Arctic P14 Pro PST CO, Black

Airflow Performance - 186 m³/h
Bearing type Performance - Dual ball bearing
Brand - ARCTIC
BrandPartCode - ACFAN00316A
Cable length Weight & dimensions - 0.48 m
category - Aircooling|Fans|By Size|140mm PC Fans
Category - Computer Cooling Systems
Category - Datortehnika :: Datoru komponentes :: Korpusa ventilatori
Category 1 - Gehäuse
Category 2 - Gehäuselüfter
Category Code - COS
category_en - Computers & Components > Computer components > Cooling systems
category_lv - Datortehnika > Datoru komponentes > Dzesēšanas sistēmas
category_ru - Datortehnika > Datoru komponentes > Dzesēšanas sistēmas
Code - ACFAN00316A
code - ACFAN00316A
Desc - Ligdza (socket): 4-pin, Diametrs: 140 mm, Ventilators ātrums (apgr.min.): 2500 apgr.min., Apgaismojums: Nav, Skaits komplektācijā: 1, Garantija: 2 gadi
description_en - The ARCTIC P14 Pro PST CO 140mm (ACFAN00316A) is engineered for continuous operation, offering superior cooling efficiency and long-lasting performance. Designed with double ball bearings, this fan ensures durability and reliable functionality even under constant 24/7 use. The PWM PST (PWM Sharing Technology) enables synchronized speed control across multiple fans for optimal airflow management. Its optimized static pressure blades make it ideal for radiators and cases with high airflow resistance.
Technical Specifications: Model: P14 Pro PST CO (ACFAN00316A) Fan Size: 140 × 140 × 27 mm Fan Speed: 200 – 1900 RPM (PWM controlled) Airflow: up to 109 CFM Static Pressure: 2.4 mmH₂O Bearing Type: Double Ball Bearing (for continuous operation) Noise Level: ~28 dBA Connector: 4-pin PWM Voltage: 12V DC Power Consumption: 2.16 W Lifespan: 150,000 hours Compatibility: Standard 140 mm fan mounts, PWM fan controllers Color: Black Included: 1 × P14 Pro PST CO fan, mounting screws
description_lv - ARCTIC P14 Pro PST CO 140mm (ACFAN00316A) ir augstas veiktspējas ventilators, paredzēts nepārtrauktai darbībai (Continuous Operation). Ar dubultajiem lodīšu gultņiem tas nodrošina izcilu izturību un uzticamību pat 24/7 darbības režīmā. PWM PST tehnoloģija ļauj sinhronizēt vairākus ventilatorus, bet statiskā spiediena lāpstiņas garantē lielisku dzesēšanu radiatoriem un korpusiem ar ierobežotu gaisa plūsmu.
Tehniskās īpašības: Modelis: P14 Pro PST CO (ACFAN00316A) Ventilatora izmērs: 140 × 140 × 27 mm Apgriezieni: 200–1900 RPM (PWM) Gaisa plūsma: līdz 109 CFM Statiskais spiediens: 2.4 mmH₂O Gultņu tips: Dubultie lodīšu gultņi (Continuous Operation) Trokšņa līmenis: ~28 dBA Savienojums: 4-pin PWM Spriegums: 12V DC Patēriņš: 2.16 W Kalpošanas laiks: 150 000 stundas Savietojamība: Standarta 140 mm stiprinājumi, PWM kontrolieri Krāsa: Melna Komplektācija: 1 ventilators, montāžas skrūves
description_ru - ARCTIC P14 Pro PST CO 140mm (ACFAN00316A) — это мощный вентилятор, созданный для непрерывной круглосуточной работы (Continuous Operation). Благодаря двойным шарикоподшипникам, он обеспечивает исключительную надёжность и долгий срок службы, даже при постоянных нагрузках. Технология PWM PST позволяет синхронизировать работу нескольких вентиляторов, а улучшенные лопасти обеспечивают высокий статический напор, идеально подходящий для радиаторов и корпусов с ограниченным воздушным потоком.
