Asus Prime AP201, Black

2.5"/3.5" Internal Drive Bays - 3
2.5" Internal Drive Bays - 1
Accessories included -
Brand - ASUS
BrandPartCode - 90DC00G0-B39000
Case Type - MiniTower
category - Cases & Modding|PC Cases|Mini Cases|Micro-ATX Cases
Category - Computer Cases
Category - Datortehnika :: Datoru komponentes :: Korpusi
Category - Root/Electronics/PC parts/Computer casings
Category Code - CAS
Category_1 - Computer Cases and Cooling
Category_2 - Computer Cases
Chassis type - Mini Tower
Chłodzenie: Możliwość montażu - 3 wentylatory 120mm
Chłodzenie: Obsługiwane radiatory - 120mm
Chłodzenie: Obsługiwane radiatory - 140mm
Chłodzenie: Obsługiwane radiatory - 240mm
Chłodzenie: Obsługiwane radiatory - 280mm
Chłodzenie: Obsługiwane radiatory - 360mm
Chłodzenie: Zainstalowane komponenty - 1 wentylator 120mm
Code - 90DC00G0-B39000
code - 90DC00G0-B39000
Color - Black
Colour - Black
Computer case backlight - No
Cooling & Ventilation System - Top: 3 x 120 mm; 2 x 140 mm, Rear: 1 x 120 mm, Pre-installed Fans (Rear): 1 x 120 mm
Cooling - Rear fans diameters supported - 120 mm
Cooling - Rear fans installed - 1x 120 mm
Cooling - Rear radiator sizes supported - 120 mm
Cooling - Top fans installed - 3x 120 mm, 2x 140 mm
Cooling - Top radiator sizes supported - 120
Cooling - Top radiator sizes supported - 120,140,240,280,360 mm
Cooling - Top radiator sizes supported - 140
Cooling - Top radiator sizes supported - 240
Cooling - Top radiator sizes supported - 280
Cooling - Top radiator sizes supported - 360 mm
Dane fizyczne: Głębokość - 350 mm
Dane fizyczne: Szerokość - 205 mm
Dane fizyczne: Waga - 5.8 kg
Dane fizyczne: Wysokość - 460 mm
Dane techniczne: Gwarancja - 2 lata w serwisie sprzedawcy
Dane techniczne: Kolor - czarny
Dane techniczne: Panel boczny - zabudowany
Dane techniczne: Producent - Asus
Dane techniczne: Standard - micro-ATX
Dane techniczne: Standard - mini-ITX
Dane techniczne: Typ obudowy - Mini Tower
Desc - Korpusa tips: Mini Tower (mATX), Barošanas bloks: Nav, Krāsa: Melna, Materiāls: Metāls, 5.25” sloti: Nav, 3.5” sloti: 3, 2.5” sloti: 1, Audio ieeja: Ir, Audio izeja: Ir, USB 2.0: Nav, USB 3.0: 2, USB 3.2: 0, USB Type-C: 1, Garantija: 2 gadi
Description - Prime AP201 Mesh MicroATX Case Filter-like mesh panels: Mesh design with over 57,000 precision-machined 1.5mm holes increases airflow and provides a clear view of your system components. Optimized for cooling: With support for 280mm and 360mm radiators and up to six fans, the AP201 can handle the extreme heat of your highest-performing components. Industry-leading space efficiency: Despite only having 33L of volume, the AP201 supports ATX PSUs up to 180mm long, graphics cards up to 338mm long, custom liquid cooling systems, and a variety of storage drives. Tool-free side panels: Simple yet secure latching mechanism allows for easy removal of the cases side panels, and eliminates the risk of them accidentally coming loose. Ample Cable Management Space: AP201 is equipped with an enlarged motherboard tray with practical cutouts and a 32mm hole for hiding cables. USB Type-C Support on Front Panel: AP201 is equipped with a USB 3.2 Gen 2 Type-C port on the front panel, allowing users to enjoy transfer speeds of up to 10Gbps.
Description - The ASUS Prime AP201 is a stylish 33-liter MicroATX case with tool-free side panels and a quasi-filter mesh, with support for 360 mm coolers, graphics cards up to 338 mm long, and standard ATX PSUs. Quasi-Filter Mesh Panels: A mesh design comprised of over 57,000 precision-machined 1.5mm holes increases airflow and provides a compelling view of the components within your build. Optimized for Cooling: With support for 280 and 360mm radiators and up to six fans, the AP201 is primed to deal with the thermal onslaught of high-performance hardware. Industry-Leading Spatial Efficiency: Despite a 33L footprint, the AP201 supports ATX PSUs up to 180 mm long, graphics cards up to 338 mm long, custom liquid cooling, and various storage devices. Tool-Free Side Panels: A simple yet secure clip mechanism allows chassis side panels to be easily removed and resistant to accidental dislodging. Sizeable Cable-Management: The AP201 features an extended motherboard tray with strategically placed cutouts and a 32 mm gap to tuck cables out of sight. Front Panel USB Type-C® Support: The front panel of the AP201 features a USB 3.2 Gen 2 Type-C port, so users can enjoy transfer speeds of up to 10 Gbps.
