2.4 GHz Features - Yes
5 GHz Features - Yes
6 GHz Features - No
Accessories included - EAP650 D120-Outdoor Zestaw montażowy Instrukcja instalacji
AC input voltage Power - 48 V
Airtime Fairness (ATF) Features - Yes
Antenna - Built-in
Antenna - Antenna type - Internal
Antenna gain - 5 dBi
Antenna type Antenna - Internal
ARTIKEL1 - AX3000 OUTDOOR WI-FI 6 AP
ARTIKEL2 - DUAL-BAND
Automatic channel selection Features - Yes
Band steering Features - Yes
Bluetooth Features - Yes
Brand - TP-Link
BrandPartCode - EAP650 D120-OUTDOOR
Breite - 0
Category - Wireless Access Points
Category Code - WAP
Certificates - CE, FCC, RoHS
Color - White
Depth Weight & dimensions - 207.5 mm
Description - AX3000 Indoor/Outdoor Wi-Fi 6 Access Point Superb Wi-Fi 6 speeds: Up to 2402 Mbps on the 5 GHz band and up to 574 Mbps on the 2.4 GHz band. Wide, directional coverage: Built-in high-gain directional antennas ensure precise and long signal coverage. Ideal for warehouses and outdoor applications: IP68 rating and operating temperature range from -30°C to +70°C. Seamless 802.11k/v/r roaming: Ensures uninterrupted connections for AGVs and handheld scanners. Flexible deployment: Supports 802.3at PoE and Omada Mesh technology. Centralized cloud management: Control everything from a single interface using the Omada app or web interface.
Description - Omada AX3000
Indoor/Outdoor WiFi 6
Access Point Designed for Warehouses
The EAP650 D120-Outdoor features a durable, fully sealed IP68 weatherproof enclosure, making it dustproof and capable of withstanding submersion in water. It is ideal for warehouse environments. Elevate WiFi Experience for Shelf Areas with Directional Antennas
Equipped with 4× built-in dual-band directional antennas with high gain to ensure the optimal WiFi experience ideal for precise and extended coverage. Stay Smooth with Seamless Roaming
Ensure users enjoy uninterrupted steaming when moving around by switching clients automatically to the access points with the optimal signals.Superior WiFi 6 Speeds: 2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHzDirectional Ultra-Range Coverage: Equipped with built-in high-gain directional antennas to deliver precise and extended coverageIdeal for Warehouses and Outdoor Scenes: Features an IP68 waterproof enclosure with -30°C to +70°C operating range802.11k/v/r Seamless Roaming: Ensures uninterrupted connectivity for AGVs and handheld scannersFlexible Deployment: Supports 802.3at PoE and Omada Mesh technologyCentralized Cloud Management: Control everything from a single interface anywhere via the Omada app or Web UI
Design - Placement - Ceiling, Wall
Design - Product colour - White
Designation - CE+WEEE
dimension depth - 85 mm
dimension height - 255 mm
Dimensions - 207,5 × 58 × 230 mm
dimension weight - 2120 g
dimension width - 360 mm
ean - 8885020625066
EAN - 8885020625066
EANCode - 8885020625066
Environment requirements - Permissible operating temperature: -30-70 degrees Permissible storage temperature: -40-70 degrees Permissible air humidity: 10%-90%, non-condensing Permissible storage humidity: 5%-90%, non-condensing
Ethernet LAN (RJ-45) ports Ports & interfaces - 1
Ethernet LAN data rates Features - 10,100,1000 Mbit/s
Features - 2.4 GHz - Yes
Features - 5 GHz - Yes
Features - 6 GHz - No
Features - Airtime Fairness (ATF) - Yes
