8-pin 12V power connectors - 0
Accessories included - Zasilacz 4 x Śruby Opaski kablowe x5 Przewód zasilający AC Instrukcja obsługi Kabel + Torba na kable
ATX version - 3.1
Brand - Zalman
BrandPartCode - ZM850-TMX2SE
Category - Power Supply Units
Certificates - Compliance certificates - EAC, TÜV mark, RoHS, CB, CE, cTUVus
Certificates 80+ - 80 PLUS Gold
Description - Zasilacz Zalman ZM850-TMX2SE Termax 850W 80+ GOLD
Cybenetics ETA GOLD
Model TMX II SE 850W posiada certyfikat sprawności ETA Gold, co oznacza, że gwarantuje typową sprawność na poziomie 89%.
Cybenetics LAMBDA
Oceniana jest nie tylko sprawność zasilaczy, ale również generowany przez nie hałas. Zasilacz TMXII SE 850W posiada klasę Lambda dla certyfikowanego cichego zasilacza.
Aktywny układ PFC z maksymalnym współczynnikiem mocy 99%
Układ aktywnego PFC z maksymalnym współczynnikiem mocy 99% zapewnia stałą i stabilną moc wyjściową, a także wysoką sprawność energetyczną. Wysoka sprawność gwarantuje bezpieczną i stabilną pracę systemu z niskim poziomem hałasu podzespołów, mniejszą emisją ciepła i minimalnymi wahaniami napięcia zasilania.
Przetwornica DC-DC 12 V o 100% dostępności
Zasilacz obsługuje szeroką gamę komponentów komputerowych, minimalizując wahania napięcia wyjściowego i maksymalizując napięcie wyjściowe na szynie 12 V DC aby zapewnić stabilną pracę systemu.
Wbudowany filtr EMI redukujący szumy
Filtr EMI został zainstalowany w celu tłumienia częstotliwości powodujących szumy, co zapewnia lepszą pracę systemu.
Design - Fan diameter - 12 cm
Design - Product colour - Black
Designation - CE+WEEE
dimension depth - 125 mm
dimension height - 205 mm
Dimensions - 140 x 150 x 86 mm
dimension weight - 2520 g
dimension width - 300 mm
ean - 8800263650446
Fan - 12 cm
Filters / protection - Circuit
Filters / protection - Current too high
Filters / protection - Overload
Filters / protection - Surge
Filters / protection - Thermal
Filters / protection - Voltage drop
Floppy power connectors - 0
Form Factor - ATX
GTIN - 8800263650446
guarantee - 24
guarantee_type - normal
LongDesc - Cybenetics ETA GOLDThe TMX II SE 850W has an ETA gold efficiency rating, meaning it has a guaranteed typical efficiency of 89%.Cybenetics LAMBDANot only the efficiency of the power supplies is evaluated, also the noise generated by it.TMXII SE 850W has Lambda grade for certificated silent PSU.Intel ATX 3.1 Guide CompatiblePCIe AIC and PSU Power Budget used for Peak Power Excursion(Allows up to 200% of maximum rated power)Low Load Efficiency Requirements(High efficiency at the low load)PCIe 5.1 & 12V-2X6 Ready!ATX 3.1 compatible100% ready for Intel and AMDPCIe 5.1 ReadySupports a dedicated 16pin PCIe 5.1 connector for the latest graphics cardsGOLD PLATING CONNECTORStable power supply by applying gold-plated connector with low power lossActive PFC With 99% Maximum Power FactorActive PFC system with maximum power factor of 99% providing consistent and stable output as well as high energy efficiency. High efficiency ensures safe, stable system operation with low component noise, less heat from parts, and minimal fluctuation of power supply. 12V DC-TO-DC Convertor With 100% AvailabilityThe power supply supports a wide range of PC components, minimizing variations in output voltage, maximizing 12V DC rail output to provide a stable system operationBuilt-In High PerformanceCapacitor That Handles Up To 221˚FHighly reliable capacitor used to supply stable voltage even at high temperatures up to 221˚FBuilt-In EMI Filter For Noise ReductionEMI filter is installed to suppress frequency that causes noise for better system operation.Aluminum Solid CapacitorAll capacitors in the power supply are top quality and very reliable in supplying stable power even at high temperature.Superior Efficiency & Energy Savings80 PLUS GOLD Certified80PLUS Gold guarantees 88%, 90%, 87% efficiency with 20%, 50% and 100% load rates, significantly reducing overall system power consumption.The higher efficiency of the PSU means that there is less leakage of current, which means less heat, high frequency noises, and fan noise.Full modular PSUFull modular design minimizes resistance and voltage drop on the cables and lowers impedance to further enhance energy efficiency, connecting only the cables your system needs to allow for smooth airflow to cool the system.Multiple Protection Circuit SystemMultiple protection circuit system protects your systemOTP (Over Temperature Protection)OCP (Over Current Protection)OPP (Over Power Protection)OVP (Over Voltage Protection)UVP (Under Voltage Protection)SCP (Short Circuit Protection)Zalman’s TechnologyIntegrated advanced design method to reduce voltage fluctuation to within 3% to ensure a stable power supply.