Design - Anti-dust filter - Yes
Design - Cable management - Yes
Design - Form factor - Mini Tower
Design - Illumination - No
Design - Maximum CPU cooler height - 17 cm
Design - Maximum graphics card length - 33.8 cm
Design - Maximum PSU length - 18 cm
Design - Number of 2.5" bays - 1
Design - Number of 3.5" bays - 3
Design - Number of expansion slots - 4
Design - Number of internal 3.5" bays - 3
Design - Product colour - Black
Design - Side window - No
Design - Supported motherboard form factors - micro ATX
Design - Supported motherboard form factors - micro ATX, Mini-ITX
Design - Supported motherboard form factors - Mini-ITX
Design - Type - PC
Designation - CE+WEEE
Design features - Max GPU Length 338 mm; PSU Length 140-180 mm
dimensionalWeight - 12592
dimension depth - 440 mm
dimension height - 530 mm
Dimensions - 205 x 350 x 460 mm
dimension weight - 6500 g
dimension width - 270 mm
Drive bays 2.5'' extern. - 0
Drive bays 2.5'' intern. - 4
Drive bays 3.5'' extern. - 0
Drive bays 3.5'' intern. - 3
Drive bays 5.25'' extern. - 0
Drive bays 5.25'' intern. - 0
EAN - 4711081771821
ean - 4711081771821
Eans - 4711081771821
EAN_code - 4711081771821
Fans installed - 1 x 120 mm (back)
Form-factor - Micro ATX
Form-factor - Mini ITX
Front panel connectors - 1 x headphones
Front panel connectors - 1 x UB1 x USB 3.2 Gen 2 Type-CavS 3.2 Gen 2 Type-C
Front panel connectors - 1x microphone
Front panel connectors - 2 x USB 3.2 Gen1
Full Description Line - Prime AP201|Max GPU Length 338 mm; PSU Length 140-180 mm|MiniTower|PSU Not included|Top: 3 x 120 mm; 2 x 140 mm, Rear: 1 x 120 mm, Pre-installed Fans (Rear): 1 x 120 mm|Dimensions 205 x 350 x 460 mm
GTIN - 0195553771825
GTIN - 195553771825
GTIN - 4711081771821
guarantee - 24
guarantee_type - normal
Headphones jack Input/Output connectors - 1
ImageUrl - https://www.balticdata.lv/Gfx/ProductImages/Info/Product_104045_1.jpg
Kieszenie na dyski: Ilość kieszeni 2.5 wewn. - 1 szt.
Kieszenie na dyski: Ilość kieszeni 3.5 wewn. - 3 szt.
LargeDescHTML -
LongDesc - The ASUS Prime AP201 is a stylish 33-liter MicroATX case with tool-free side panels and a quasi-filter mesh, with support for 360 mm coolers, graphics cards up to 338 mm long, and standard ATX PSUs.GO BIG. STAY COMPACT.33-LITERS OF COOL​The ASUS Prime AP201 is a breakthrough in microATX chassis design, delivering a high-performance platform that invites 360 mm AIO coolers and graphics cards up to 338 mm long, all within a compact 33-liter space. Tool-free side panels with a quasi-filter mesh also provide easy access and enhanced airflow, and they complete a tasteful, minimalist aesthetic that can be the centerpiece of any DIY PC build.QUASI-FILTER MESH PANELSBREATHE FREELYThe AP201 mesh design is comprised of over 57,000 precision-machined 1.5mm holes, structured to increase airflow, reduce dust ingress, and collectively provide a compelling view of the components within your build.OPTIMIZED FOR COOLINGSTAY CHILLEDWith support for 280 and 360mm radiators and up to 6 fans, the AP201 is primed to deal with the thermal onslaught of high-performance hardware.REMOVABLE DUST FILTERSPECS, NOT SPECKSThe two 120 mm fan mounts at the bottom of the AP201 include a dust filter that can be removed for easy cleaning, or to enhance airflow even further.INDUSTRY-LEADING SPATIAL EFFICIENCYLOAD UPDespite its compact size, the AP201 supports standard ATX power supplies up to 180 mm long, graphics cards up to 338 mm long, custom liquid cooling setups, and a spread of storage devices.TOOL-FREE SIDE PANELSUNRESTRICTED ACCESSInstead of making you wrestle with screws or potentially awkward hinges, the side panels of the AP201 both use a simple but secure clip mechanism to attach to the case. This makes them easy to remove when you want to access the interior of the chassis, and resistant to being accidentally dislodged.SIZEABLE CABLE-MANAGEMENTTIDY AS YOU LIKEThe AP201 features an extended motherboard tray with strategically placed cutouts and a 32 mm gap, giving builders ample room to tuck cables out of sight and create a clean aesthetic for their DIY PC.FRONT PANEL USB TYPE-C SUPPORTNIMBLE CONNECTIONSIn addition to two Type-A USB 3.2 Gen 1 ports, the front panel of the AP201 also features a Type-C port that is rated for USB 3.2 Gen 2. Compatible microATX ASUS motherboards such as the TUF Gaming B660M Plus or ROG STRIX B660-G can use this port to enjoy transfer speeds of up to 10 Gbps.AVAILABLE IN TWO COLORSCHOOSE YOUR ALLEGIANCEThe AP201 is available in either black or white, giving you options to create a rig that blends in or stands out.
LongProductName - Prime AP201 MicroATX Case, 33 l, Black
LongSummaryDescription - ASUS PRIME AP201 MicroATX. Form factor: Mini Tower, Type: PC, Product colour: Black. Supported power supply form factors: ATX. Rear fans installed: 1x 120 mm, Rear fans diameters supported: 120 mm, Top fans installed: 3x 120 mm, 2x 140 mm. Width: 205 mm, Depth: 350 mm, Height: 460 mm
Manufacturer - Asus
Manufacturer_code - 90DC00G0-B39000
Maximum CPU cooling height - 170 mm
Maximum length of the graphics card - 338 mm
Maximum length of the power supply - 180 mm
Maximum number of fans - 4
MicroATX Mainboard Form Factor - Yes
Microphone jack 3.5mm Input/Output connectors - 1
MiniITX Mainboard Form Factor - Yes
Model name - Prime AP201
Name - ASUS AP201 ASUS PRIME CASE, tower case (black)
Name - ASUS PRIME AP201
name - ASUS Prime AP201 Micro-ATX Gehäuse - schwarz
Name - Korpuss Asus AP201 Prime Melns
name - Pc case Prime AP201 Mesh MicroATX black
No. of drive bays - 4
Number of expansion slots - 4
Number of fans installed - 1
Number of slots for expansion cards - 4
Ooptional water cooling - 1 x 120 mm (back)
Ooptional water cooling - 1 x 120 mm (top)
Ooptional water cooling - 1 x 140 mm (top)
Ooptional water cooling - 1 x 240 mm (góra)
Ooptional water cooling - 1 x 280 mm (góra)
Ooptional water cooling - 1 x 360 mm (top)
Optional fans - 1 x 120 mm (back)
Optional fans - 3 x 120 mm or 2 x 140 mm (top)
Other features -
Panel przedni: Złącza na przednim panelu - 1 x USB 3.2 Gen 2 (Typ-C)
Panel przedni: Złącza na przednim panelu - 2 x USB 3.2 Gen 1
Panel przedni: Złącza na przednim panelu - audio
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 2
Ports & interfaces - USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity - 1
Power supply - Failure
Power supply - Supported power supply form factors - ATX
Pozostałe cechy: Model - ASUS AP201 PRIME
Producent: Nazwa producenta / importera - AsusASUS COMPUTER GmBHHARKORT STR. 21-2340880 RATINGENEmail: https://www.asus.com/support/Product/ContactUs/Services/questionform/?lang=en&utm_source=asus-qr&utm
producer - Asus
Producer - Asus
producerCode - 90DC00G0-B39000
ProducerCode - 90DC00G0-B39000
ProductName - AP201 MicroATX
productName - ASUS Prime AP201 MicroATX Mini Tower Black
Product Net Weight - 5.8 kg
productSize - Normal
Przestrzeń na komponenty: Maksymalna długość karty graficznej - 338 cm
Przestrzeń na komponenty: Maksymalna wysokość chłodzenia - 17 cm
PSU - Not included
Shipping Box Depth Shipping/Package Box Dimensions - 52.5 cm
Shipping Box Height Shipping/Package Box Dimensions - 44.5 cm
Shipping Box Weight Shipping/Package Box Dimensions - 7.3 kg
Shipping Box Width Shipping/Package Box Dimensions - 27.5 cm
ShortDescription - Micro ATX | czarna | bez zasilacza | 2 x USB 3.2 | 205mm x 350mm x 460mm |
ShortSummaryDescription - ASUS PRIME AP201 MicroATX, Mini Tower, PC, Black, micro ATX, Mini-ITX, 17 cm, 33.8 cm
Side panel - Metal fence
sizeX - 530
sizeY - 440
sizeZ - 270
Title - ASUS PRIME AP201 MicroATX Mini Tower Black
Unit Calculated Volume - 0.0642469 cubm
Unit Calculated Weight - 7.3 kg
Units per Shipping Box - 1
URL - https://www.asus.com/Motherboards-Components/Gaming-Cases/PRIME/ASUS-Prime-AP201-MicroATX-Case/
USB-C Input/Output connectors - 1
USB 3.2 Input/Output connectors - 2
Vendor Homepage - www.asus.com/Motherboards-Components/Gaming-Cases/PRIME/ASUS-Prime-AP201-MicroATX-Case/
vendpn - 90DC00G0-B39000
Warranty - 24 months
WarrantyInfo -
warrantyLength - 36
warrantyType - G
Weight - 5.8 kg
Weight - 7,35
weight - 6500
Weight & dimensions - Depth - 350 mm
Weight & dimensions - Height - 460 mm
Weight & dimensions - Weight - 5.8 kg
Weight & dimensions - Width - 205 mm
Zasilacz: Wbudowany zasilacz - brak w komplecie
