ID: 836054
Product code: FPMA-VESA400
Can be ordered 25 units Availability: 14 days after order approval
Warranty: 3 years
Newstar NEOMOUNTS BY NEWSTAR FPMA-VESA400 VESA Adapter Plate for Mount 5x5/7.5x7.5/10x10/20x10cm Screen up to 52i VESA 20x20/40x20/12x18cm
Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
-
Posti parcel machineWithin 1-2 working days6.99 € -
Post OfficeWithin 1-2 working days6.99 €
-
Delivery with Posti courier mailWithin 1-2 working days10.99 €
Main product parameters All parameters
- Maximum load (1 screen), kg: 35.00
- Maximum screen diagonal, inches: 52
- Minimum screen diagonal, inches: 22
All parameters
Colour
: Sudraba
Maximum load (1 screen), kg
: 35.00
Maximum screen diagonal, inches
: 52
Minimum screen diagonal, inches
: 22
Model
: FPMA-VESA400
Notebook holder
: Nav
Number of supported screens
: 1
Rotation
: Not
Swivel
: Nav
Tilt
: Not
Type of attachment
: Sienas
VESA support
: 50 x 50, 75 x 75, 100 x 100, 200 x 100, 200 x 200, 300 x 200, 400 x 200
More detailed specification
Accessories included -
Brand - Neomounts
BrandPartCode - FPMA-VESA400
Category - Monitor Mount Accessories
Category Code - MMA
Color - Silver
Country of origin Technical details - China
Description - NEWSTAR VESA CONVERSION PLATE - VESA 75/100 - 200X100, 200X200, 400X200 - SILVER
Description - The Neomounts VESA adapter, model FPMA-VESA400 allows a VESA mount with 50x50, 75x75, 100x100 and 200x100 mm interface to be used with displays with VESA hole patterns of 200x200mm, 400x200 and 120x180 mm (JVC holepattern). Ideal when flat screen needs different VESA pattern to select wall-, desk- or ceiling mount. Neomounts FPMA-VESA400 is suitable for screens up to 52" (130 cm). The weight capacity of this product is 35 kg each screen. Depth of this adapter is 3 millimetres only. The adapter is suitable for screens that meet VESA hole pattern 200x200, 400x200 and 120x180 mm (JVC holepattern). Different hole patterns can be covered using Neomounts VESA adapter plates. All installation material is included with the product.
Designation - CE+WEEE
dimension depth - 430 mm
dimension height - 20 mm
Dimensions -
dimension weight - 1200 g
dimension width - 230 mm
ean - 8717371441678
Features - Housing material - Steel
Features - Maximum screen size - 132.1 cm (52")
Features - Maximum VESA mount - 400 x 200 mm
Features - Maximum weight capacity - 35 kg
Features - Minimum screen size - 55.9 cm (22")
Features - Number of displays supported - 1
Features - Panel mounting interface - 100 x 200,100 x 100,200 x 100,200 x 200,200 x 300,200 x 400,300 x 200,400 x 200,50 x 50,75 x 75
Features - Product colour - Silver
Features - VESA mounting - Yes
GTIN - 5054629876350
GTIN - 8717371441678
guarantee - 60
guarantee_type - normal
Harmonized System (HS) code Logistics data - 7326909890
Height - 20.000000
Height adjustment - No
Housing material Features - Steel
Length - 425.000000
Load (max) - 35 kg
Logistics data - Harmonized System (HS) code - 7326909890
Logistics data - Master (outer) case gross weight - 12.5 kg
Logistics data - Master (outer) case height - 245 mm
Logistics data - Master (outer) case length - 220 mm
Logistics data - Master (outer) case net weight - 10.6 kg
Logistics data - Master (outer) case width - 435 mm
Logistics data - Products per master (outer) case - 10 pc(s)
Logistics data - Products per pallet (EU) - 180 pc(s)
LongDesc - The Neomounts VESA adapter, model FPMA-VESA400 allows a VESA mount with 50x50, 75x75, 100x100 and 200x100 mm interface to be used with displays with VESA hole patterns of 200x200mm, 400x200 and 120x180 mm (JVC holepattern). Ideal when flat screen needs different VESA pattern to select wall-, desk- or ceiling mount.Neomounts FPMA-VESA400 is suitable for screens up to 52" (130 cm). The weight capacity of this product is 35 kg each screen. Depth of this adapter is 3 millimetres only. The adapter is suitable for screens that meet VESA hole pattern 200x200, 400x200 and 120x180 mm (JVC holepattern). Different hole patterns can be covered using Neomounts VESA adapter plates.All installation material is included with the product.
