Newstar Tiltable wall mount, 42-86"

Accessories included -
Brand - Neomounts
BrandPartCode - WL35-750BL16
Cable management Ergonomics - Yes
Category - TV Mounts & Stands
Category Code - TMS
Color - Black
Colour of product - orange / off-white
Corner mount - No
Country of origin Technical details - China
Depth (max) Weight & dimensions - 9.3 cm
Depth Weight & dimensions - 93 mm
Description - NEOMOUNTS LEVEL-750 WALL MOUNT (XL, 125 KG, TILTABLE, TILT GUARD, CONNECTABLE, VESA 600X400)
Description - Neomounts WL35-750BL16 LEVEL is the ultimate tilt solution for securely mounting an interactive or heavy display up to 86 inches with a maximum load capacity of 125 kg. Tool-free tilt adjustment (+15°/-15°) allows for optimal viewing angles. This durable wall mount features a solid, contoured wall plate and is designed for stability and precision, ensuring a secure screen mount even on uneven surfaces. The mount has individual adjustable brackets (10 mm) for securely adjusting the height of the display or leveling it.
The LEVEL-750 wall mount has a profile of 9.3 cm and is suitable for screens that meet VESA hole patterns from 100x100 to 600x400 mm. The quick-connect wall plate allows for multiple screens to be mounted. Additionally, the wall plate is designed with special cutouts for wall outlets, safety devices and cables. It has various perforated holes for easy cable tie attachment and provides cable storage for a neat and tidy finish.
The WL35-750BL16 features a secure and practical pull & release system, allowing you to quickly attach and detach your display in a safe and secure manner. The tilt lock prevents the display from tilting upwards when attaching or detaching it from the mount, allowing for a safe installation. It is possible to lock the mount with a padlock (not included) for additional screen security.
For simple and efficient storage, the optional AV stand can be installed on the left or right side of the mount.
Description - The Neomounts WL35-750BL16 LEVEL is the ultimate tiltable solution for securely mounting an interactive or heavy weight display up to 86" with a maximum capacity of 125 kg. The toolless tilt adjustment (+15°/-15°) allows you to create the optimum viewing angle. This heavy-duty wall mount features a sturdy high profile wall plate and is engineered for stability and precision, ensuring your screen is securely mounted even on uneven surfaces. The mount features individual adjustable brackets (10 mm) for securely adjusting the display height or levelling it. The LEVEL-750 wall mount has a profile of 9,3 cm and is suitable for screens that meet VESA hole pattern 100x100 to 600x400 mm. Its quickly connectable wall plate allows for multiple screen mounting. Additionally, the wall plate is designed with specific cut-outs for wall sockets and securing devices and cables. It features various perforated holes for easy tie-wrap cable fixing and provides space for cable storage, ensuring a clean and tidy finishing. The WL35-750BL16 includes a safe and practical pull & release system, allowing you to quickly attach and detach the display in a safe and secure manner. The tilt-lock prevents the display from tilting upwards when attaching it on or detaching it from the mount to enable a safe install. It is possible to lock the bracket using a padlock (not included) for extra screen security. For a simple and effective storage, an optionally available, AV-rack can be installed to the left or right side of the mount.
Design - Housing material - Steel
Design - Product colour - Black
Designation - CE+WEEE
dimension depth - 750 mm
dimension height - 100 mm
Dimensions - 430 x 686 x 93 mm
dimension weight - 7000 g
dimension width - 210 mm
Distance to the wall (max) Ergonomics - 9.3 cm
ean - 8717371443665
Ergonomics - Cable management - Yes
Ergonomics - Distance to the wall (max) - 9.3 cm
Ergonomics - Height adjustment - Yes
Ergonomics - Height adjustment range - 0 - 10 mm
Ergonomics - Tilt adjustment - Yes
Ergonomics - Tilt angle range - -15 - 15°
GTIN - 8717371443665
guarantee - 60
guarantee_type - normal
Harmonized System (HS) code Logistics data - 7326909890
Height - 104.000000
Height adjustment - Yes
Height adjustment Ergonomics - Yes
Height adjustment range Ergonomics - 0 - 10 mm
Height Weight & dimensions - 430 mm
Horizontal adjustment - 15 °
Housing material Design - Steel
Length - 730.000000
Load (max) - 125 kg
Lockable Technical details - Padlock not included
Logistics data - Harmonized System (HS) code - 7326909890
Logistics data - Master (outer) case gross weight - 21.5 kg
Logistics data - Master (outer) case height - 324 mm
Logistics data - Master (outer) case length - 227 mm
Logistics data - Master (outer) case net weight - 16.5 kg
Logistics data - Master (outer) case width - 746 mm
Logistics data - Products per master (outer) case - 3 pc(s)
Logistics data - Products per pallet (EU) - 60 pc(s)
LongDesc - The Neomounts WL35-750BL16 LEVEL is the ultimate tiltable solution for securely mounting an interactive or heavy weight display up to 86" with a maximum capacity of 125 kg. The toolless tilt adjustment (+15°/-15°) allows you to create the optimum viewing angle. This heavy-duty wall mount features a sturdy high profile wall plate and is engineered for stability and precision, ensuring your screen is securely mounted even on uneven surfaces. The mount features individual adjustable brackets (10 mm) for securely adjusting the display height or levelling it. The LEVEL-750 wall mount has a profile of 9,3 cm and is suitable for screens that meet VESA hole pattern 100x100 to 600x400 mm. Its quickly connectable wall plate allows for multiple screen mounting. Additionally, the wall plate is designed with specific cut-outs for wall sockets and securing devices and cables. It features various perforated holes for easy tie-wrap cable fixing and provides space for cable storage, ensuring a clean and tidy finishing.The WL35-750BL16 includes a safe and practical pull & release system, allowing you to quickly attach and detach the display in a safe and secure manner. The tilt-lock prevents the display from tilting upwards when attaching it on or detaching it from the mount to enable a safe install. It is possible to lock the bracket using a padlock (not included) for extra screen security. For a simple and effective storage, an optionally available, AV-rack can be installed to the left or right side of the mount.
