ID: 1150293
Product code: FOCUS-GX-1000-V4
In stock >50 units
Warranty: 3 years
Seasonic Focus GX (2024), 1000W, 80PLUS Gold, ATX 3.1, PCIe 5.1
Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
-
Posti parcel machineWithin 1-2 working days6.99 € -
Delivery with Posti courier mailWithin 1-2 working days10.99 €
Main product parameters All parameters
- Producer: Seasonic
- Power output: 1000W
- 80 PLUS certification: 80 PLUS Gold
- Fan size: 120 mm
- Modular cables: Fully-Modular
- Processor plug-in: 2 x 8-pin(4+4) EPS
- PCI-E: 3 x 6+2pin
Description
Available for purchase is a power supply produced by Seasonic with a power output of 1000W. The product has been awarded an 80 PLUS Gold energy efficiency certificate.
This 1000W power supply unit will be able to run the best gaming computer. It has enough power to run multiple high-end graphics cards, a large water cooling system, an overclocked high-end processor, and several hard drives.
The diameter of this power supply unit's fan is 120 mm, which will ensure quiet operation in mid-range computers. For especially quiet power supply unit operation, we recommend selecting a fan with a 135 mm or 140 mm diameter.
The power supply has received the 80 PLUS Gold energy efficiency certificate, which guarantees at least 90% efficiency at 50% load. This means that for every 100W of power received from the electrical grid, at least 90W is delivered to your computer components, and the remaining 10W is lost as heat.
The power supply unit contains a connector designed for modern graphics cards, such as the Nvidia GeForce RTX 4070 or more powerful ones, the 1 x 600W 12VHPWR plug. Lower-level graphics cards (for example, RTX 4060) will suffice with a standard 8-pin connector.
The color of the block is Melna. The block has flat cables, whose color is Melna.
This power supply is assigned the ATX 3.0 standard. This means that the unit has a 16-pin (12VHPWR) connector, providing up to 600W of power for the newest generation (RTX 30 and 40 series) PCIe 5.0 graphics cards. Additionally, the ATX 3.0 standard supports a 200% power increase for 1 millisecond to ensure more stable power for the components.
Thanks to the fact that this power supply has modular cables, you can add hard drives, video cards, and other components as needed, using the various cables included in the package. This way, there are fewer wires in the computer, which improves ventilation and appearance (especially useful for those who choose a partially transparent case).
Basic information
Cybenetics Efficiency certification
: Nav
Cybenetics Noise level certification
: Nav
Power supply type
: ATX
Power output
1000W
The capacity of the power supply unit in watts. A higher capacity means higher stability of the computer operation. The recommended capacity of the power supply unit of a modern average computer is 500 W and above. If you use several HDDs, a powerful video card and processor it is recommended to buy a power supply unit with the capacity 600 W or above.
80 PLUS certification
: 80 PLUS Gold
Total amperage (+12V)
: 83A
Fan size
: 120 mm
Functionality
Cable colour
: Melna
Lighting
: Nav
Color
: Melna
Modular cables
: Fully-Modular
Ports and equipment
PCI-E 5.0/5.1
: 1 x 600W 12V-2X6 (5.1)
Processor plug-in
: 2 x 8-pin(4+4) EPS
Motherboard power
: 20+4pin
PCI-E
: 3 x 6+2pin
SATA cconnectors
: 10
4pin Molex
: 1
More detailed specification
80 PLUS certification Performance - 80 PLUS Gold
AC input frequency Power - 50/60 Hz
AC input voltage Power - 100 - 240 V
Bearing technology Performance - FDB
Cabling type Ports & interfaces - Fully-Modular
category - PC Components|Power Supplies|PSUs above 800 Watts
Category 1 - Netzteile
Category Code - PSU
Category_1 - Power
Category_2 - Computer Power Supplies
code - FOCUS-GX-1000-V4
Combined power (+3.3V) Power - 125 W
Combined power (+5V) Power - 125 W
Combined power (+5Vsb) Power - 15 W
Combined power (+12V) Power - 996 W
Combined power (-12V) Power - 3.6 W
Compliance certificates Certificates - CB/CE/cTUVus/EAC/REACH/RoHS/WEEE
Cooling type Design - Active
CPU power cable length Ports & interfaces - 700 mm
CPU power connector (4+4 pin) Ports & interfaces - Yes
Depth Weight & dimensions - 140 mm
Description - FOCUS GX ATX 3.0 Following the well-established legacy of the Seasonic FOCUS Series, the FOCUS GX Series was upgraded to comply with the ATX 3.0 and PCIe 5.0 standards. Offering a complete range of power supplies ranging from 750 W to 1000 W with in a 140 mm depth, these units will be the perfect allies to power the newest high power graphics cards and processors on the market. Digital Hybrid Fan Control
The industry’s first, Seasonic patented, advanced three-phased thermal control achieves optimal between silence and cooling. This Digital Hybrid Fan Control functions in three operational stages: Fanless Mode, Silent Mode, and Cooling Mode. Reduced noise without increase in temperature Extended fan life due to the reduced number of fan rotations Optimized heat dissipation at all times
Unsurpassed silent performance in Fanless Mode Fluid Dynamic Fan Bearing
High performance Fluid Dynamic Bearing (FDB) fans are designed to take advantage of the impact absorbance effects of oil. They are extremely reliable and generate considerably less operating noise and heat than ball bearing fans. The lubrication of the bearing surface reduces friction and vibration and therefore lowers overall power consumption. Due to the effortless, quieter rotations and its robust construction, this reliable fan technology also greatly increases the lifespan of the fan. When the fan shaft rotates, high pressure oil drifts along the grooves of the bearing sleeve to generate a thin layer of lubrication between the bearing faces.
