10G support Network - Yes
Access Control List (ACL) rules Security - 10
Access Control List (ACL) Security - Yes
Accessories included -
AC input frequency Power - 50 - 60 Hz
AC input voltage Power - 100 - 240 V
Application - Medium and large companies
Basic switching RJ-45 Ethernet ports quantity Ports & interfaces - 48
Basic switching RJ-45 Ethernet ports type Ports & interfaces - Gigabit Ethernet (10/100/1000)
brand - Ubiquiti
Broadcast storm control Network - Yes
category - Mājas un biroju tīkli > Komutatori > PoE komutatori
Category - Root/Electronics/Networks and communication/Switchers
Category 1 - Netzwerk
Category 2 - Switching Hubs
Category Code - SWI
Category_1 - Network and Servers
Category_2 - Network - Switches and Hubs
Certification Certificates - CE, FCC, IC
Chassis type - Rack
Console port - Yes
Console port Ports & interfaces - RJ-45
Copper ethernet cabling technology Network - 10BASE-T, 100BASE-TX, 1000BASE-T
Dane techniczne: Dodatkowe informacje - maksymalny pobór mocy 500W
Dane techniczne: Gwarancja - 1 rok w serwisie sprzedawcy
Dane techniczne: Głębokość - 348 mm
Dane techniczne: Liczba portów LAN 10/100/1000 - 48 szt.
Dane techniczne: Obsługiwane protokoły - IEEE 802.3af
Dane techniczne: Obsługiwane protokoły - IEEE 802.3at
Dane techniczne: Port konsolowy - 1 szt.
Dane techniczne: Porty PoE - 48 szt.
Dane techniczne: Producent - Ubiquiti
Dane techniczne: Przeznaczenie - do szaf RACK 19"
Dane techniczne: Prędkość magistrali wew. - 140 Gb/s
Dane techniczne: Sloty SFP+ 10G - 2 szt.
Dane techniczne: Sloty SFP 1000 Mb/s - 2 szt.
Dane techniczne: Szerokość - 485 mm
Dane techniczne: Typ - zarządzalny
Dane techniczne: Waga - 5.3 kg
Dane techniczne: Warstwa przełączania - 3
Dane techniczne: Wysokość - 45 mm
Depth Weight & dimensions - 347.6 mm
Description - - Non-Blocking Throughput Switching Performance
- Gigabit Ethernet RJ45 and SFP+/SFP Ports
- Auto-Sensing IEEE 802.3af/at PoE Advanced Switching Technology for the Masses
Build and expand your network with Ubiquiti Networks® EdgeSwitch™, part of the EdgeMAX® line of products. The EdgeSwitch is a fully managed, PoE+ Gigabit switch, delivering robust performance and intelligent switching for growing networks. The EdgeSwitch offers an extensive suite of advanced Layer-2 switching features and protocols, and also provides Layer-3 routing capability. Switching Performance
The EdgeSwitch offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss. For its total, non-blocking throughput, the 24-port models support up to 26 Gbps, while the 48-port models support up to 70 Gbps. PoE+ Flexibility
The EdgeSwitch models are available with 24 or 48 PoE Gigabit Ethernet ports of auto-sensing IEEE 802.3af/at or configurable 24V Passive PoE to simplify your infrastructure. By default, the EdgeSwitch automatically detects 802.3af/at devices so they automatically receive PoE. For 24V Passive PoE devices, manually enable 24V passive PoE using the EdgeSwitch Configuration
Interface. Fiber Connectivity
The EdgeSwitch provides fiber connectivity options for your growing networks. The 24-port models include two SFP ports, providing up to 1 Gbps uplinks. For high-capacity uplinks, the 48-port models include two SFP and two SFP+ ports, providing up to 10 Gbps uplinks. Comprehensive User Interface
Designed for convenient management, the EdgeSwitch Configuration Interface allows administrators to configure and monitor switch features in a graphical user interface. For advanced users, an industry-standard command-line interface (CLI) is available through telnet and SSH. Powerful Functionality
The EdgeSwitch uses a sophisticated operating system that provides basic switching features, PoE configuration per port, and a variety of advanced features including:
- MSTP/RSTP/STP
- VLAN, Private VLAN, Voice VLAN
- Link Aggregation
- DHCP Snooping, IGMP Snooping
- TACACS+, RADIUS, 802.1X, MAC Filtering, ACL
- DiffServ, CoS
- Static Routing, Policy-Based Routing
Description - Managed PoE+ Gigabit Switch with SFP Available with 24 or 48 RJ45 Gigabit ports, the EdgeSwitch delivers robust performance, PoE+ support and intelligent switching for growing networks. Powerful Enterprise Switch Models
The EdgeSwitch delivers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss. Total non-blocking throughput: up to 26 Gbps for 24-port models and up to 70 Gbps for 48-port models. Enterprise-Class Features
The EdgeSwitch supports an extensive suite of advanced Layer-2 switching features and protocols, and also provides Layer-3 routing capability. Optical Fiber Backhaul
Two SFP ports support uplinks of up to 1 Gbps. For high-capacity uplinks, each 48-port model includes two SFP+ ports for uplinks of up to 10 Gbps. Breakthrough Value
The EdgeSwitch provides top price/performance value: a full-featured, enterprise-class switch starting at $199 USD MSRP. Convenient PoE+ Support
The EdgeSwitch features auto-sensing IEEE 802.3af/at and 24V passive PoE to power multiple devices on the network.
Designation - CE+WEEE
DHCP features Security - DHCP server, DHCP snooping
dimension depth - 570 mm
dimension height - 100 mm
Dimensions - 485 x 43.7 x 374.6 mm 1U
dimension weight - 7340 g
dimension width - 420 mm
ean - 810354022272
EAN - 0810354022272
Eans - 810354022272
EAN_code - 0810354022272
Fan - No
Flow control support Network - Yes
Form factor Design - 1U
Forwarding rate - 104.16 Mpps
Forwarding rate Data transmission - 104.16 Mpps
Gigabit Ethernet (copper) ports quantity Ports & interfaces - 48
Gross Weight Kg - 3,7
guarantee - 12
guarantee_type - normal
Harmonized System (HS) code Logistics data - 85176990
height - 0.142 m
Height Weight & dimensions - 44.5 mm
IGMP snooping Security - Yes
Jumbo frames support Data transmission - Yes
L2 features -
L3 features -
LED indicators Design - Activity, Link, PoE
length - 0.58 m
Link aggregation Network - Yes
MAC address filtering Security - Yes
MAC address table Data transmission - 16384 entries
Management, monitoring, configuration -
Management protocols Protocols - SNMP v1, v2, v3
Manufacturer - Ubiquiti
Manufacturer Code - ES-48-500W
Manufacturer Name - Ubiquiti Networks
Manufacturer_code - ES-48-500W
mpn - ES-48-500W
MPN - ES-48-500W
Multicast support Multicast features - Yes
Name - 48+2P UbiQuiti Networks ES-48-500W RM POE+
name - Switch 48x1GbE 2SFP 2SFP+ ES-48-500W
Name - UBIQUITI ES-48-500W
Name - Ubiquiti ES-48-500W PoE/GE/XG/MAN/48 - 48x PoE+, PoE Budget 500W
Network architecture - GigabitEthernet
Networking standards Network - IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Number of 10/100 Mbps ports - None
Number of 10/100/1000 Mbps ports - 48
Number of 10Gb ports - None
Number of COMBO ports - None
Number of PoE+ ports - None
Number of PoE ports (PoE & PoE+) - None
Number of QSFP+ ports - None
Number of queues Data transmission - 8
Number of SFP+ ports - 2
Number of SFP ports - 2
Number of VLANs Network - 4093
Operating relative humidity (H-H) Operational conditions - 5 - 95%
Operating temperature (T-T) Operational conditions - -5 - 40 °C
Other features -
Other functions -
Port mirroring Network - Yes
Power consumption - 500 W
Power consumption (typical) Power - 500 W
Power over Ethernet (PoE) Power over Ethernet (PoE) - Yes
Power supply - AC/DC, 500W DC
Power supply - Internal
Producent: Nazwa producenta / importera - Ubiquiti
BATNA SPÓŁKA Z OGRANICZONĄ ODPOWIEDZIALNOŚCIĄ
Olgi Boznańskiej 3e
42-202 producer - UBIQUITI
Producer - Ubiquiti
ProducerCode - ES-48-500W
Product colour Design - Black
QoS -
Quality of Service (QoS) support Management features - Yes
Rack mounting Design - Yes
Security -
SFP+ module slots quantity Ports & interfaces - 2
SFP module slots quantity Ports & interfaces - 2
ShortDescription -
Short description - Ubiquiti Switch EdgeSwitch 48xRJ45 GBit/2xSFP/2xSFP+ 500W PoE Managed 19" Rack-Mountable, Gigabit RJ45/SFP/SFP+ Ports
Spanning tree protocol Network - Yes
Stackability - Yes
Summary - Ubiquiti ES-48-500W. Switch type: Managed, Switch layer: L2/L3. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 48, Console port: RJ-45. MAC address table: 16384 entries, Switching capacity: 140 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE.... Power over Ethernet (PoE). Rack mounting, Form factor: 1U
Supported protocols and standards -
Switch class - Managed
Switching capacity Data transmission - 140 Gbit/s
Switch layer - L2
Switch layer Management features - L2/L3
Switch type Management features - Managed
Technical_details - 48x 1000Base-T (PoE+, 500W) 2x SFP+ 2x SFP Special features: rackmountable
Throughput - 70 Gb/s
title - Ubiquiti EdgeSwitch 48 500W
Unit Box Height - 0.42
Unit Box Length - 0.575
Unit Box Width - 0.095
Unit Calculated Volume - 0.03249 cubm
Unit Calculated Weight - 8.7 kg
Units per Shipping Box - 2
Vendor Homepage - https://www.ubnt.com/edgemax/edgeswitch/
vendpn - ES-48-500W EU
Virtual LAN features Network - Voice VLAN, Port-based VLAN
VLAN -
VLAN support Network - Yes
Warranty - 12 months
Web-based management Management features - Yes
Weight - 6.1 kg
Weight - 7,25
Weight - 7.32
weight - 8.8 kg
Weight Weight & dimensions - 5.3 kg
width - 0.42 m
Width Weight & dimensions - 485 mm
