FSP Hydro Ti PRO, 1000W, 80PLUS Titanium, ATX 3.1, PCIe 5.1
Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
-
Posti parcel machineWithin 1-2 working days6.99 € -
Post OfficeWithin 1-2 working days6.99 €
-
Delivery with Posti courier mailWithin 1-2 working days10.99 €
Main product parameters All parameters
- Producer: FSP
- Power output: 1000W
- 80 PLUS certification: 80 PLUS Titanium
- Fan size: 135 mm
- Modular cables: Fully-Modular
- Processor plug-in: 2 x 8-pin(4+4) EPS
- PCI-E: 5 x 6+2pin
Description
Available for purchase is a power supply produced by Fortron with a power output of 1000W. The product has been awarded an 80 PLUS Titanium energy efficiency certificate.
This 1000W power supply unit will be able to run the best gaming computer. It has enough power to run multiple high-end graphics cards, a large water cooling system, an overclocked high-end processor, and several hard drives.
Thanks to the large 135 mm cooling fan diameter, this power supply is much quieter than average. The fan has a larger blade area, which provides the necessary airflow at lower fan speeds, thereby reducing the overall noise and vibration levels to a minimum.
The power supply has received the 80 PLUS Titanium energy efficiency certificate, which guarantees at least 94% efficiency at 50% load. This means that for every 100W of power the supply receives from the electrical grid, at least 94W is delivered to your computer components, while the remaining 6W is lost as heat.
The color of the power supply is Melna. It is equipped with flat cables, whose color is Melna.
The noise level of this power supply is lower than 15 dB and it has a Cybenetics A ++ noise level certification.
This power supply has modular cables, which provide the possibility to add video card cables, hard disk cables, etc. as needed from the supplied range. This way, the wire clutter in the computer is reduced, improving ventilation and the aesthetic factor (particularly important for those who purchase a partially transparent case).
Basic information
Cybenetics Efficiency certification
: Cybenetics Titanium
Cybenetics Noise level certification
: Cybenetics A ++
Power supply type
: ATX
Power output
1000W
The capacity of the power supply unit in watts. A higher capacity means higher stability of the computer operation. The recommended capacity of the power supply unit of a modern average computer is 500 W and above. If you use several HDDs, a powerful video card and processor it is recommended to buy a power supply unit with the capacity 600 W or above.
80 PLUS certification
: 80 PLUS Titanium
Total amperage (+12V)
: 83.33A
Fan size
: 135 mm
Functionality
Cable colour
: Black
Lighting
: None
Color
: Black
Modular cables
: Fully-Modular
Ports and equipment
PCI-E 5.0/5.1
: 1 x 600W 12V-2X6 (5.1)
Processor plug-in
: 2 x 8-pin(4+4) EPS
Motherboard power
: 20+4-pin
PCI-E
: 5 x 6+2pin
SATA cconnectors
: 12
4pin Molex
: 4
More detailed specification
Brand - FSP
BrandPartCode - PPA10A3807
Category - Power Supply Units
Category_1 - Power
Category_2 - Computer Power Supplies
Design - Cooling type - Active
Design - Fan diameter - 13.5 cm
Design - Fan location - Top
Design - Number of fans - 1 fan(s)
Design - On/off switch - Yes
Design - Product colour - Black
EAN_code - 4713224527456
GTIN - 4713224527456
LongDesc - New ATX PSU SpecificationsUpdated ATX 3.0 specifications for the next-generation hardware power demands and ensure users get the most stable and cost-optimized performance possible with the highest power efficiency.Ultra Power DensityCompared to general high-efficiency & high wattage PSU 170mm length, Hydro Ti PRO series delivers high power with shorter size of 150mm.80 Plus® Titanium CertificationHydro Ti PRO series is a power supply with 80 PLUS® Titanium provides over 94% efficiency at the load of 50 % and Cybenetics-certified for lower power consumption.Lambda A++ CertificationHydro Ti PRO ATX3.0(PCIe5.0) 1000W got Lambda A++ noise rating. By averaging the noise measurements that take from Cybenetics test results.Smarter, Quieter and Longer Lasting Eco Friendly FanUnder 50% loading, you will enjoy Zero RPM experience when eco semi-fanless fan control switch is on, , and get the benefit of long lifespan from a 135mm fluid dynamic bearing fan.Off-Wet, Off-Dust and Off-Stain CoatingCovered with exclusive conformal coating which guarantees to offer better and reliable performance in harsh environments and is tested to work in environments up to 95% relative humidity.LLC TopologyZero voltage switching of the main switches thereby dramatically lowering switching losses and boosting efficiency.450V, 105°C Japanese E-CapacitorsHydro Ti PRO series uses Japanese bulk capacitors to ensure a longer lifetime and protect your equipment from the infamous capacitor leakage problem.Unleash +12V Power OutputVGA card is a power-hungry component that needs most power. A single +12V rail design can deliver stable power and avoid any overloading conditions.Fully Modular Design Fully-modular design not just for easier installation, but also provides your system a neat and tidy look.Stylish & Changeable Side StickerIncludes unique side stickers for DIY enthusiasts and gamers.