Технические характеристики: Модель: P14 Pro PST CO (ACFAN00316A) Размер вентилятора: 140 × 140 × 27 мм Скорость вращения: 200–1900 об/мин (PWM) Воздушный поток: до 109 CFM Статическое давление: 2.4 ммH₂O Тип подшипников: Двойные шариковые (для непрерывной работы) Уровень шума: ~28 дБА Разъём: 4-pin PWM Напряжение: 12V DC Потребляемая мощность: 2.16 Вт Ресурс работы: 150 000 часов Совместимость: Крепления 140 мм, PWM контроллеры Цвет: Чёрный Комплектация: 1 вентилятор, крепёжные винты
Design - Fan connector - 4-pin + 4-pin
Design - Product colour - Black
EAN - 4895265000409
ean - 4895265000409
Fan connector Design - 4-pin + 4-pin
Fan diameter Performance - 140 mm
Fan dimensions (W x D x H) Weight & dimensions - 140 x 140 x 27 mm
Fan weight Weight & dimensions - 242 g
gross_weight - 0.25 kg
GTIN - 0840033403078
GTIN - 840033403078
GTIN - 4895265000409
LargeDescHTML -
LongDesc -
LongProductName - P14 Pro PST CO 140 mm PWM Fan with Cable Splitter for Continuous Operation
LongSummaryDescription - ARCTIC P14 Pro PST CO 140 mm PWM Fan with Cable Splitter for Continuous Operation. Type: Fan, Fan diameter: 14 cm, Rotational speed (min): 400 RPM, Rotational speed (max): 2500 RPM, Airflow: 186 m³/h, Maximum air pressure: 5.2 mmH2O, Bearing type: Dual ball bearing. Product colour: Black
Manufacturer - ARCTIC
Maximum airflow Performance - 110 cfm
Maximum air pressure Performance - 5.2 mmH2O
Model -
Model - ACFAN00316A
Model name - P14 Pro PST CO
MPN - ACFAN00316A
Name - 140mm Arctic P14 Pro PST CO
name - ARCTIC P14 Pro PST CO PWM Lüfter - 140mm, schwarz
Name - Dzesētājs Arctic P14 Pro PST CO 140mm
Number of screws Packaging content - 4
Operating temperature (T-T) Performance - 0 - 40 °C
Package depth Weight & dimensions - 145 mm
Package height Weight & dimensions - 32 mm
Package weight Weight & dimensions - 294 g
Package width Weight & dimensions - 145 mm
Packaging content - Number of screws - 4
Packaging content - Screws included - Yes
Performance - Airflow - 186 m³/h
Performance - Bearing type - Dual ball bearing
Performance - Fan diameter - 14 cm
Performance - Maximum airflow - 110 cfm
Performance - Maximum air pressure - 5.2 mmH2O
Performance - Operating temperature (T-T) - 0 - 40 °C
Performance - Pulse-width modulation (PWM) support - Yes
Performance - Quantity per pack - 1 pc(s)
Performance - Rotational speed (max) - 2500 RPM
Performance - Rotational speed (min) - 400 RPM
Performance - Suitable location - Computer case
Performance - Type - Fan
Power - Rated current - 0.35 A
Power - Rated voltage - 12 V
Power - Starting voltage - 5 V
Producer - Arctic
Product colour Design - Black
ProductName - P14 Pro PST CO 140 mm PWM Fan with Cable Splitter for Continuous Operation
Pulse-width modulation (PWM) support Performance - Yes
Quantity per pack Performance - 1 pc(s)
Rated current Power - 0.35 A
Rated voltage Power - 12 V
Rotational speed (max) Performance - 2500 RPM
Rotational speed (min) Performance - 400 RPM
Screws included Packaging content - Yes
ShortSummaryDescription - ARCTIC P14 Pro PST CO 140 mm PWM Fan with Cable Splitter for Continuous Operation, Fan, 14 cm, 400 RPM, 2500 RPM, 186 m³/h, Black
Starting voltage Power - 5 V
Suitable location Performance - Computer case
Summary - ARCTIC P14 Pro PST CO 140 mm PWM Fan with Cable Splitter for Continuous Operation. Type: Fan, Fan diameter: 14 cm, Rotational speed (min): 400 RPM, Rotational speed (max): 2500 RPM, Airflow: 186 m³/h, Maximum air pressure: 5.2 mmH2O, Bearing type: Dual ball bearing. Product colour: Black
Title - ARCTIC P14 Pro PST CO 140 mm PWM Fan with Cable Splitter for Continuous Operation
title_en - Arctic P14 Pro Cooling fan 140mm
title_lv - Arctic P14 Pro Datora dzesētājs 140mm
title_ru - Arctic P14 Pro Вентилятор для ПК 140mm
Type Performance - Fan
Unit Box Height - 0.145
Unit Box Length - 0.148
Unit Box Width - 0.032
Unit Calculated Volume - 0.0008341 cubm
Unit Calculated Weight - 0.298 kg
Units per Pallet - 0
Units per Shipping Box - 48
URL - https://www.arctic.de/en/P14-Pro-PST-CO/ACFAN00316A
Vendor Homepage - https://www.arctic.de/en/P14-Pro-PST-CO/ACFAN00316A
Warranty - 24 months
WarrantyInfo - 6 Years
weight - 0.2 kg
Weight - 0.287
Weight & dimensions - Cable length - 0.48 m
Weight & dimensions - Fan dimensions (W x D x H) - 140 x 140 x 27 mm
Weight & dimensions - Fan weight - 242 g
Weight & dimensions - Package depth - 145 mm
Weight & dimensions - Package height - 32 mm
Weight & dimensions - Package weight - 294 g
Weight & dimensions - Package width - 145 mm