As the speed increases, so does dynamic oil pressure and the shaft is lifted from the bearing to create smooth, effortless rotations. The herringbone shape of the groves helps to efficiently channel the lubricant and avert leakage.
80 PLUS® GOLDFully ModularATX 3.0 & PCIe 5.0
ean - 4711173878421
EAN - 4711173878421
EAN_code - 4711173878421
Fan diameter Design - 135 mm
Height Weight & dimensions - 86 mm
Input current Power - 13 - 6.5 A
Manufacturer - Seasonic
Manufacturer - Sea Sonic
Manufacturer_code - FOCUS-GX-1000-V4
Maximum input current (@110V) Power - 13 A
Maximum input current (@220V) Power - 6.5 A
Max output current (+3.3V) Power - 25 A
Max output current (+5V) Power - 25 A
Max output current (+5Vsb) Power - 3 A
Max output current (+12V) Power - 83 A
Max output current (-12V) Power - 0.3 A
Mean time between failures (MTBF) Performance - 100000 h
Model name - FOCUS GX ATX 3.0
Motherboard power cable length Ports & interfaces - 610 mm
Motherboard power connector Ports & interfaces - 20+4 pin ATX
MPN - FOCUS-GX-1000-V4
Name - 1000W Seasonic Focus-GX-1000 ATX 3.1 80+ Gold
Name - Seasonic FOCUS GX-1000-V4 1000W ATX3.1, PC power supply (black, 1x 12-pin high power GPU, 3x PCIe, cable management, 1000 watts)
name - Seasonic Focus GX 80 PLUS Gold Netzteil, modular - 1000 Watt, schwarz
Number of fans Design - 1 fan(s)
Number of SATA power connectors Ports & interfaces - 2
On/off switch Design - Yes
Operating temperature (T-T) Operational conditions - 0 - 50 °C
Package type Packaging data - Box
PCI Express power connectors (6+2 pin) Ports & interfaces - 3
PCI Express power connectors (12+4 pin) Ports & interfaces - 1
Peripheral (Molex) power cable length Ports & interfaces - 690 mm
Peripheral (Molex) power connectors (4-pin) Ports & interfaces - 3
Power protection features Power - Over current/Over power/Over voltage/Overheating/Short circuit/Under voltage
Power supply unit (PSU) form factor Performance - ATX
Product colour Design - Black
Purpose Performance - PC
Safety Safety regulation & standards - cTUVus, TUV, CB, CCC, BSMI, EAC, CE
SATA power cable length Ports & interfaces - 550 mm
Summary - Seasonic Focus GX ATX 3.0. Total power: 1000 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 61 cm, SATA power cable length: 550 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Cooling type: Active, Fan diameter: 13.5 cm. Compliance certificates: CB, CE, EAC, REACH, RoHS, WEEE, cTUVus
Sustainability certificates Technical details - ENERGY STAR
Total power Power - 1000 W
Unit Box Height - 0.335
Unit Box Length - 0.6
Unit Box Width - 0.04
Unit Calculated Volume - 0.00804 cubm
Unit Calculated Weight - 3.62 kg
Units per Shipping Box - 5
Vendor Homepage - https://seasonic.com/atx3-focus-gx/
Warranty - 120 months
Warranty period Logistics data - 10 year(s)
Weight - 3,40
Weight - 3.438
Width Weight & dimensions - 150 mm
AC input frequency Power - 50/60 Hz
AC input voltage Power - 100 - 240 V
Bearing technology Performance - FDB
Cabling type Ports & interfaces - Fully-Modular
category - PC Components|Power Supplies|PSUs above 800 Watts
Category 1 - Netzteile
Category Code - PSU
Category_1 - Power
Category_2 - Computer Power Supplies
code - FOCUS-GX-1000-V4
Combined power (+3.3V) Power - 125 W
Combined power (+5V) Power - 125 W
Combined power (+5Vsb) Power - 15 W
Combined power (+12V) Power - 996 W
Combined power (-12V) Power - 3.6 W
Compliance certificates Certificates - CB/CE/cTUVus/EAC/REACH/RoHS/WEEE
Cooling type Design - Active
CPU power cable length Ports & interfaces - 700 mm
CPU power connector (4+4 pin) Ports & interfaces - Yes
Depth Weight & dimensions - 140 mm
Description - FOCUS GX ATX 3.0 Following the well-established legacy of the Seasonic FOCUS Series, the FOCUS GX Series was upgraded to comply with the ATX 3.0 and PCIe 5.0 standards. Offering a complete range of power supplies ranging from 750 W to 1000 W with in a 140 mm depth, these units will be the perfect allies to power the newest high power graphics cards and processors on the market. Digital Hybrid Fan Control
