card. ATX 2.0 power connectors are not designed to handle the high power fluctuations of modern graphics cards; therefore, if you are building a system with a powerful GPU, such as the RTX 4070, we recommend choosing a power supply unit with the ATX 3.* standard and 12VHPWR (PCIe 5.0) connector.

Thanks to the fact that this power supply has modular cables, you can add hard drives, video cards, and other components as needed, using the various cables included in the package. This way, there are fewer wires in the computer, which improves ventilation and appearance (especially useful for those who choose a partially transparent case).

This is a SFX (Small Form Factor eXtended) type power supply. It is smaller in size and power compared to AFX type units, but is ideally suited for small form (SFF) computers where space is limited. It has smaller size fans and it is compatible with such motherboards as Mini-ITX.

Basic information
Cybenetics Efficiency certification : There isn't
Cybenetics Noise level certification : There isn't
Power supply type : SFX-L
Power output 500W
The capacity of the power supply unit in watts. A higher capacity means higher stability of the computer operation. The recommended capacity of the power supply unit of a modern average computer is 500 W and above. If you use several HDDs, a powerful video card and processor it is recommended to buy a power supply unit with the capacity 600 W or above.
80 PLUS certification : 80 PLUS Gold
Total amperage (+12V) : 40A
Fan size : 120 mm
Functionality
Cable colour : Black
Lighting : None
Color : Black
Modular cables : Fully-Modular
Ports and equipment
PCI-E 5.0/5.1 : There is no
Processor plug-in : 2 x 8-pin(4+4) EPS
Motherboard power : 20+4-pin
PCI-E : 2 X 6+2pin
SATA cconnectors : 3
4pin Molex : 2
More detailed specification
category - PC Components|Power Supplies|Modular Power Supplies
Category_1 - Power
Category_2 - Computer Power Supplies
code - SST-SX500-LG V 2.1
ean - 4710679810881
EAN_code - 4710679810881
Manufacturer - Silverstone Technology
Manufacturer_code - SST-SX500-LG V2.1
name - SilverStone SST-SX500-LG v2.1 SFX-L Netzteil 80 PLUS Gold, modular - 500 Watt
Name - SilverStone SST-SX500-LG V2.1, PC PSU
Weight - 1,96
