MikroTik RB4011iGS+5HacQ2HnD-IN

Accessories included -
Antenna - Fixed external
Antenna - Antenna design - External
Antenna - Antennas quantity - 4
Antenna design Antenna - External
Antenna gain - 3 dBi
Antennas quantity Antenna - 4
brand - MikroTik
Built-in processor Features - Yes
category - MikroTik > Wi-Fi mājai un ofisam > RouterBoard
Category Code - WRO
Code - RB4011iGS+5HacQ2HnD-IN
Color - Black
DC-in jack Ports & interfaces - Yes
Depth Weight & dimensions - 120 mm
Description - RB4011 series - amazingly powerful routers with ten Gigabit ports, SFP+ 10Gbps interface and IPsec hardware acceleration for a great price! The RB4011 uses a quad core Cortex A15 CPU, same as in our carrier grade RB1100AHx4 unit. The unit is equipped with 1GB of RAM, can provide PoE output on port #10 and comes with a compact and professional looking solid metal enclosure in matte black. RB4011iGS+5HacQ2HnD-IN (WiFi model) is dual band, four chain unit with a supported data rate of up to 1733 Mbps in 5GHz. For legacy devices, the unit also has a dual chain 2GHz wireless card installed in miniPCI-e slot. We have two versions available. RB4011iGS+5HacQ2HnD-IN-US (USA) is factory locked for 2412-2462MHz, 5170-5250MHz and 5725-5835MHz frequencies. This lock can not be removed. RB4011iGS+5HacQ2HnD-IN (International) supports 2412-2484MHz and 5150MHz-5875MHz range (Specific frequency range can be limited by country regulations).Powerful 10xGigabit port router with a Quad-core 1.4Ghz CPU1GB RAM, SFP+ 10Gbps cage, dual band 2.4GHz / 5GHz 4x4MIMO 802.11a/b/g/n/ac wireless and desktop case
Description - Seria RB4011 niesamowicie wydajne routery z dziesięcioma portami Gigabit, interfejsem SFP+ 10Gbps i akceleracją sprzętową IPsec.
RB4011 wykorzystuje czterordzeniowy procesor Cortex A15, taki sam jak w naszej jednostce RB1100AHx4 klasy operatorskiej. Urządzenie jest wyposażone w 1 GB pamięci RAM, może zapewnić wyjście PoE na porcie #10 i jest wyposażone w kompaktową i profesjonalnie wyglądającą solidną metalową obudowę w matowej czerni.
RB4011iGS+5HacQ2HnD-IN (model WiFi) to dwuzakresowa, czterołańcuchowa jednostka z obsługiwaną szybkością transmisji danych do 1733 Mb/s w 5 GHz. W przypadku starszych urządzeń jednostka ma również kartę bezprzewodową z podwójnym łańcuchem 2 GHz zainstalowaną w gnieździe miniPCI-e.
Obsługuje zakresy 2412-2484 MHz i 5150 MHz-5875 MHz (Określony zakres częstotliwości może być ograniczony przepisami krajowymi). Uwaga: pasywny przetwornik cyfrowo-analogowy (MikroTik S+DA0001/S+DA0003) nie jest obsługiwany.
Design - Product colour - Black
Design - Product type - Tabletop router
Designation - CE+WEEE
dimensionalWeight - 1020
dimension depth - 70 mm
dimension height - 280 mm
Dimensions - 228 x 120 x 30 mm
dimension weight - 1500 g
dimension width - 270 mm
EAN - 4752224002693
ean - 4752224002693
Ethernet LAN data rates Network - 10,100,1000 Mbit/s
Ethernet LAN interface type Network - Gigabit Ethernet
Ethernet LAN Network - Yes
Features - Built-in processor - Yes
Features - Processor cores - 4
Features - Processor frequency - 1400 MHz
Features - Processor model - Annapurna Labs Alpine AL21400
Features > Mesh Support - No
Features > Mobile Broadband - No mobile broadband
Features > MU-MiMO - Yes
Gross weight - 1.49 kg
guarantee - 12
guarantee_type - normal
height - 0.27 m
Height Weight & dimensions - 30 mm
I/O ports - 1 x 10Gbit SFP/SFP+
I/O ports - 1 x Serial port (RJ-45 )
I/O ports - 10 x 10/100/1000 Mbit/s
length - 0.27 m
Management, monitoring, configuration -
Model - RB4011iGS+5HacQ2HnD-IN
Model name - RB4011iGS+5HacQ2HnD-IN
mpn - RB4011iGS+5HacQ2HnD-IN
Name - MikroTik | RB4011iGS+5HacQ2HnD-IN | 802.11ac | 10/100/1000 Mbit/s | Ethernet LAN (RJ-45) ports 10 | Mesh Support No | MU-MiMO Yes | No mobile broadband
name - Router AC xDSL RB4011iGS+5HacQ2HnD-IN
Network - Ethernet LAN - Yes
Network - Ethernet LAN (RJ-45) ports - 10
Network - Ethernet LAN data rates - 10
Network - Ethernet LAN data rates - 100
Network - Ethernet LAN data rates - 1000
Network - Ethernet LAN interface type - Gigabit Ethernet
Network - SFP+ module slots quantity - 1
Network architecture - GigabitEthernet
Number of antennas - 4
Operating frequency - 2,4 GHz
Operating frequency - 5 GHz