LongProductName - 1000 W, 80 PLUS Titanium, ATX 3.0, 100-240V, 50/60 Hz, 150 x 150 x 85 mm
LongSummaryDescription - FSP Hydro Ti PRO 1000W Power supply unit ATX ATX3.1 Black. Total power: 1000 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 60 cm, PCI Express power connectors (12+4 pin) cable length: 700 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Titanium. Product colour: Black, Cooling type: Active, Fan diameter: 13.5 cm. Cables included: CPU, PCIe, Peripheral (Molex), SATA
Manufacturer - Fortron
Manufacturer_code - PPA10A3807
Name - FSP Hydro Ti PRO 1000W, PC power supply (1x 12-pin high power GPU, 5x PCIe, cable management, 1000 watts)
Packaging content - Cables included - CPU, PCIe, Peripheral (Molex), SATA
Performance - 80 PLUS certification - 80 PLUS Titanium
Performance - ATX version - 3.0
Performance - Bearing technology - FDB
Performance - EPS version - 2.92
Performance - Noise level - 15 dB
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
Ports & interfaces - Cabling type - Fully-Modular
Ports & interfaces - CPU power cable length - 70 cm
Ports & interfaces - CPU power connector (4+4 pin) - Yes
Ports & interfaces - Motherboard power cable length - 60 cm
Ports & interfaces - Motherboard power connector - 20+4 pin ATX
Ports & interfaces - Number of SATA power connectors - 12
Ports & interfaces - PCI Express power connectors (6+2 pin) - 5
Ports & interfaces - PCI Express power connectors (12+4 pin) cable length - 700 mm
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 4
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - Combined power (+3.3V) - 120 W
Power - Combined power (+5V) - 120 W
Power - Combined power (+5Vsb) - 18.6 W
Power - Combined power (+12V) - 1000 W
Power - Combined power (-12V) - 18.6 W
Power - Efficiency - 94%
Power - Input current - 13-6 A
Power - Max output current (+3.3V) - 20 A
Power - Max output current (+5V) - 20 A
Power - Max output current (+5Vsb) - 3 A
Power - Max output current (+12V) - 83.33 A
Power - Max output current (-12V) - 0.3 A
Power - Power protection features - Over current, Over power, Over voltage, Overheating, Short circuit
Power - Total power - 1000 W
ProductName - Hydro Ti PRO 1000W Power supply unit ATX ATX3.1 Black
ShortSummaryDescription - FSP Hydro Ti PRO 1000W Power supply unit ATX ATX3.1 Black, 1000 W, 100 - 240 V, 50/60 Hz, 13-6 A, 120 W, 1000 W
Title - FSP Hydro Ti PRO 1000W Power supply unit ATX ATX3.1 Black
URL - https://www.fsplifestyle.com/en/product/HydroTIPRO1000W.html
WarrantyInfo - 10 years
Weight - 4,09
Weight & dimensions - Depth - 150 mm
Weight & dimensions - Height - 86 mm
Weight & dimensions - Width - 150 mm