LongProductName - Neomounts LEVEL-750 WL35-750BL16 Tiltable heavy duty wall mount - 42-86" screen - max 125 kg - VESA 100x100-600x400 - d 9,3 cm - level adjustment - lockable (excl. lock) - TÜV certified - Rapid Install-model - Tilt Guard - black
LongSummaryDescription - Neomounts WL35-750BL16 Heavy duty wall mount 42-86" - tilt - lockable - fast installation - TÜV. Maximum weight capacity: 125 kg, Minimum screen size: 106.7 cm (42"), Maximum screen size: 2.18 m (86"), Minimum VESA mount: 100 x 100 mm, Maximum VESA mount: 600 x 400 mm. Height adjustment range: 0 - 10 mm, Tilt angle range: -15 - 15°, Distance to the wall (max): 9.3 cm. Product colour: Black
Manufacturer - Neomounts
ManufacturerPartNumber - WL35-750BL16
Master (outer) case gross weight Logistics data - 21.5 kg
Master (outer) case height Logistics data - 324 mm
Master (outer) case length Logistics data - 227 mm
Master (outer) case net weight Logistics data - 16.5 kg
Master (outer) case width Logistics data - 746 mm
Maximum screen size Mounting - 2.18 m (86")
Maximum VESA mount Mounting - 600 x 400 mm
Maximum weight (capacity), kg - 125
Maximum weight capacity (per display) Mounting - 125 kg
Maximum weight capacity Mounting - 125 kg
Minimum screen size Mounting - 106.7 cm (42")
Minimum VESA mount Mounting - 100 x 100 mm
Model - WL35-750BL16
Motorized - No
Mounting - Maximum screen size - 2.18 m (86")
Mounting - Maximum VESA mount - 600 x 400 mm
Mounting - Maximum weight capacity - 125 kg
Mounting - Maximum weight capacity (per display) - 125 kg
Mounting - Minimum screen size - 106.7 cm (42")
Mounting - Minimum VESA mount - 100 x 100 mm
Mounting - Mounting type - Wall
Mounting - Number of displays supported - 1
Mounting - Panel mounting interface - 100 x 200,100 x 100,100 x 150,120 x 120,150 x 200,200 x 100,200 x 150,200 x 200,200 x 300,200 x 400,300 x 100,300 x 200,300 x 300,350 x 350,400 x 200,400 x 300,400 x 400,400 x 600,440 x 400,500 x 400,600 x 300,600 x 200,600 x 400
Mounting type Mounting - Wall
name - WL35-750BL16 LEVEL-750 XL, 125 kg
Number of displays supported Mounting - 1
Other features - Height adjustment 10 mm Anti-tilt protection
Package depth Packaging data - 102 mm
Package height Packaging data - 209 mm
Package weight Packaging data - 6.9 kg
Package width Packaging data - 728 mm
Packaging data - Package depth - 102 mm
Packaging data - Package height - 209 mm
Packaging data - Package weight - 6.9 kg
Packaging data - Package width - 728 mm
Panel mounting interface Mounting - 100 x 200,100 x 100,100 x 150,120 x 120,150 x 200,200 x 100,200 x 150,200 x 200,200 x 300,200 x 400,300 x 100,300 x 200,300 x 300,350 x 350,400 x 200,400 x 300,400 x 400,400 x 600,440 x 400,500 x 400,600 x 300,600 x 200,600 x 400
PeriodofWarranty - 5 Y
producer - Neomounts
Product colour Design - Black
ProductName - Neomounts WL35-750BL16 Heavy duty wall mount 42-86" - tilt - lockable - fast installation - TÜV
Products per master (outer) case Logistics data - 3 pc(s)
Products per pallet (EU) Logistics data - 60 pc(s)
Quantity per pack Technical details - 1 pc(s)
Range adjustment - No