Other features - Architektura: 32-bitowe ARM Procesor: AL21400 Liczba rdzeni procesora: 4 Częstotliwość nominalna procesora: 1,4 GHz Licencja RouterOS: 5 System operacyjny: RouterOS Rozmiar pamięci RAM: 1 GB Rozmiar pamięci: 512 MB Typ pamięci: NAND MTBF: około 200 000 godzin w 25C Testowana temperatura otoczenia: -40°C do 45°C Przyspieszenie sprzętowe IPsec: Tak
Other features > Ethernet LAN (RJ-45) ports - 10
Output current Power - 0.6 A
Output voltage Power - 57 V
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 270 mm
Package features > Gross height (mm) - 270 mm
Package features > Gross width (mm) - 70 mm
Package features > Packing quantity - 1 pc(s)
Package features > Palette Qty - 169 pc(s)
Package features > Tare weight (kg) - 0.13 kg
Package features > TI weight (kg) - 0 kg
Package features > Volume (m3) - 0.005103 m³
Performance > Ethernet LAN data rates - 10/100/1000 Mbit/s
Ports & interfaces - DC-in jack - Yes
Ports & interfaces > SFP+ ports quantity - 1
Power - Output voltage - 12 - 57 V
Power - Power consumption (max) - 44 W
Power - Power consumption (typical) - 23 W
Power - Power over Ethernet (PoE) - Yes
Power - Power source type - DC
Power consumption (typical) Power - 26 W
Power over Ethernet (PoE) Power - Yes
Power source type Power - DC
Power supply - Liczba wejść DC: 2 (gniazdo DC, PoE-IN) Napięcie wejściowe gniazda DC: 12-57 V Maksymalny pobór mocy: 44 W Maksymalny pobór mocy bez załączników: 23 W FAN count: Passive PoE in Passive PoE Napięcie wejściowe PoE: 18-57 V
Processor cores Features - 4
Processor frequency Features - 1400 MHz
Processor model Features - Annapurna Labs Alpine AL21400
producer - Mikrotik
producerCode - RB4011iGS+5HacQ2HnD-IN
Producer product name - RB4011iGS+5HacQ2HnD-IN
Product colour Design - Black
productName - Mikrotik RB4011iGS+5HacQ2HnD-IN wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) Black
productSize - Normal
Product type Design - Tabletop router
Safety warning - Warnings - Do not open the appliance - risk of electric shock.
Safety warning - Warnings - Do not use in damp conditions.
Security -
sizeX - 270
sizeY - 270
sizeZ - 70
Software -
Special functions -
Standards - 802.11a
Standards - 802.11ac
Standards - 802.11n
Summary - Mikrotik RB4011iGS+5HacQ2HnD-IN. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), Top Wi-Fi standard: Wi-Fi 5 (802.11ac), WLAN data transfer rate (max): 1733 Mbit/s. Ethernet LAN interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s. Product type: Tabletop router, Product colour: Black. Antenna design: External. Processor model: Annapurna Labs Alpine AL21400, Processor frequency: 1400 MHz
System Requirements -
Technical details > Net weight - 1.36 kg
Technical details > Producer - MikroTik
Technical details > Software type - RouterOS (level 5)
title - MikroTik RB4011iGS+5HacQ2HnD-IN
Top Wi-Fi standard Wireless LAN features - Wi-Fi 5 (802.11ac)
Type - xDSL
Unit Box Height - 0.07
Unit Box Length - 0.27
Unit Box Width - 0.27
Unit Calculated Volume - 0.006479 cubm
Unit Calculated Weight - 1.45 kg
Units per Pallet - 0
Units per Shipping Box - 10
Vendor Homepage - https://mikrotik.com/product/rb4011igs_5hacq2hnd_in#fndtn-specifications
vendpn - RB4011iGS+5HacQ2HnD-IN
Warranty - 12
Warranty - 12 month(s)
Warranty - 12 months
warrantyLength - 12
warrantyType - G
weight - 1.5 kg
weight - 1350
Weight & dimensions - Depth - 120 mm
Weight & dimensions - Height - 30 mm
Weight & dimensions - Width - 228 mm
Wi-Fi band Wireless LAN features - Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards Wireless LAN features - 802.11a, Wi-Fi 5 (802.11ac), 802.11ad, 802.11g, Wi-Fi 4 (802.11n)
width - 0.09 m
Width Weight & dimensions - 228 mm
Wireless LAN features - Top Wi-Fi standard - Wi-Fi 5 (802.11ac)
Wireless LAN features - Wi-Fi band - Dual-band (2.4 GHz / 5 GHz)
Wireless LAN features - Wi-Fi standards - 802.11a
Wireless LAN features - Wi-Fi standards - 802.11b
Wireless LAN features - Wi-Fi standards - 802.11g
Wireless LAN features - Wi-Fi standards - Wi-Fi 4 (802.11n)
Wireless LAN features - Wi-Fi standards - Wi-Fi 5 (802.11ac)
Wireless LAN features - WLAN data transfer rate (max) - 1733 Mbit/s
Wireless LAN features > Wi-Fi band - 802.11ac
WLAN data transfer rate (max) Wireless LAN features - 1733 Mbit/s
