MikroTik hEX S RB760iGS 10/100/1000 Mbit/s, Ethernet LAN (RJ-45) ports 5, USB ports quantity 1

Accessories included -
Antenna - Antenna type - Not supported
Antenna > Antenna type - No antenna
Antenna type Antenna - Not supported
brand - MikroTik
Cabling technology Network - 10/100/1000Base-T(X)
category - MikroTik > Ethernet rūteri > hEX
Category - Root/Electronics/Networks and communication/Routers
Category - Tīkla produkti, Gudrā māja :: Tīkla produkti :: Maršrutētāji / Rūteri
Category 1 - Netzwerk
Category 2 - Router
Category Code - ROU
category_en - Computers & Components > Network products > Wired routers
category_lv - Datortehnika > Tīkla produkti > Vadu maršrutētāji
category_ru - Datortehnika > Tīkla produkti > Vadu maršrutētāji
Cechy podstawowe: Ilość rdzeni - 2 szt.
Cechy podstawowe: Pamięć Flash - 16 MB
Cechy podstawowe: Pamięć RAM - 256 MB
Cechy podstawowe: Procesor - 0.88 GHz
Certificates > Certification - CE, EAC, ROHS
Code - RB760IGS
Code - RB760iGS
Color - Black
Dane techniczne: Funkcje urządzenia - router DSL
Dane techniczne: Gwarancja - 1 rok w serwisie sprzedawcy
Dane techniczne: Producent - MikroTik
Dane techniczne: Zastosowanie - biznesowy
DC-in jack Ports & interfaces - Yes
Depth Weight & dimensions - 89 mm
Desc - Portu ātrums: 10/100/1000 Mb/s, Tips: LAN, WiFi protokoli: Nav, WiFi ātrums: Nav, Bāzes portu skaits: 5, Ugunsmūris | Firewall: Nav, Garantija: 2 gadi
Description - hEX S is a five port Gigabit Ethernet router for locations where wireless connectivity is not required. Compared to the hEX, the hEX S also features an SFP port and PoE output on the last port. It is affordable, small and easy to use, but at the same time comes with a very powerful dual core 880 MHz CPU and 256 MB RAM, capable of all the advanced configurations that RouterOS supports. The device has a USB 2.0, PoE output for Ethernet port #5 and a 1.25Gbit/s SFP cage. IPsec hardware encryption (~470 Mbps) and The Dude server package is supported, microSD slot on it provides improved r/w speed for file storage and Dude.
Description - hEX S to pięcioportowy router Gigabit Ethernet przeznaczony do lokalizacji, w których łączność bezprzewodowa nie jest wymagana. W porównaniu do hEX, hEX S posiada również port SFP i wyjście PoE na ostatnim porcie.
Jest niedrogi, mały i łatwy w użyciu, ale jednocześnie jest wyposażony w bardzo mocny dwurdzeniowy procesor 880 MHz i 256 MB pamięci RAM, zdolny do wszystkich zaawansowanych konfiguracji obsługiwanych przez RouterOS. Urządzenie posiada wyjście USB 2.0, PoE dla portu Ethernet nr 5 oraz klatkę 1,25Gbit/s SFP. Port nr 5 może zasilać inne pasywne urządzenia obsługujące PoE tym samym napięciem, co urządzenie.
Szyfrowanie sprzętowe IPsec (~470 Mb/s) i pakiet serwerowy The Dude są obsługiwane, gniazdo microSD zapewnia lepszą prędkość r/w do przechowywania plików i Dude.