LongProductName - Neomounts FPMA-VESA400 VESA-adapter - 22-52" - max 35 kg - VESA 50x50-400x200 - silver
LongSummaryDescription - Neomounts FPMA-VESA400 VESA-adapter 22-52". Product colour: Silver, Housing material: Steel, Maximum weight capacity: 35 kg. Weight: 1.06 kg. Package height: 425 mm, Package width: 225 mm, Package depth: 20 mm. Master (outer) case net weight: 10.6 kg, Master (outer) case width: 435 mm, Master (outer) case length: 220 mm. Package net weight: 1.06 kg
Manufacturer - Neomounts
ManufacturerPartNumber - FPMA-VESA400
Master (outer) case gross weight Logistics data - 12.5 kg
Master (outer) case height Logistics data - 245 mm
Master (outer) case length Logistics data - 220 mm
Master (outer) case net weight Logistics data - 10.6 kg
Master (outer) case width Logistics data - 435 mm
Maximum screen size Features - 132.1 cm (52")
Maximum VESA mount Features - 400 x 200 mm
Maximum weight (capacity), kg - 35
Maximum weight capacity Features - 35 kg
Minimum screen size Features - 55.9 cm (22")
Motorized - No
name - Płyta do montażu w uchwycie FPMA-VESA400 ADAPTER 100X100-400X200
Number of displays supported Features - 1
Number of supported monitors - 1
Other features -
Package depth Packaging data - 20 mm
Package height Packaging data - 425 mm
Package net weight Packaging data - 1.06 kg
Package weight Packaging data - 1.1 kg
Package width Packaging data - 225 mm
Packaging data - Package depth - 20 mm
Packaging data - Package height - 425 mm
Packaging data - Package net weight - 1.06 kg
Packaging data - Package weight - 1.1 kg
Packaging data - Package width - 225 mm
Panel mounting interface Features - 100 x 200,100 x 100,200 x 100,200 x 200,200 x 300,200 x 400,300 x 200,400 x 200,50 x 50,75 x 75
PeriodofWarranty - 5 Y
producer - Neomounts
Product colour Features - Silver
ProductName - Neomounts FPMA-VESA400 VESA-adapter 22-52"
Products per master (outer) case Logistics data - 10 pc(s)
Products per pallet (EU) Logistics data - 180 pc(s)
Screen size (max) - 52 ''
Screen size (min) - 22 ''
Short summary - Neomounts FPMA-VESA400 VESA-adapter - 22-52" - max 35 kg - VESA 50x50-400x200 - silver
ShortSummaryDescription - Neomounts FPMA-VESA400 VESA-adapter 22-52", Silver, Steel, 35 kg, 100 x 200,100 x 100,200 x 100,200 x 200,200 x 300,200 x 400,300 x 200,400 x 200,50 x 50,75 x 75, 132.1 cm (52"), 55.9 cm (22")
Stand/mount type - Other/accessories
Stuff - Steel
Summary - Neomounts FPMA-VESA400 VESA-adapter 22-52". Product colour: Silver, Housing material: Steel, Maximum weight capacity: 35 kg. Weight: 1.06 kg. Package height: 425 mm, Package width: 225 mm, Package depth: 20 mm. Master (outer) case net weight: 10.6 kg, Master (outer) case width: 435 mm, Master (outer) case length: 220 mm. Package net weight: 1.06 kg
Technical details - Country of origin - China
Tilt - No
Title - Neomounts FPMA-VESA400 VESA-adapter 22-52"
Turn - No
Type - Wall
Unit Box Height - 0.23
Unit Box Length - 0.428
Unit Box Width - 0.02
Unit Calculated Volume - 0.001969 cubm
Unit Calculated Weight - 1.3 kg
Units per Pallet - 160
Units per Shipping Box - 1
URL - https://www.neomounts.com/default.asp?pageid=44&artdetail=FPMA-VESA400
Usage - Monitors
Vendor Homepage - https://www.neomounts.com/default.asp?pageid=44&artdetail=FPMA-VESA400
vendpn - FPMA-VESA400
VESA - 50 x 50
VESA - 75 x 75
VESA - 100 x 100
VESA - 100 x 200
VESA - 200 x 200
VESA - 200 x 400
VESA - 300 x 200
VESA - 400 x 200
VESA-standard, mm - 50 x 50
VESA-standard, mm - 400 x 200
VESA mounting Features - Yes
Warranty - 60 months
WarrantyInfo - 5 year
Weight - 1.330000
Weight & dimensions - Weight - 1.06 kg
Weight Weight & dimensions - 1.06 kg
Wheels - No
Width - 230.000000