[FLAT Cable]Unlike sleeved cables, Zalman Tech applies flat cable to all cables, which makes the cables easier to organize when building your system.Mainboard cable and sense voltage cable are connected simultaneously to reduce voltage fluctuation.Eco-Friendly ProductsAll Materials Included Are Environmentally Safe And Harmless.RoHS CompliantCertified products are environmentally safe that do not cause harm to the human body.Certification is received when XRF testing determines that the 10 hazardous substances is below the standard value for the electronic products exported to Europe.Unlike other inexpensive products, ZALMAN’s products are produced from the beginning with RoHS standards in mind. Intel and AMD RYZEN 100% Compatible and ReadyMeets all the needs of Intel and AMD RYZEN processors for high performance PC users.High Quality, Performance Parts used to be durable and reliableIt supplies smooth power to the PC while reducing unnecessary power consumption by using high performance parts that are durable and reliableGuaranteed MaximumEfficiency of 92% (230V)Up to 92% energy conversion efficiency reduces power leakage and maintenance costsProviding energy savings and a stable system operation environment for your systemFDB(Fluid Dynamic Bearing)Quiet and Long Lifespan Cooling TechnologyFDB(Fluid Dynamic Bearing) has benefits of low noise and long lifespan.It discharges internal heat quickly and provides sufficient cooling at a low RPM to maximize stable, safe power supply.Compact SizeStandard ATX size provides wide compatibilityHoneycomb VentsHoneycomb vents provide superior performance and ventilation, discharging hot air quickly
LongProductName - TeramaxII SE 850W, ATX Ver.3.1, Active PFC, 80 PLUS GOLD
LongSummaryDescription - Zalman TeramaxII SE. Total power: 850 W, AC input voltage: 100 - 260 V, AC input frequency: 50/60 Hz. Motherboard power connector: 18+10 pin ATX, SATA power cable length: 500 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Fan diameter: 12 cm. Compliance certificates: EAC, TÜV mark, RoHS, CB, CE, cTUVus
MB power connector - 20 + 4 pin
Modular power supply - Yes
MOLEX power connectors - 0
name - ZALMAN ZM850-TMX2SE TERAMAX 850W 80+ GOLD
Number of connectors PATA - 0
Number of power connectors 12VHPWR - 1
Number of power connectors PCI-E 16-pin Gen 5 - 0
Number of power supply connector 4+4-pin 12V - 2
Number of power supply connector 4-pin 12V - 0
Number of power supply connectors PCI-E 6 +2 pin - 3
Number of USB 10p connectors - 0
Operational conditions - Operating temperature (T-T) - 10 - 40 °C
Other features -
PCI-E 6-pin power connectors - 0
PCI-E 8-pin power connectors - 0
Performance - 80 PLUS certification - 80 PLUS Gold
Performance - Bearing technology - FDB
Performance - Mean time between failures (MTBF) - 100000 h
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
PFC - Yes
Ports & interfaces - Motherboard power connector - 18+10 pin ATX
Ports & interfaces - SATA power cable length - 500 mm
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 260 V
Power - Combined power (+3.3V) - 100 W
Power - Combined power (+5V) - 100 W
Power - Combined power (+5Vsb) - 15 W
Power - Combined power (+12V) - 850 W
Power - Combined power (-12V) - 3.6 W
Power - Efficiency - 90%
Power - Input current - 12-6 A
Power - Max output current (+3.3V) - 20 A
Power - Max output current (+5V) - 20 A
Power - Max output current (+5Vsb) - 3 A
Power - Max output current (+12V) - 70.83 A
Power - Max output current (-12V) - 0.3 A
Power - Power Factor Correction (PFC) type - Active
Power - Power protection features - Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Power - Total power - 850 W
Power supply - 850 W
producer - Zalman
ProductName - TeramaxII SE
SATA power connectors - 3
ShortSummaryDescription - Zalman TeramaxII SE, 850 W, 100 - 260 V, 50/60 Hz, 12-6 A, Active, 100 W
Title - Zalman TeramaxII SE power supply unit 850 W 18+10 pin ATX ATX Black
URL - https://www.zalman.com/EN/Product/ProductDetail.do?pageIndex=1&pageSize=10&productSeq=1636&searchCategory1=0&searchCategory2=-99&searchCategory3=-99&searchKey=&searchWord=ZM850-TMX2SE&active=pro_specTab
vendpn - ZM850-TMX2SE
WarrantyInfo -
Weight - 2.6 kg
Weight & dimensions - Depth - 150 mm
Weight & dimensions - Height - 86 mm
Weight & dimensions - Weight - 2.6 kg
Weight & dimensions - Width - 140 mm