description_en - Specifications
General Product code: RB760iGS Architecture: MMIPS CPU: MT7621A CPU cores: 2 CPU threads: 4 CPU nominal frequency: 880 MHz Switch chip model: MT7621A Dimensions: 113 × 89 × 28 mm Operating system: RouterOS RouterOS license: level 4 RAM: 256 MB Storage: 16 MB (FLASH) MTBF: approx. 100,000 hours at 25°C Tested ambient temperature: –40°C to +70°C IPsec hardware acceleration: yes Suggested price: $79.00 Powering Number of DC inputs: 2 (DC jack, PoE-IN) DC jack input voltage: 12–57 V Max power consumption: 24 W Max power consumption without attachments: 6 W PoE-IN: 802.3af/at, 12–57 V Cooling type: passive PoE-out PoE-out port: Ether5 PoE-out: passive, up to 57 V Low voltage PoE-out current limit: 500 mA High voltage PoE-out current limit: 500 mA Max total output current: 500 mA Networking 10/100/1000 Ethernet ports: 5 SFP ports: 1 Peripherals Memory card type: microSD Memory card slots: 1 USB ports: 1 USB Power Reset: yes USB type: USB Type A Max USB current: 1 A
description_lv - Specifikācija
Vispārīgi Produkta kods: RB760iGS Arhitektūra: MMIPS Procesors: MT7621A CPU kodoli: 2 CPU pavedieni: 4 CPU nominālā frekvence: 880 MHz Slēdža mikroshēmas modelis: MT7621A Izmēri: 113 × 89 × 28 mm Operētājsistēma: RouterOS RouterOS licence: līmenis 4 RAM: 256 MB Atmiņa: 16 MB (FLASH) MTBF: apmēram 100 000 stundas pie 25°C Testētā darba temperatūra: –40°C līdz +70°C IPsec aparatūras paātrinājums: jā Ieteicamā cena: $79.00 Barošana DC ievadu skaits: 2 (DC ligzda, PoE-IN) DC ligzdas ieejas spriegums: 12–57 V Maksimālais enerģijas patēriņš: 24 W Maksimālais patēriņš bez pieslēgumiem: 6 W PoE-IN: 802.3af/at, 12–57 V Dzesēšanas veids: pasīvs PoE-izeja PoE-out ports: Ether5 PoE-out: pasīvs, līdz 57 V Zema sprieguma strāvas ierobežojums: 500 mA Augsta sprieguma strāvas ierobežojums: 500 mA Maksimālā kopējā strāva: 500 mA Tīklošana 10/100/1000 Ethernet porti: 5 SFP porti: 1 Perifērijas ierīces Atmiņas kartes tips: microSD Atmiņas karšu sloti: 1 USB porti: 1 USB Power Reset: jā USB tips: USB Type A Maksimālā USB strāva: 1 A
description_ru - Технические характеристики
Общие параметры Код продукта: RB760iGS Архитектура: MMIPS Процессор: MT7621A Количество ядер CPU: 2 Количество потоков CPU: 4 Номинальная частота CPU: 880 МГц Модель коммутатора: MT7621A Размеры: 113 × 89 × 28 мм Операционная система: RouterOS Лицензия RouterOS: уровень 4 ОЗУ: 256 МБ Хранилище: 16 МБ (FLASH) MTBF: около 100 000 часов при 25°C Температура эксплуатации: от –40°C до +70°C Аппаратное ускорение IPsec: есть Рекомендуемая цена: $79.00 Питание Количество DC-входов: 2 (разъём питания, PoE-IN) Напряжение DC-разъёма: 12–57 В Максимальное энергопотребление: 24 Вт Максимальное энергопотребление без подключений: 6 Вт PoE-IN: 802.3af/at, 12–57 В Тип охлаждения: пассивное PoE-выход PoE-out порт: Ether5 PoE-out: пассивное, до 57 В Токовый лимит (низкое напряжение): 500 мА Токовый лимит (высокое напряжение): 500 мА Максимальный суммарный ток: 500 мА Сетевые интерфейсы Ethernet-порты 10/100/1000: 5 SFP-порты: 1 Периферия Тип карты памяти: microSD Слоты для карт памяти: 1 Количество USB-портов: 1 USB Power Reset: есть Тип USB: USB Type A Максимальный ток USB: 1 А
Design - Product colour - Black
Designation - CE+WEEE
dimensionalWeight - 204
dimension depth - 45 mm
dimension height - 170 mm
Dimensions - 113 x 89 x 28 mm
dimension weight - 200 g
dimension width - 120 mm
EAN - 2000001011881
EAN - 4752224002785
ean - 4752224002785
Eans - 4752224002785
Ethernet interface type Network - Gigabit Ethernet
Ethernet LAN (RJ-45) ports Ports & interfaces - 5
Ethernet LAN data rates Network - 10,100,1000 Mbit/s
Ethernet LAN Network - Yes
Ethernet WAN WAN connection - Yes
Features - Internal memory - 256 MB
Features > Mesh Support - No
Features > Mobile Broadband - No mobile broadband
Features > MU-MiMO - No
Gross weight - 0.431 kg
gross_weight - 0.14 kg
guarantee - 12
guarantee_type - normal
Hard drive > Storage capacity - 16 MB
Harmonized System (HS) code Logistics data - 85176990
height - 0.07 m
Height Weight & dimensions - 28 mm