The industry’s first, Seasonic patented, advanced three-phased thermal control achieves optimal between silence and cooling. This Digital Hybrid Fan Control functions in three operational stages: Fanless Mode, Silent Mode, and Cooling Mode. Reduced noise without increase in temperature Extended fan life due to the reduced number of fan rotations Optimized heat dissipation at all times
Unsurpassed silent performance in Fanless Mode Fluid Dynamic Fan Bearing
High performance Fluid Dynamic Bearing (FDB) fans are designed to take advantage of the impact absorbance effects of oil. They are extremely reliable and generate considerably less operating noise and heat than ball bearing fans. The lubrication of the bearing surface reduces friction and vibration and therefore lowers overall power consumption. Due to the effortless, quieter rotations and its robust construction, this reliable fan technology also greatly increases the lifespan of the fan. When the fan shaft rotates, high pressure oil drifts along the grooves of the bearing sleeve to generate a thin layer of lubrication between the bearing faces.
As the speed increases, so does dynamic oil pressure and the shaft is lifted from the bearing to create smooth, effortless rotations. The herringbone shape of the groves helps to efficiently channel the lubricant and avert leakage.
80 PLUS® GOLDFully ModularATX 3.0 & PCIe 5.0
ean - 4711173878421
EAN - 4711173878421
EAN_code - 4711173878421
Fan diameter Design - 135 mm
Height Weight & dimensions - 86 mm
Input current Power - 13 - 6.5 A
Manufacturer - Seasonic
Manufacturer - Sea Sonic
Manufacturer_code - FOCUS-GX-1000-V4
Maximum input current (@110V) Power - 13 A
Maximum input current (@220V) Power - 6.5 A
Max output current (+3.3V) Power - 25 A
Max output current (+5V) Power - 25 A
Max output current (+5Vsb) Power - 3 A
Max output current (+12V) Power - 83 A
Max output current (-12V) Power - 0.3 A
Mean time between failures (MTBF) Performance - 100000 h
Model name - FOCUS GX ATX 3.0
Motherboard power cable length Ports & interfaces - 610 mm
Motherboard power connector Ports & interfaces - 20+4 pin ATX
MPN - FOCUS-GX-1000-V4
Name - 1000W Seasonic Focus-GX-1000 ATX 3.1 80+ Gold
Name - Seasonic FOCUS GX-1000-V4 1000W ATX3.1, PC power supply (black, 1x 12-pin high power GPU, 3x PCIe, cable management, 1000 watts)
name - Seasonic Focus GX 80 PLUS Gold Netzteil, modular - 1000 Watt, schwarz
Number of fans Design - 1 fan(s)
Number of SATA power connectors Ports & interfaces - 2
On/off switch Design - Yes
Operating temperature (T-T) Operational conditions - 0 - 50 °C
Package type Packaging data - Box
PCI Express power connectors (6+2 pin) Ports & interfaces - 3
PCI Express power connectors (12+4 pin) Ports & interfaces - 1
Peripheral (Molex) power cable length Ports & interfaces - 690 mm
Peripheral (Molex) power connectors (4-pin) Ports & interfaces - 3
Power protection features Power - Over current/Over power/Over voltage/Overheating/Short circuit/Under voltage
Power supply unit (PSU) form factor Performance - ATX
Product colour Design - Black
Purpose Performance - PC
Safety Safety regulation & standards - cTUVus, TUV, CB, CCC, BSMI, EAC, CE
SATA power cable length Ports & interfaces - 550 mm
Summary - Seasonic Focus GX ATX 3.0. Total power: 1000 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 61 cm, SATA power cable length: 550 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Cooling type: Active, Fan diameter: 13.5 cm. Compliance certificates: CB, CE, EAC, REACH, RoHS, WEEE, cTUVus
Sustainability certificates Technical details - ENERGY STAR
Total power Power - 1000 W
Unit Box Height - 0.335
Unit Box Length - 0.6
Unit Box Width - 0.04
Unit Calculated Volume - 0.00804 cubm
Unit Calculated Weight - 3.62 kg
Units per Shipping Box - 5
Vendor Homepage - https://seasonic.com/atx3-focus-gx/
Warranty - 120 months
Warranty period Logistics data - 10 year(s)
Weight - 3,40
Weight - 3.438
Width Weight & dimensions - 150 mm
