Teltonika TSW210, 8x1Gb 2SFP

10G support Network - No
Accessories included - TSW210 Quick start guide
Application - Home and small office
Auto-negotiation Network - Yes
Auto MDI/MDI-X Network - Yes
Basic switching RJ-45 Ethernet ports quantity Ports & interfaces - 8
Basic switching RJ-45 Ethernet ports type Ports & interfaces - Gigabit Ethernet (10/100/1000)
Category - Root/Electronics/Networks and communication/Switchers
Category Code - SWI
Certificates - CE/RED, UKCA, CB, UCRF, EAC, RoHS, REACH, ANRT, RCM, GITEKI, FCC, IC, NOM, E-mark
Chassis type - Desktop
Chassis type - Rack
Code - TSW210000040
Console port - No
Dane techniczne: Algorytm przełączania - store-and-forward
Dane techniczne: Bufor pamięci - 128 KB
Dane techniczne: Dodatkowe informacje - Switch przemysłowy w aluminiowej obudowie, Możliwość opcjonalnego montażu na szynie DIN - produkt dostarczany bez zestawu montażowego, Stopień ochrony IP30
Dane techniczne: Gwarancja - 2 lata w serwisie zewnętrznym
Dane techniczne: Głębokość - 95.1 mm
Dane techniczne: Liczba portów LAN 10/100/1000 - 8 szt.
Dane techniczne: Obsługiwane protokoły - IEEE 802.3
Dane techniczne: Obsługiwane protokoły - IEEE 802.3ab
Dane techniczne: Obsługiwane protokoły - IEEE 802.3az
Dane techniczne: Obsługiwane protokoły - IEEE 802.3u
Dane techniczne: Obsługiwane protokoły - IEEE 802.3x flow control
Dane techniczne: Producent - Teltonika
Dane techniczne: Prędkość magistrali wew. - 20 Gb/s
Dane techniczne: Rozmiar tablicy adresów MAC - 2000
Dane techniczne: Sloty SFP 1000 Mb/s - 2 szt.
Dane techniczne: Szerokość - 132 mm
Dane techniczne: Typ - niezarządzalny
Dane techniczne: Waga - 0.5 kg
Dane techniczne: Warstwa przełączania - 2
Dane techniczne: Wysokość - 44.2 mm
DC input voltage Power - 7 - 57 V
Depth Weight & dimensions - 95.1 mm
Description - TELTONIKA IOT SWITCH TSW210 8X GIGABIT PORT + 2X SFP M
Description - The TSW210 is an unmanaged industrial switch for centralizing your resources. Equipped with 2 SFP ports for long-range fiberoptic communication and 8 Gigabit Ethernet ports with of up to 1000 Mbps download/upload speed. Durable, rugged aluminum housing with DIN rail and surface mounting options make the TSW210 perfect for industrial settings.SFPETHERNETDURABILITYMOUNTING (DIN rail)
Description - TSW210 INDUSTRIAL ETHERNET SWITCH The TSW210 is an Ethernet switch offering a perfect combination of Gigabit Ethernet and SFP. Eight Ethernet ports allow you to quickly and easily connect multiple devices to the network, without the need for further configuration. SFP enables remote devices to be enabled while maintaining high speed and reliability.
Designation - CE+WEEE
dimension depth - 70 mm
dimension height - 175 mm
Dimensions - 132 x 44.2 x 95.1 mm
dimension weight - 605 g
dimension width - 150 mm
DIN rail mounting Design - Yes
EAN - 4779051843664
ean - 4779051843664
Eans - 4779051840243
Environment requirements - Operating temperature -40°C to 75°C Operating humidity 10% to 90%, non-condensing
Fan - No
Forwarding mode - Store-and-forward
guarantee - 24
guarantee_type - normal
Height - 50.000000
Height Weight & dimensions - 44.2 mm
Housing material Design - Aluminium
Installed SFP modules quantity Ports & interfaces - 2
International Protection (IP) code Design - IP30
Jumbo frames Data transmission - 9216
Jumbo frame size - 9216 KB
Jumbo frames support Data transmission - Yes
L2 features -
L3 features -
LED indicators Design - LAN, Power, Status
Length - 150.000000
Link - https://teltonika-networks.com/lt/produktai/sakotuvai/tsw210
MAC address table Data transmission - 2048 entries
MAC address table size - 2000
Management, monitoring, configuration -
Manufacturer - Teltonika
ManufacturerPartNumber - TSW210000040
Model - TSW210
Model name - TSW210000040
Name - Teltonika Switch 8 GbE, 2 SFP ports | TSW210
Name - Teltonika TSW210
name - TSW210 Switch 2xSFP 8xGbE DIN RAIL Back Panel
Network architecture - GigabitEthernet
Networking standards Network - IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Number of 10/100/1000 Mbps ports - 8
Number of SFP ports - 2
Operating relative humidity (H-H) Operational conditions - 10 - 90%
Operating temperature (T-T) Operational conditions - -40 - 75 °C
Other features -
Other functions -
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 148 mm
Package features > Gross height (mm) - 71 mm
Package features > Gross width (mm) - 173 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 475 pc(s)
Package features > Paper/Pasteboard - 100.00 g
Package features > Plastic (No PET) - 20.00 g
Package features > Tare weight (kg) - 0.12 kg
Package features > Volume (m3) - 0.001817884 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
Packet buffer - 128 KB
Packet buffer memory Data transmission - 128 MB
PeriodofWarranty - 2 Y
Ports & interfaces > Predominant port type - 10/100/1000 Mbps (RJ-45)
Power consumption - 3.71 W
Power consumption (max) Power - 3.71 W
Power consumption (typical) Power - 1.03 W
Power over Ethernet (PoE) Power over Ethernet (PoE) - No
Power source Power - DC
Power supply - 2 pin industrial DC power socket
Power supply - Internal
Power supply included Power - No
Producent: Nazwa producenta / importera - Teltonika
Teltonika Networks
K. Baršausko st. 66
LT-51436 Kaunas

producer - TELTONIKA
Producer - Teltonika
ProducerCode - TSW210
Product colour Design - Aluminium
QoS -
Rack mounting Design - No
Security - IP30 protection level
ShortDescription - Teltonika TSW210 Switch przemysłowy, 8x Gigabit RJ45, 2x SFP, aluminiowa obudowa
Stackable Design - No
Summary - Teltonika TSW210. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8, Installed SFP modules quantity: 2. MAC address table: 2048 entries, Switching capacity: 20 Gbit/s. Networking standards: IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x. DC input voltage: 7 - 57 V. Wall mountable
Supported protocols and standards -
Support for Jumbo frames - Yes
Switch class - Unmanaged
Switching capacity Data transmission - 20 Gbit/s
Switch type Management features - Unmanaged
Technical details > Gross weight - 0.62 kg
Technical details > Net weight - 0.5 kg
Technical details > Producer - Teltonika
Technical details > Producer product family - Switch 8 GbE, 2 SFP ports
Technical details > Producer product name - TSW210
Throughput - 20 Gb/s
Unit Box Height - 0.148
Unit Box Length - 0.17
Unit Box Width - 0.07
Unit Calculated Volume - 0.001761 cubm
Unit Calculated Weight - 0.6 kg
Units per Shipping Box - 1
Vendor Homepage - https://teltonika-networks.com/product/tsw210/
vendpn - TSW210000040
VLAN -
Wall mountable Design - Yes
Warranty - 24
Warranty - 24 month(s)
Warranty - 24 months
Weight - 0.520000
Weight - 500 g
Weight Weight & dimensions - 500 g
Width - 113.000000
Width Weight & dimensions - 132 mm
