Alarm input/output Performance - Yes
Angle of rotation Camera - 360°
Audio - Audio input channels - 1.0 channels
Audio - Audio output channels - 1.0 channels
Audio - Built-in microphone - Yes
Audio - Voice codecs - AAC, G.711Mu, G.711a, G.723, G.726, PCM
Audio input channels Audio - 1.0 channels
Audio output channels Audio - 1.0 channels
Back Light Compensation (BLC) Video - Yes
Bit rate control Video - Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Bit rate Video - 32 - 8192 Kbps, 12 - 8192 Kbps
Bluetooth Network - No
Brand - Dahua Technology
BrandPartCode - IPC-HFW3549T1-ASPV0280BS5-B
Built-in HDD Storage - No
Built-in microphone Audio - Yes
Camera - Angle of rotation - 360°
Camera - Camera pan control - Yes
Camera - Camera shutter speed - 1/3 - 1/100000 s
Camera - Camera tilt control - Yes
Camera - Lens viewing angle, diagonal - 129°
Camera - Lens viewing angle, horizontal - 98°
Camera - Lens viewing angle, vertical - 71°
Camera - Minimum illumination - 0.003 lx
Camera - Pan range - 0 - 360°
Camera - Tilt angle range - 0 - 90°
Camera - White balance - Auto, Custom modes, Manual, Natural, Outdoor
Camera pan control Camera - Yes
Camera shutter speed Camera - 1/3 - 1/100000 s
Camera tilt control Camera - Yes
Category - Security Cameras
Category Code - FNC
Certification Performance - CE-LVD: EN62368-1; CE-EMC: 2014/30/EU; FCC: 47 CFR FCC 15, B
Closest focusing distance Lens system - 1.2 m
Connectivity technology Performance - Wired
Day/night mode Performance - Yes
DC output voltage Power - 12
Depth Weight & dimensions - 84.7 mm
Description - Launched by Dahua Technology, WizSense is a series of AI products and solutions that adopt independent AI chip and deep learning algorithm. It focuses on human and vehicle with high accuracy, enabling users to fast act on defined targets. Based on Dahua's advanced technologies, WizSense provides intelligent, simple and inclusive products and solutions.5MP, 1/2.7” CMOS image sensor, low illuminance, high image definitionOutputs max. 5MP (2592 × 1944) @20 fps, and supports 4MP (2688 × 1520) @25/30 fpsH.265 codec, high compression rate, low bit rateBuilt-in warm illuminator, and the max. illumination distance: 40 mROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environmentsRotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenesIntelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human)Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detectionSupports sound and light alarm linkage. When an alarm is triggered, the camera links sound alarm and light flashingSupports one-tap disarming. You can disarm the events of alarm output, sending email, audio, and light in the configured periodAlarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card, built-in Mic and speaker12V DC/PoE power supplyIP67 protectionSMD PlusRed and blue flashlight alarm
Design - Form factor - Bullet
Design - Housing material - Metal, Plastic
Design - International Protection (IP) code - IP67
Design - Mounting type - Ceiling/wall
Design - Product colour - Black
Detect distance Lens system - 67.4 m
Ethernet interface type Network - Fast Ethernet
Ethernet LAN (RJ-45) ports Ports & interfaces - 1
Ethernet LAN Network - Yes
Fixed focal length Lens system - 2.8 mm
Form factor Design - Bullet
Frame rate Video - 30 fps
Gain control type Video - Auto/Manual
GTIN - 6939554967498
Highlight Compensation (HLC) Video - Yes
Housing material Design - Metal, Plastic
Identify distance Lens system - 6.7 m
Image sensor - Number of sensors - 1
Image sensor - Optical sensor size - 25.4 / 2.7 mm (1 / 2.7")
Image sensor - Progressive scan - Yes
Image sensor - Sensor type - CMOS
Intelligent Video Surveillance (IVS) system features Security - Intrusion, Tripwire
Internal memory Storage - 512 MB
International Protection (IP) code Design - IP67
LED type Night vision - IR
Length Weight & dimensions - 288.4 mm
Lens system - Closest focusing distance - 1.2 m
Lens system - Detect distance - 67.4 m
Lens system - Fixed focal length - 2.8 mm
Lens system - Identify distance - 6.7 m
Lens system - Maximum aperture number - 1
Lens system - Number of lenses - 1
Lens system - Observe distance - 27 m
Lens system - Recognize distance - 13.5 m
Lens viewing angle, diagonal Camera - 129°
Lens viewing angle, horizontal Camera - 98°
Lens viewing angle, vertical Camera - 71°
LongDesc - Launched by Dahua Technology, WizSense is a series of AI products and solutions that adopt independent AI chip and deep learning algorithm. It focuses on human and vehicle with high accuracy, enabling users to fast act on defined targets. Based on Dahua's advanced technologies, WizSense provides intelligent, simple and inclusive products and solutions.
LongProductName - 5 MP, 1/2.7” CMOS, 2592x1944, > 56 dB, WDR, RJ-45, RCA, PoE, IP67
LongSummaryDescription - Dahua Technology WizSense IPC-HFW3549T1-AS-PV. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: Black, Form factor: Bullet. Minimum illumination: 0.003 lx, Angle of rotation: 360°, Lens viewing angle, horizontal: 98°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.7 mm (1 / 2.7"). Detect distance: 67.4 m, Observe distance: 27 m, Recognize distance: 13.5 m
Management features - Web-based management - Yes
Maximum aperture number Lens system - 1
Maximum resolution Video - 2592 x 1944 pixels
Minimum illumination Camera - 0.003 lx
Mirror Security - Yes
Model - IPC-HFW3549T1-AS-PV
Mounting type Design - Ceiling/wall
Network - Bluetooth - No
Network - Ethernet interface type - Fast Ethernet
Network - Ethernet LAN - Yes
Network - Networking standards - IEEE 802.1x, IEEE 802.3af
Network - Number of users - 20 user(s)
Network - Quality of Service (QoS) support - Yes
Network - Supported network protocols - IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; 802.1x; SNMP
Network - Wi-Fi - No
Networking standards Network - IEEE 802.1x, IEEE 802.3af
Night vision - LED type - IR
Night vision - Night vision - Yes
Night vision - Night vision distance - 40 m
Night vision distance Night vision - 40 m
Night vision Night vision - Yes
Noise reduction technology Video - 3D noise reduction
Noise reduction Video - Yes
Number of cameras Packaging content - 1
Number of lenses Lens system - 1
Number of sensors Image sensor - 1
Number of users Network - 20 user(s)
Observe distance Lens system - 27 m
Operating relative humidity (H-H) Operational conditions - 0 - 95%
Operating temperature (T-T) Operational conditions - -40 - 60 °C
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - -40 - 60 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -40 - 60 °C
Optical sensor size Image sensor - 25.4 / 2.7 mm (1 / 2.7")
Package weight Packaging data - 1.23 kg
Packaging content - Number of cameras - 1
Packaging data - Package weight - 1.23 kg
Pan range Camera - 0 - 360°
Performance - Alarm input/output - Yes
Performance - Certification - CE-LVD: EN62368-1; CE-EMC: 2014/30/EU; FCC: 47 CFR FCC 15, B
Performance - Connectivity technology - Wired
Performance - Day/night mode - Yes
Performance - Placement supported - Outdoor
Performance - Type - IP security camera
Performance - Wide Dynamic Range (WDR) - Yes
Placement supported Performance - Outdoor
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Power - DC output voltage - 12
Power - Power consumption (max) - 2 W
Power - Power consumption (Power over Ethernet (PoE)) - 2.6 W
Power - Power source type - DC, PoE
Power consumption (max) Power - 2 W
Power consumption (Power over Ethernet (PoE)) Power - 2.6 W
Power source type Power - DC, PoE
Privacy masking Video - Yes
Product colour Design - Black
ProductName - IPC-HFW3549T1-AS-PV
Progressive scan Image sensor - Yes
Quality of Service (QoS) support Network - Yes
Recognize distance Lens system - 13.5 m
Region of Interest (ROI) encoding Video - Yes
ROM capacity Storage - 128 MB
Security - Intelligent Video Surveillance (IVS) system features - Intrusion, Tripwire
Security - Mirror - Yes
Security - Video motion detection - Yes
Sensor type Image sensor - CMOS
ShortSummaryDescription - Dahua Technology WizSense IPC-HFW3549T1-AS-PV, IP security camera, Outdoor, Wired, CE-LVD: EN62368-1; CE-EMC: 2014/30/EU; FCC: 47 CFR FCC 15, B, Ceiling/wall, Black
Storage - Built-in HDD - No
Storage - Internal memory - 512 MB
Storage - ROM capacity - 128 MB
Storage relative humidity (H-H) Operational conditions - 0 - 95%
Storage temperature (T-T) Operational conditions - -40 - 60 °C
Summary - Dahua Technology WizSense IPC-HFW3549T1-AS-PV. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: Black, Form factor: Bullet. Minimum illumination: 0.003 lx, Angle of rotation: 360°, Lens viewing angle, horizontal: 98°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.7 mm (1 / 2.7"). Detect distance: 67.4 m, Observe distance: 27 m, Recognize distance: 13.5 m
Supported graphics resolutions Video - 640 x 480 (VGA), 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080), 2304 x 1296, 2560 x 1440, 2592 x 1944, 2688 x 1520
Supported network protocols Network - IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; 802.1x; SNMP
Tilt angle range Camera - 0 - 90°
Title - Dahua Technology WizSense IPC-HFW3549T1-AS-PV Bullet IP security camera Outdoor 2592 x 1944 pixels Ceiling/wall
Total megapixels Video - 5 MP
Type Performance - IP security camera
Unit Box Height - 0.325
Unit Box Length - 0.57
Unit Box Width - 0.045
Unit Calculated Volume - 0.008336 cubm
Unit Calculated Weight - 1.38 kg
Units per Pallet - 0
Units per Shipping Box - 8
URL - https://www.dahuasecurity.com/products/All-Products/Network-Cameras/WizSense-Series/3-Series/TiOC/IPC-HFW3549T1-AS-PV=S5
Vendor Homepage - https://www.dahuasecurity.com/products/All-Products/Network-Cameras/WizSense-Series/3-Series/TiOC/IPC-HFW3549T1-AS-PV=S5
Video - Back Light Compensation (BLC) - Yes
Video - Bit rate - 32 - 8192 Kbps, 12 - 8192 Kbps
Video - Bit rate control - Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Video - Frame rate - 30 fps
Video - Gain control type - Auto/Manual
Video - Highlight Compensation (HLC) - Yes
Video - Maximum resolution - 2592 x 1944 pixels
Video - Noise reduction - Yes
Video - Noise reduction technology - 3D noise reduction
Video - Privacy masking - Yes
Video - Region of Interest (ROI) encoding - Yes
Video - Supported graphics resolutions - 640 x 480 (VGA), 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080), 2304 x 1296, 2560 x 1440, 2592 x 1944, 2688 x 1520
Video - Total megapixels - 5 MP
Video - Video compression formats - H.264, H.264+, H.265, H.265+, M-JPEG
Video - Video streaming - Yes
Video compression formats Video - H.264, H.264+, H.265, H.265+, M-JPEG
Video motion detection Security - Yes
Video streaming Video - Yes
Voice codecs Audio - AAC, G.711Mu, G.711a, G.723, G.726, PCM
Warranty - 36 months
WarrantyInfo -
Web-based management Management features - Yes
Weight & dimensions - Depth - 84.7 mm
Weight & dimensions - Length - 288.4 mm
Weight & dimensions - Weight - 1 kg
Weight & dimensions - Width - 94.4 mm
Weight Weight & dimensions - 1 kg
White balance Camera - Auto, Custom modes, Manual, Natural, Outdoor
Wi-Fi Network - No
Wide Dynamic Range (WDR) Performance - Yes
Width Weight & dimensions - 94.4 mm