Features - Automatic channel selection - Yes
Features - Band steering - Yes
Features - Bluetooth - Yes
Features - Ethernet LAN data rates - 10,100,1000 Mbit/s
Features - Maximum data transfer rate - 3000 Mbit/s
Features - Maximum data transfer rate (2.4 GHz) - 574 Mbit/s
Features - Maximum data transfer rate (5 GHz) - 2402 Mbit/s
Features - Maximum indoor range - 500 m
Features - MIMO - Yes
Features - MIMO type - Multi User MIMO
Features - Networking standards - IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Gewicht - 2.11
Gross Weight Kg - 2,4
GRUPPE1 - Network
GRUPPE2 - Wireless Lan Ap
GTIN - 0810142822770
GTIN - 810142822770
GTIN - 1210002612722
GTIN - 8885020625066
guarantee - 60
guarantee_type - normal
Height Weight & dimensions - 69.7 mm
HERSTELLER - TP-LINK
Hoehe - 0
Horizontal beam width Other features - 120°
HSTNUMMER - EAP650 D120-OUTDOOR
I/O ports - 1 x 10/100/1000 Mbit/s PoE
Laenge - 0
LongDesc - Omada AX3000Indoor/Outdoor WiFi 6Access PointDesigned for WarehousesThe EAP650 D120-Outdoor features a durable, fully sealed IP68 weatherproof enclosure, making it dustproof and capable of withstanding submersion in water. It is ideal for warehouse environments.Elevate WiFi Experience for Shelf Areas with Directional AntennasEquipped with 4× built-in dual-band directional antennas with high gain to ensure the optimal WiFi experience ideal for precise and extended coverage.Stay Smooth with Seamless RoamingEnsure users enjoy uninterrupted steaming when moving around by switching clients automatically to the access points with the optimal signals.
LongProductName - 574 Mbps (2.4 GHz) + 2402 Mbps (5 GHz), 802.3at PoE, 1x Gigabit Ethernet, IP68, 230 x 207.5 x 69.7 mm
LongSummaryDescription - TP-Link Omada AX3000 Indoor/Outdoor WiFi 6 Access Point. 2.4 GHz, 5 GHz, Maximum data transfer rate: 3000 Mbit/s. Security algorithms: SNMP, SNMPv2, SNMPv3. Ethernet LAN data rates: 10,100,1000 Mbit/s. Power over Ethernet (PoE). Product colour: White
MAC address filtering Security - Yes
Management, monitoring, configuration - Aplikacja Omada Kopia i przywracanie ustawień NTP Dostęp do chmury: Tak. Wymaga użycia Kontrolera Omada. Powiadomienia e-mail Wyłącznik diod Kontrola dostępu po adresach MAC SNMP: v1, v2c, v3 Dziennik systemowy SSH Zarządzanie przez przeglądarkę Zarządzanie wieloma lokacjami Bezobsługowa konfiguracja ZTP: Tak. Wymaga użycia Kontrolera Omada opartego na Chmurze. Scentralizowane zarządzanie: Kontroler sprzętowy Omada Kontroler programowy Omada Kontroler Omada oparty na Chmurze Aplikacja Omada
Management features - Web-based management - Yes
Manufacturer Code - EAP650 D120-OUTDOOR
Manufacturer Name - TP-LINK
Maximum data transfer rate (2.4 GHz) Features - 574 Mbit/s
Maximum data transfer rate (5 GHz) Features - 2402 Mbit/s
Maximum data transfer rate Features - 3000 Mbit/s
Maximum indoor range Features - 500 m
MIMO Features - Yes
MIMO type Features - Multi User MIMO
Model name - EAP650 D120-OUTDOOR
Mounting kit Packaging content - Yes
name - TP-Link EAP650 D120-Outdoor
Network architecture - GigabitEthernet
Networking standards Features - IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Number of antennas - 2
Operating frequency - 2,4 GHz
Operating frequency - 5 GHz
Other features - Horizontal beam width - 120°
Other features - Vertical beam width - 30°
Packaging content - Mounting kit - Yes
Packaging content - Quantity per pack - 1 pc(s)
Packaging content - Quick start guide - Yes
Placement Design - Ceiling, Wall
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Power - AC input voltage - 48 V
Power - Power over Ethernet (PoE) - Yes
Power - Power over Ethernet (PoE) type supported - Passive PoE
Power over Ethernet (PoE) Power - Yes
Power over Ethernet (PoE) type supported Power - Passive PoE
Power supply - PoE 802.3at Passive PoE 48V
producer - TP-LINK
Product colour Design - White
ProductName - AX3000 Indoor/Outdoor WiFi 6 Access Point
Quantity per pack Packaging content - 1 pc(s)
Quick start guide Packaging content - Yes
Remote Authentication Dial-In User Service (RADIUS) Security - Yes
Security - Bezpieczeństwo transmisji bezprzewodowej: Uwierzytelnianie przy pomocy strony powitalnej§ Kontrola dostępu Filtrowanie bezprzewodowych adresów MAC Izolacja klientów sieci bezprzewodowej Mapowanie SSID do VLAN Wykrywanie nieautoryzowanych AP Obsługa 802.1X Szyfrowanie WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
Security - MAC address filtering - Yes
Security - Remote Authentication Dial-In User Service (RADIUS) - Yes
Security - Security algorithms - SNMP, SNMPv2, SNMPv3
Security algorithms Security - SNMP, SNMPv2, SNMPv3
Series - Omada
Short description - TP-LINK WLAN AX3000 Access Point Dualband EAP650 D120-Outdoor
ShortSummaryDescription - TP-Link Omada AX3000 Indoor/Outdoor WiFi 6 Access Point, 2.4 GHz, 5 GHz, 3000 Mbit/s, SNMP, SNMPv2, SNMPv3, 10,100,1000 Mbit/s
Special functions - Wireless Features: 1024-QAM DL/UL OFDMA Multi-SSID (up to 16 SSIDs, 8 for each band) Wireless On/Off SSID Broadcast On/Off Guest Network Automatic Channel Selection Transmit Power Control (dBm-based) QoS (WMM) 2x2 (2.4 GHz and 5 GHz) DL/UL MU-MIMO Omada Mesh§ Seamless Roaming (802.11k/v/r)§ Band Steering Load Balancing Airtime Fairness Beamforming DIUS Accounting MAC Authentication Reboot Scheduler Wireless Scheduler Wireless Statistics Static IP/Dynamic IP
Standards - 802.11a
Standards - 802.11ac
Standards - 802.11ax
Standards - 802.11b
Standards - 802.11g
Standards - 802.11n
Stck_Kart - 9998
Stck_Pal - 0
Storno - Y
Summary - TP-Link Omada AX3000 Indoor/Outdoor WiFi 6 Access Point. 2.4 GHz, 5 GHz, Maximum data transfer rate: 3000 Mbit/s. Security algorithms: SNMP, SNMPv2, SNMPv3. Ethernet LAN data rates: 10,100,1000 Mbit/s. Power over Ethernet (PoE). Product colour: White
System Requirements - Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows 10, Windows 11, Linux
Title - TP-Link Omada AX3000 Indoor/Outdoor WiFi 6 Access Point
Unit Box Height - 0.085
Unit Box Length - 0.355
Unit Box Width - 0.255
Unit Calculated Volume - 0.007695 cubm
Unit Calculated Weight - 2.1 kg
Units per Pallet - 0
Units per Shipping Box - 1
URL - https://www.omadanetworks.com/my/business-networking/omada-wifi-outdoor/eap650-d120-outdoor/
Vendor Homepage - https://www.omadanetworks.com/my/business-networking/omada-wifi-outdoor/eap650-d120-outdoor/
vendpn - EAP650 D120-Outdoor
Vertical beam width Other features - 30°
Warranty - 60 months
WarrantyInfo -
Web-based management Management features - Yes
Weight & dimensions - Depth - 207.5 mm
Weight & dimensions - Height - 69.7 mm
Weight & dimensions - Width - 230 mm
Width Weight & dimensions - 230 mm