Screen size (max) - 86 ''
Screen size (min) - 42 ''
Screen size compatibility, " - 42-86
Short summary - Neomounts LEVEL-750 WL35-750BL16 Tiltable heavy duty wall mount - 42-86" screen - max 125 kg - VESA 100x100-600x400 - d 9,3 cm - level adjustment - lockable (excl. lock) - TÜV certified - Rapid Install-model - Tilt Guard - black
ShortSummaryDescription - Neomounts WL35-750BL16 Heavy duty wall mount 42-86" - tilt - lockable - fast installation - TÜV, 2.18 m (86"), 100 x 100 mm, 600 x 400 mm, -15 - 15°, Steel, Black
Stand/mount type - Wall
Stuff - Steel
Summary - Neomounts WL35-750BL16 Heavy duty wall mount 42-86" - tilt - lockable - fast installation - TÜV. Maximum weight capacity: 125 kg, Minimum screen size: 106.7 cm (42"), Maximum screen size: 2.18 m (86"), Minimum VESA mount: 100 x 100 mm, Maximum VESA mount: 600 x 400 mm. Height adjustment range: 0 - 10 mm, Tilt angle range: -15 - 15°, Distance to the wall (max): 9.3 cm. Product colour: Black
Technical details - Country of origin - China
Technical details - Lockable - Padlock not included
Technical details - Quantity per pack - 1 pc(s)
Tilt - Yes
Tilt adjustment, ° - +15-15
Tilt adjustment Ergonomics - Yes
Tilt angle range Ergonomics - -15 - 15°
Title - Neomounts WL35-750BL16 Heavy duty wall mount 42-86" - tilt - lockable - fast installation - TÜV
Turn - No
Type - Wall
Unit Box Height - 0.1
Unit Box Length - 0.73
Unit Box Width - 0.21
Unit Calculated Volume - 0.01533 cubm
Unit Calculated Weight - 6.9 kg
Units per Shipping Box - 1
URL - https://www.neomounts.com/default.asp?pageid=44&artdetail=WL35-750BL16
Usage - TV
Vendor Homepage - https://www.neomounts.com/default.asp?pageid=44&artdetail=WL35-750BL16
vendpn - WL35-750BL16
VESA - 100 x 100
VESA - 100 x 150
VESA - 100 x 200
VESA - 120 x 120
VESA - 200 x 100
VESA - 200 x 200
VESA - 200 x 300
VESA - 200 x 400
VESA - 300 x 100
VESA - 300 x 200
VESA - 300 x 300
VESA - 350 x 350
VESA - 400 x 200
VESA - 400 x 300
VESA - 400 x 400
VESA - 400 x 500
VESA - 400 x 600
VESA - 440 x 400
VESA - 500 x 400
VESA - 600 x 200
VESA - 600 x 300
VESA - 600 x 400
VESA-standard, mm - 100 x 100
VESA-standard, mm - 100 x 150
VESA-standard, mm - 100 x 200
VESA-standard, mm - 120 x 120
VESA-standard, mm - 200 x 100
VESA-standard, mm - 200 x 200
VESA-standard, mm - 200 x 300
VESA-standard, mm - 200 x 400
VESA-standard, mm - 300 x 100
VESA-standard, mm - 300 x 200
VESA-standard, mm - 300 x 300
VESA-standard, mm - 350 x 350
VESA-standard, mm - 400 x 200
VESA-standard, mm - 400 x 300
VESA-standard, mm - 400 x 400
VESA-standard, mm - 400 x 500
VESA-standard, mm - 400 x 600
VESA-standard, mm - 440 x 400
VESA-standard, mm - 500 x 400
VESA-standard, mm - 600 x 200
VESA-standard, mm - 600 x 300
VESA-standard, mm - 600 x 400
Warranty - 60 months
WarrantyInfo - 5 year
Weight - 6.850000
Weight & dimensions - Depth - 93 mm
Weight & dimensions - Depth (max) - 9.3 cm
Weight & dimensions - Height - 430 mm
Weight & dimensions - Weight - 5.5 kg
Weight & dimensions - Width - 686 mm
Weight Weight & dimensions - 5.5 kg
Wheels - No
Width - 210.000000
Width Weight & dimensions - 686 mm
