ARTIKEL1 - 52-PORT SMART MGD POE+GB SWITCH
ARTIKEL2 -
Brand - D-Link
BrandPartCode -
Category - Network Switches
-
-
-
-
Certificates - Certification - CB, UL, BSMI, CCC
Data transmission - Forwarding rate - 130.95 Mpps
Data transmission - Jumbo frames - 12000
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 32000 entries
Data transmission - Number of static routes - 124
Data transmission - Packet buffer memory - 16 MB
Data transmission - Static route - Yes
Data transmission - Switching capacity - 176 Gbit/s
Design - Electromagnetic compatibility - CE A, VCCI A, FCC A, IC, BSMI
Design - LED indicators - Activity, Link, Power, Speed
Design - Product colour - Black
Design - Rack mounting - Yes
EAN -
EANCode -
-
- 5,2
GRUPPE1 - Network
GRUPPE2 - Switches Managed
GTIN -
GTIN - 790069467905
GTIN - 5704174940463
HERSTELLER - D-LINK
HSTNUMMER -
Logistics data - Harmonized System (HS) code -
LongDesc - Power & ValueThe D-Link DGS-1250 Series Smart Managed Switches deliver real value as an Enterprise Access and Small-to-Medium Business (SMB) Access/Aggregation solution. They provide a range of physical interfaces (including a Console Port w/full CLI), multiple management interfaces, 11 Web languages, QoS enablement, and Advanced Layer-2 w/Lite Layer-3 features. The DGS-1250 Series switches support 24 or 48 x 10/100/1000BASE-T ports, with each switch also supporting an additional 4 x 10G SFP+ ports for optical connections using multimode or single-mode SFP transceivers – enabling real network horsepower at a value price.Easy Maintenance, Less DowntimeThe DGS-1250 Series supports Dual Image and Dual Configuration functionality, as well as a Console Port, all of which make it easier to configure, troubleshoot, and make other changes without interfering with network operation, while full Command Line Interface (CLI) functionality enables remote configuration, without the need for the Internet. And if a network issue ever does occur, the supported Spanning Tree Protocols (STP/RSTP/MSTP) help keep things running without interruptions or downtime.Automatic ConfigurationThe DGS-1250 Series supports Auto Voice VLAN and Surveillance Mode, which allow Voice and Video traffic to be automatically identified and handled differently from regular network traffic. Auto Voice VLAN detects Voice over IP (VoIP) traffic and automatically segments it from the rest of the network, increasing security and allowing Quality of Service (QoS) to be applied.High PoE Budget (370W)The DGS-1250 series offers Power-over-Ethernet (PoE), which simplifies deployment of IP cameras, VoIP phones, Wireless Access Points, and other powered devices. Using the switch’s management interface, an administrator can control various PoE functions, such as remotely rebooting Cameras or Access Points, from anywhere on the network, including over the Internet. All PoE models support the IEEE 802.3af and 802.3at standards.Extensive Management and Advanced FeaturesThe DGS-1250 Series comes with IGMP snooping, Port Mirroring, Spanning Tree Protocol (STP), and Link Aggregation Control Protocol (LACP). The IEEE 802.3x Flow Control function allows servers to directly connect to the switch for fast, reliable data transfers. The series also supports advanced features such as Static Routing, which allows for communication between different user groups in different VLAN segments in a network.
LongProductName - 52-Port 10-Gigabit Smart Managed PoE Switch
LongSummaryDescription - D-Link 48-port Gigabit Smart Managed Switch with 4 x 10G SFP+, 370Watts. Switch type: Managed, Switch layer: L3. Basic switching RJ-45 Ethernet ports quantity: 48, Console port: RJ-45. MAC address table: 32000 entries, Switching capacity: 176 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE.... Power over Ethernet (PoE). Rack mounting
Management features - Cloud-managed - No
Management features - Configuring Location Settings (CLI) - Yes
Management features - MIB support - RFC2893, RFC4213, RFC4291, RFC2464, RFC2462, RFC4862, RFC2461, RFC4861, RFC2573, RFC1321, RFC2284, RFC2865, RFC2716, RFC3580, RFC826, RFC2463, RFC4443, RFC792, RFC793, RFC768, RFC791, RFC2389, RFC4113, RFC4022, RFC2618, RFC2674, RFC1398, RFC1643, RFC1650, RFC2358, RFC2665, RFC2021, RFC271, RFC1757, RFC2819, RFC1442, RFC1901, RFC1902, RFC1903, RFC1904, RFC1905, RFC1906, RFC1907, RFC1908, RFC2578, RFC3418, RFC2573, RFC2575, RFC2576, RFC1212, RFC1213, RFC1215, RFC1493, RFC1157, RFC2620,
Management features - Quality of Service (QoS) support - Yes
Management features - Switch layer - L3
Management features - Switch type -
Management features - System event log - Yes
Management features - Web-based management - Yes
Manufacturer - D-Link
-
- D-Link
-
MPN -
Multicast features - Multicast support - Yes
Name -
Name - D-Link DGS-1250-52XMP 52-Port Smart Mgd. PoE+ Gigabit Switch
Network - 10G support - Yes
Network - Auto MDI/MDI-X - Yes
Network - Broadcast storm control - Yes
Network - Flow control support - Yes
Network - Head-of-line (HOL) blocking - Yes
Network - Link aggregation - Yes
Network - Networking standards -
Network - Number of VLANs - 4094
Network - Spanning tree protocol - Yes
Network - Virtual LAN features - Voice VLAN
Network - VLAN support - Yes
Operational conditions - Heat dissipation - 1512.676 BTU/h
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - -5 - 50 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -20 - 70 °C
Packaging data - Package depth - 563 mm
Packaging data - Package height - 89 mm
Packaging data - Package weight - 5.17 kg
Packaging data - Package width - 393 mm
Performance - Flash memory - 64 MB
Performance - Internal memory - 2048 MB
Performance - Mean time between failures (MTBF) - 309053.1 h
Performance - Memory type - DDR3-SDRAM
Performance - Noise level - 51.2 dB
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 48
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - No
Ports & interfaces - Console port - RJ-45
Ports & interfaces - SFP+ module slots quantity - 4
Power - AC input voltage - 100 - 240 V
Power - Power consumption (max) - 467.3 W
Power - Power supply included - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) ports quantity - 48
Power over Ethernet (PoE) - Power over Ethernet (PoE) power per port - 15.4 W
Power over Ethernet (PoE) - Total Power over Ethernet (PoE) budget -
ProductName - D-Link 48-port Gigabit Smart Managed Switch with 4 x 10G SFP+, 370Watts
Security - Access Control List (ACL) - Yes
Security - Access Control List (ACL) rules - 768
Security - DHCP features -
Security - IGMP snooping - Yes
Security - IP-MAC-Port binding - Yes
Security - Loop protection - Yes
Security - Queue scheduling algorithms - Weighted Round Robin (WRR)
Security - Security algorithms -
ShortSummaryDescription - D-Link 48-port Gigabit Smart Managed Switch with 4 x 10G SFP+, 370Watts, Managed, L3, Power over Ethernet (PoE), Rack mounting
Stck_Kart - 1
Stck_Pal - 0
Storno -
Technical details - Master (outer) cases per pallet (air) - 16 pc(s)
Technical details - Master (outer) cases per pallet (sea) - 16 pc(s)
Technical details - Pallet gross length -
Technical details - Pallet gross weight (air) - 456.1 kg
Technical details - Pallet gross weight (sea) - 456.1 kg
Technical details - Pallet gross width - 120 cm
Technical details - Pallet height (air) - 184.7 cm
Technical details - Pallet height (sea) - 184.7 cm
Technical details - Products per pallet (air) - 80 pc(s)
Technical details - Products per pallet (sea) - 80 pc(s)
Technical details - Products per shipping (inner) case - 5 pc(s)
Technical details - Shipping (inner) case gross weight - 27.4 kg
Technical details - Shipping (inner) case height - 42.8 cm
Technical details - Shipping (inner) case length - 58.5 cm
Technical details - Shipping (inner) case net weight - 22.9 kg
Technical details - Shipping (inner) case width - 47.8 cm
Title - D-Link 48-port Gigabit Smart Managed Switch with 4 x 10G SFP+, 370Watts
URL - https://www.dlink.com/en/products/dgs-1250-52xmp-52-port-10-gigabit-smart-managed-poe-switch
WarrantyInfo -
Weight -
Weight & dimensions - Depth - 430 mm
Weight & dimensions - Height - 44 mm
Weight & dimensions - Weight -
Weight & dimensions - Width - 440 mm
