Lanberg FF01-8227-12BL free-standing rack 19inch self-assembly flat pack 27U/800x1200mm black glass door LCD

Accessories included - Wheels with brake legs Ventilation Panel (4 fans) Vertical cable organizer x2 M6 screws Thermostat Front zipper Rear zipper Side zippers
Code - FF01-8227-12BL
Color - Black
Color - RAL 9004
Colour > Colour of product - Black
Description - The Lanberg FF01-8227-12BL single-section standing cabinet is a solution designed for network construction, cabling and equipment installation in 19-inch size with a maximum total load capacity of up to 800 kg. It can be used in data centers that require a large amount of space in equipment cabinets. The cabinet will successfully fulfill its role in large, extensive networks and server rooms, both in small, medium and large companies and corporations. It will also work well in low-voltage installations such as cable TV networks, alarm systems, fire protection systems, access control systems as well as CCTV and IP monitoring systems. The construction is made using high quality rolled steel, it is characterized by excellent design and workmanship. The cabinet enables full adjustment of the depth of the vertical mounting rails. It is equipped with a front door made of tempered glass with a lock, which can be mounted on the right or left side. It has removable side panels (with locks included) and a rear solid steel door with a lock. Grounding pins are located on the three cabinet components, bottom panel, front door, and rear door. It is possible to introduce wiring through the lockable upper and lower panels (with plugs in the set). The cabinet has an LCD display mounted on the front, displaying basic information (e.g. temperature inside the cabinet, current time and current status of fans) about the status of the device. The set includes a ventilation panel with 4 fans 230V, equipped with a thermostat. In addition, the set includes accessories for mounting the mounting rails, M6 screws and plugs for entry panels. Thanks to the construction for self-assembly (flat pack), the whole is in 4 flat packages, which facilitates transport.
Designation - CE+WEEE
dimension depth - 965 mm
dimension height - 510 mm
Dimensions - Cabinet dimensions (W x D x H): 800 x 1200 x 1438 mm Height (top panel - bottom panel): 1352 mm Height (upper panel - ground): 1425 mm Height (upper panel - ground including screws): 1431 mm Internal spacing width between rack rails: 450 mm The width of the spacing between the openings of the rack rails: 465 mm External width between rack rails: 500 mm Front door thickness: 5 mm Rear door thickness: 1.2 mm Top & bottom panel thickness: 1.2 mm Side panel thickness: 1.2 mm The thickness of the mounting rails: 2 mm Thickness of other elements: 1.2 mm
dimension weight - 142000 g
dimension width - 1270 mm
EAN - 5901969438017
ean - 5901969438017
Front door type - Glass
guarantee - 36
guarantee_type - normal
Height - 27U
LCD display - Yes
Link - https://lanberg.eu/product/rack-installation-rack-19-27u-800x1200-black-door-glass-lcd-lanberg-flat-pack
Load (max) - 800 kg
Name - Lanberg | Rack cabinet 19" free-standing 27U/800x1200 (flat pack) with glass door, LCD | FF01-8227-12BL | Black
name - Standing rack cabinet 19 inches 27U 800x1200 black LCD glass door FLAT PACK
Number of fan slots - 4
Number of vertical rails - 4
Other features - Standard: ANSI/EIA RS-310-D DIN 41491/PART 1 DIN 41494/PART 7 ETSI IEC297-2:1982
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 1200.00 mm
Package features > Gross height (mm) - 1354.00 mm
Package features > Gross width (mm) - 800.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 1 pc(s)
Package features > Paper/Pasteboard - 4600.00 g
Package features > Tare weight (kg) - 4.60 kg
Package features > Volume (m3) - 1.30 m³
Package features > WEEE tax - No
producer - Lanberg
Protection class - IP20
Stuff - Glass
Stuff - Metal
Stuff - Steel
Technical details > Gross weight - 126.60 kg
Technical details > Net weight - 122.00 kg
Technical details > Producer - Lanberg
Technical details > Producer product family - Rack cabinet 19" free-standing 27U/800x1200 (flat pack) with glass door, LCD
Technical details > Producer product name - FF01-8227-12BL
Type - Floor standing
vendpn - FF01-8227-12BL
Warranty - 36
Warranty - 36 month(s)
Weight - 122 kg
Width - 800 mm