I/O ports - 1 x USB 2.0 Type A
I/O ports - 5 x 10/100/1000 Mbit/s
Installed SFP modules quantity Ports & interfaces - 1
Internal memory Features - 256 MB
LargeDescHTML -
length - 0.18 m
Link - https://mikrotik.com/product/hex_s#fndtn-specifications
Link - https://wiki.mikrotik.com/wiki/MikroTik_SFP_module_compatibility_table
Logistics data - Harmonized System (HS) code - 85176990
Management, monitoring, configuration -
Manufacturer - MikroTik
Model - MikroTik hEX S RB760iG Router
Model - RB760iGS
mpn - RB760iGS
MPN - RB760IGS
Name - MikroTik hEX Black
Name - MikroTik RB760iGS
Name - Mikrotik RB760iGS
name - MikroTik Router xDSL 1xWAN 4xLAN SFP RB760iG
Name - Mikrotik Wired Ethernet Router RB760iGS, hEX S, Dual Core 880MHz CPU, 256MB RAM, 16 MB (MicroSD), 5xGigabit LAN, 1xSFP, USB, IPsec hardware encryption support and The Dude server package, PCB temperature and Voltage Monitor, Beeper, RouterOS L4 | MikroTik | Enthernet Router hEX S | RB760iGS | No Wi-Fi | 10/100/1000 Mbit/s | Mesh Support No | MU-MiMO No | No mobile broadband | Antenna type No antenna | 1 | 12 month(s)
Name - NET ROUTER 10/100/1000M 5PORT/HEX S RB760IGS MIKROTIK
Network - Cabling technology - 10/100/1000Base-T(X)
Network - Ethernet interface type - Gigabit Ethernet
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 10
Network - Ethernet LAN data rates - 100
Network - Ethernet LAN data rates - 1000 Mbit/s
Network architecture - GigabitEthernet
Networking > PoE in - 802.3af/at
Operational conditions > Operating temperature (T-T) - -40°C to 70°C °C
Other features - Architektura: MMIPS Procesor: MT7621A Liczba rdzeni procesora: 2 Częstotliwość nominalna procesora: 880 MHz Liczba wątków procesora: 4 Licencja RouterOS: 4 System operacyjny: RouterOS Rozmiar pamięci RAM: 256 MB Rozmiar pamięci: 16 MB Typ pamięci: FLASH MTBF: około 100 000 godzin w 25C
Other features > Ethernet LAN (RJ-45) ports - 5
Other features > USB ports quantity - 1
Other features > Wi-Fi - No
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 170.00 mm
Package features > Gross height (mm) - 45.00 mm
Package features > Gross width (mm) - 120.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 941 pc(s)
Package features > Paper/Pasteboard - 208 g
Package features > Plastic (No PET) - 23 g
Package features > Tare weight (kg) - 0.231 kg
Package features > Volume (m3) - 0.00 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
Packaging content > AC adapter included - Yes (24V 1.2A power adapter)
Packaging content > Memory card included - Yes (microSD)
PDF - http://www.blobs.lt/products/5/4/2/8/2/2/4776d4a7930ca181063fbc0e819be0eb/original.pdf
PDF - http://www.blobs.lt/products/5/4/2/8/2/2/60396f74599ef836714b28aacad4299a/original.pdf
PDF - http://www.blobs.lt/products/5/4/2/8/2/2/bf1de351c5d382d002c26bc815029915/original.pdf
Performance > Ethernet LAN data rates - 10/100/1000 Mbit/s
Performance > Internal memory - 256 MB
Performance > Memory type - Flash
Performance > Processor cores - 2
Performance > Processor frequency - 880 MHz
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 5
Ports & interfaces - Installed SFP modules quantity - 1
Ports & interfaces - Power over Ethernet (PoE) ports quantity - 1
Ports & interfaces - USB ports quantity - 1
Power - Power consumption (typical) - 11 W
Power - Power source type - DC
Power > Power consumption (max) - 24 W
Power > Voltage - (PoE in input Voltage) 12-57 V
Power consumption (typical) Power - 11 W
Power over Ethernet (PoE) ports quantity Ports & interfaces - 1
Power source type Power - DC
Power supply - Liczba wejść DC: 2 (gniazdo DC, PoE-IN) Napięcie wejściowe gniazda DC: 12-57 V Maksymalny pobór mocy: 24 W Maksymalny pobór mocy bez załączników: 6 W FAN count: Passive Wejście PoE: 802.3af/at Napięcie wejściowe PoE: 12-57 V
Pozostałe cechy: Obsługa kart pamięci - microSD
Pozostałe cechy: Wymiary - 113 x 89 x 28 mm
Pozostałe cechy: Zasilanie - PoE
Pozostałe cechy: Zasilanie - zasilacz AC
Praca przewodowa: Interfejsy LAN - RJ45
Praca przewodowa: Interfejsy WAN - 1 x SFP
Praca przewodowa: Liczba portów LAN 10/100/1000 - 5 szt.
Praca przewodowa: Liczba portów WAN - 1 szt.
Praca przewodowa: Wbudowany przełącznik [switch] - tak
Praca przewodowa: Złącza - 1 x SFP
Praca przewodowa: Złącza - 1 x USB 2.0
Praca przewodowa: Złącza - 5 x RJ45
Processor > Processor model - MT7621A
producer - Mikrotik
Producer - MikroTik
producerCode - RB760iGS
ProducerCode - RB760iGS
Producer product family - Enthernet Router hEX S
Producer product name - RB760iGS
Product colour Design - Black
productName - Mikrotik hEX S wired router Gigabit Ethernet Black
Product Net Weight ELKO Logistics Data - 0.32 kg
productSize - Normal
Safety warning - Warnings - Do not open the appliance - risk of electric shock.
Safety warning - Warnings - Do not use in damp conditions.
Safety warning - Warnings - Make sure the unit is stably mounted and ventilated.
Security -
Shipping Box Depth ELKO Internal Logistics Data - 52 cm
Shipping Box Height ELKO Internal Logistics Data - 42 cm
Shipping Box Weight ELKO Internal Logistics Data - 14 kg
Shipping Box Width ELKO Internal Logistics Data - 28 cm
ShortDescription -
sizeX - 170
sizeY - 120
sizeZ - 50
Software -
Special functions -
Standards - 802.3af
Standards - 802.3at
Summary - Mikrotik hEX S. Ethernet interface type: Gigabit Ethernet, Cabling technology: 10/100/1000Base-T(X), Ethernet LAN data rates: 10,100,1000 Mbit/s. Internal memory: 256 MB. Product colour: Black. Power consumption (typical): 11 W, Power source type: DC. Width: 113 mm, Depth: 89 mm, Height: 28 mm
System Requirements -
Technical details > Net weight - 0.20 kg
Technical details > Other features - hEX S is a five port Gigabit Ethernet router for locations where wireless connectivity is not required. Compared to the hEX, the hEX S also features an SFP port and PoE output on the last port. It is affordable, small and easy to use, but at the same time comes with a very powerful dual core 880 MHz CPU and 256 MB RAM, capable of all the advanced configurations that RouterOS supports. The device has a USB 2.0, PoE output for Ethernet port #5 and a 1.25Gbit/s SFP cage. The port #5 can power other passive PoE capable devices with the same voltage as applied to the unit IPsec hardware encryption (~470 Mbps) and The Dude server package is supported, microSD slot on it provides improved r/w speed for file storage and Dude.
Technical details > Producer - MikroTik
Technical details > Software type - RouterOS L4
Technical details > Warranty - 12 month(s)
title - MikroTik hEX S
title_en - MikroTik hEX S RB760iG Gigabit Ethernet Router (1xSFP 1xWAN 4xLAN)
title_lv - MikroTik hEX S RB760iG Gigabit Ethernet Router (1xSFP 1xWAN 4xLAN)
title_ru - MikroTik hEX S RB760iG Gigabit Ethernet Router (1xSFP 1xWAN 4xLAN)
Type - xDSL
Unit Box Height - 0.12
Unit Box Length - 0.18
Unit Box Width - 0.05
Unit Calculated Volume ELKO Internal Logistics Data - 0.001529 cubm
Unit Calculated Weight ELKO Logistics Data - 0.35 kg
Unit Depth ELKO Logistics Data - 18 cm
Unit Height ELKO Logistics Data - 12 cm
Units per Shipping Box ELKO Logistics Data - 40
Unit Width ELKO Logistics Data - 5 cm
USB ports quantity Ports & interfaces - 1
Vendor Homepage - https://mikrotik.com/product/hex_s#fndtn-gallery
vendpn - RB760iGS
WAN connection - Ethernet WAN - Yes
Warranty - 12
Warranty - 12 months
warrantyLength - 12
warrantyType - G
weight - 0.12 kg
weight - 0.41 kg
Weight - 0.351
weight - 375
Weight & dimensions - Depth - 89 mm
Weight & dimensions - Height - 28 mm
Weight & dimensions - Width - 113 mm
width - 0.12 m
Width Weight & dimensions - 113 mm
Wireless LAN features > Wi-Fi band - No Wi-Fi
