Accessories included -
Application - Medium and large companies
ARTIKEL1 - 24 X 10G SFP+ PORTS + 4 X 10G
ARTIKEL2 - BASE-T PORTS SM SWITCH
Brand - D-Link
BrandPartCode - DXS-1210-28S
Category - Network Switches
Category 1 - Netzwerk
Category 2 - Switching Hubs
Category_1 - Network and Servers
Category_2 - Network - Switches and Hubs
Certificates - Certification - CE Class A
FCC Class A
VCCI Class A
IC
BSMI
Chassis type - Rack
Code - DXS-1210-28S
Console port - Yes
Data transmission - Jumbo frames - 9000
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 32000 entries
Data transmission - Store-and-forward - Yes
Data transmission - Switching capacity - 560 Gbit/s
Data transmission - Throughput - 416.64 Mpps
Description - Przełącznik zarządzalny Smart Ethernet D-Link DXS-1210-28S
Przełączniki DXS-1210 to przystępne cenowo urządzenia przeznaczone dla wielu sieciowych zastosowań w firmach o każdej wielkości.
Design - Form factor - 1U
Design - LED indicators - Activity, Link, Speed
Design - Number of fans - 2 fan(s)
Design - Product colour - Black
Design - Rack mounting - Yes
Design - Stackable - No
Design > Form factor - Rackmountable
Designation - CE+WEEE
dimension depth - 90 mm
dimension height - 570 mm
Dimensions - 441 x 209.5 x 44 mm
dimension weight - 4600 g
dimension width - 350 mm
EAN - 790069456817
ean - 790069456817
EAN - 0790069456817
EANCode - 0790069456817
EAN_code - 0790069456817
Fan - Yes
Forwarding mode - Store-and-forward
Forwarding rate - 416.64 Mbit/s
GRUPPE1 - Network
GRUPPE2 - Switches Managed
GTIN - 790069456817
GTIN - 0790069456817
guarantee - -1
guarantee_type - external
HERSTELLER - D-LINK
HSTNUMMER - DXS-1210-28S
Jumbo frame size - 12.288 KB
L2 features - Obejmują port mirroring, Spanning Tree Protocol (STP) oraz Link Aggregation Control Protocol (LACP).
L3 features - IP Interfaces, ARP, IPv6 Neighbor Discovery (ND), Default Routing and Static Routing.
Link - https://www.dlink.com/en/products/dxs1210-series-10-gigabit-ethernet-smart-managed-switches
Logistics data - