ARTIKEL1 - DS3678 RUGG AREA IMAG EXT RANGE
ARTIKEL2 - CORDLESS IND GREEN VIB MOTOR
Brand - Zebra
BrandPartCode - DS3678-ER2F003VZWW
Category - Barcode Readers
Category 1 - Drucker & Scanner
Category 2 - Scanner
EANCode - 5656565656562
GRUPPE1 - POS
GRUPPE2 - Handheld Barcode
GTIN - 5711783312208
GTIN - 8596375044906
HERSTELLER - ZEBRA
HSTNUMMER - DS3678-ER2F003VZWW
Logistics data - Harmonized System (HS) code - 84716070
LongDesc - UNSTOPPABLE PERFORMANCE FOR EXTENDED-RANGE 1D/2D BARCODE CAPTUREAs a member of the Zebra 3600 Ultra-Rugged Series of scanners, the practically indestructible 1D/2D DS3608-ER corded and DS3678-ER cordless scanners are ready for one of the world’s toughest environments — the warehouse. Designed to capture any 1D or 2D barcode from near contact to as far as 70 ft./ 21.4 m away, these scanners provide the ultimate in versatility — workers can capture large picklist codes and small codes at near contact as easily as barcodes on pallets and location codes on the top of your warehouse racks. And truly unstoppable performance helps you drive throughput, accuracy and customer service to a new level.SUPERIOR PERFORMANCEYou get the ultimate in scanning performance — period. Your workers can scan virtually any 1D or 2D barcode from near contact to as far as 70 ft./ 21.4 m away in practically any condition, as fast as they can pull the trigger. Even if barcodes are under shrinkwrap on a pallet; damaged, dirty or poorly printed; on a picklist; or on your highest warehouse rack, no problem — this intelligent scanner can handle it all.ULTRA-RUGGED DESIGNThe warehouse and manufacturing plant floor is as tough as its gets. That’s why we created a new product category — the ultra-rugged scanner. These freezer-ready corded and cordless models are the only scanners in this class that are dust-tight, sprayproof and waterproofed to IP67, with an IP65-sealed cradle for a complete rugged cordless solution.UNRIVALED MANAGEABILITYWith our complimentary industry-best tools, managing these scanners couldn’t be easier. You can remotely configure and upgrade your scanners, format data properly for instant transmission into your business applications, monitor battery statistics for your cordless models and more.
LongProductName - DS3678-ER, 1D/2D Imager, 655nm laser, 1280 x 800, One 660nm LED, Bluetooth 4.0 (LE)
LongSummaryDescription - Zebra DS3678-ER. Type: Handheld bar code reader, Scanner type: 1D/2D, Sensor type: Laser. Connectivity technology: Wired & Wireless, Standard interfaces: RS-232, USB, Keyboard wedge, Wireless range: 100 m. Product colour: Black, Green, International Protection (IP) code: IP67, Protection features: Dust resistant, Shock resistant, Water resistant. Power source type: Battery, Battery technology: Lithium-Ion (Li-Ion), Battery capacity: 3100 mAh. Weight: 436 g, Width: 142 mm, Depth: 76 mm
Manufacturer - Zebra
MPN - DS3678-ER2F003VZWW
Name - Zebra Barcode-Scanner DS3678-ER 1D/2D USB RS-232
Operational conditions - Operating relative humidity (H-H) - 5 - 95%
Operational conditions - Operating temperature (T-T) - -20 - 50 °C
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Performance - International Protection (IP) code - IP67
Performance - LED indicators - Yes
Performance - Product colour - Black, Green
Performance - Programming function - Yes
Performance - Protection features - Dust resistant, Shock resistant, Water resistant
Ports & interfaces - Bluetooth Low Energy (BLE) - Yes
Ports & interfaces - Bluetooth version - 4.0
Ports & interfaces - Connectivity technology - Wired & Wireless
Ports & interfaces - Ethernet LAN - Yes
Ports & interfaces - Standard interfaces - RS-232, USB, Keyboard wedge
Ports & interfaces - Wireless range - 100 m
Power - Battery capacity - 3100 mAh
Power - Battery technology - Lithium-Ion (Li-Ion)
Power - Number of reads per charge - 70000
Power - Power source type - Battery
ProductName - DS3678-ER
Scanning - 2D (matrix & stacked) barcodes supported - Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Scanning - Linear (1D) barcodes supported - Codabar, Code 11, Code 128, Code 39, Code 93, GS1-128 (UCC/EAN-128), MSI, Plessey, U.P.C.
Scanning - Optical sensor resolution - 1280 pixels
Scanning - Pitch reading angle - -65 - 65°
Scanning - Scanner type - 1D/2D
Scanning - Sensor type - Laser
Scanning - Tilt reading angle - -65 - 65°
Scanning - Type - Handheld bar code reader
Scanning - Wavelength - 655 nm
Scanning - Yaw reading angle - -45 - 45°
ShortSummaryDescription - Zebra DS3678-ER, Handheld bar code reader, 1D/2D, Laser, Codabar, Code 11, Code 128, Code 39, Code 93, GS1-128 (UCC/EAN-128), MSI, Plessey, U.P.C., Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417,..., 655 nm
Stck_Kart - 15
Stck_Pal - 15
Storno - Y
Technical details - Compliance certificates - RoHS
Title - Zebra DS3678-ER Handheld bar code reader 1D/2D Laser Black, Green
URL - https://www.zebra.com/us/en/products/scanners/ultra-rugged-scanners/3600-series/ds36x8-er.html
WarrantyInfo -
Weight - 0.54
Weight & dimensions - Depth - 76 mm
Weight & dimensions - Height - 185 mm
Weight & dimensions - Weight - 436 g
Weight & dimensions - Width - 142 mm
