Accessories included -
Battery capacity - 200 Ah
Color - Black
Description - LiFePO4 Extralink lithium iron phosphate batteries with a nominal capacity of 200Ah offer a whole range of benefits compared to traditional solutions based on batteries made in other technologies. Extralink LiFePO4 means longer life, no maintenance, extreme safety, light weight, improved discharge and charge efficiency. LiFePO4 batteries, due to their long life and zero maintenance, are the best investment for many years. The most important features of LiFePO4 Extralink batteries: LiFePO4 12V battery with a nominal capacity of 200Ah Energy storage with a large number of duty cycles for emergency power supply Maintenance-free BMS LiFePO4 battery with low weight No memory effect The perfect battery for a motorhome, yacht Fully maintenance-free LiFePO4 batteries LiFePO4 200Ah Extralink batteries do not require active maintenance to extend their life. In addition, these batteries do not have a memory effect, and the low self-discharge rate (less than 3% per month) of the LiFePO4 battery means that they can be stored for a long time. Low weight and high power density of LiFePO4 batteries 12V Lithium Iron Phosphate (LiFePO4) batteries offer a high power density, making the lithium battery relatively small and lightweight. Compared to lead-acid Extralink LiFePO4 batteries, it provides a high energy density and is at least half the weight. Choose Extralink LiFePO4 if you want to reduce your worries about battery weight and size! LiFePO4 type battery with a large number of work cycles LiFePO4 batteries withstand over 2000 cycles while maintaining an average of 80% of their nominal capacity. For comparison: a traditional lead-acid battery lasts 300-500 cycles at most. The long life makes the LiFePO4 Extralink battery an excellent economic choice. Wide range of LiFePO4 battery applications The Extralink LiFePO4 12V Lithium Iron Phosphate battery is an ideal energy storage for cars, buses, logistic vehicles, boats, emergency power supply, etc. due to its safety and low cost advantages. Perfect as a motorhome battery.
Designation - CE+WEEE
dimensionalWeight - 5496
dimension depth - 550 mm
dimension height - 280 mm
Dimensions - 520 x 237 x 223 mm
dimension weight - 29000 g
dimension width - 280 mm
ean - 5905090330479
Environment requirements - Charging temperature: 0°C to 45°C (32F to 113F) at 60+/-25% RH Discharge temperature: -20°C to 60°C (-4F to 140F) at 60+/-25% relative humidity Storage temperature: 0°C to 40°C (32F to 104F) at 60+/-25% relative humidity
Features - Battery capacity - 2560 Wh
Features - Battery capacity - 200000 mAh
Features - Battery technology - Lithium Iron Phosphate (LiFePO4)
Features - Battery voltage - 12.8 V
Features - Output current - 200 A
Features - Product colour - Black
guarantee - 24
guarantee_type - normal
name - Battery LiFePO4 200AH 12.8V BMS EX.30479
No. of batteries - 1
Other features - Typ: LiFePO4 Napięcie nominalne: 12.8V Pojemność znamionowa: 200.0Ah (C5,25°C) Całkowita energia: 2560Wh Opór wewnętrzny: < 15 mOhm Żywotność: Ponad 2000 cykli przy 1C 100% DOD Miesięczne samorozładowanie: < 3% Efektywność ładowania: 100% @ 0.5C Efektywność rozładowania: 96-99% @1C Parametry ładowania Napięcie ładowania: 14,6 +/- 0,2 V Prąd ładowania: 100A Maks. prąd ładowania: 200A Napięcie odcięcia ładowania: 15,6 V +/- 0,2 V Parametry rozładowywania Znamionowy prąd rozładowania: 100A Maksymalny ciągły prąd rozładowania: 200A Maks. Prąd rozładowania: 500A ( < 1s) Napięcie odcięcia rozładowania: 10V Parametry mechaniczne BMS Obudowa: Plastikowa ABS Terminal: M8
Packaging data - Number of batteries included - 1 pc(s)
Packaging data - Package height - 255 mm
Packaging data - Package type - Box
Packaging data - Package width - 550 mm
producer - Extralink
producerCode - EX.30479
productName - Extralink Accumulator LiFePO4 200AH 12.8V, BMS
productSize - Normal
Safety warning - Hazard pictogram(s) - Corrosion
Safety warning - Hazard pictogram(s) - Environmental hazard
Safety warning - Hazard pictogram(s) - Toxic to health
Safety warning - Warnings - Avoid direct contact with electrolyte, can cause chemical burns.
Safety warning - Warnings - Do not allow battery terminals to short circuit.
Safety warning - Warnings - Do not dispose of the battery in the normal rubbish bin, contact your local collection point for waste electrical and electronic equipment.
sizeX - 223
sizeY - 237
sizeZ - 520
Type - Battery
vendpn - EX.30479
Voltage - 12.8 V
warrantyLength - 12
warrantyType - F
Weight - 22.5 kg
weight - 22500
Weight & dimensions - Depth - 237 mm
Weight & dimensions - Height - 223 mm
Weight & dimensions - Weight - 22.5 kg
Weight & dimensions - Width - 520 mm
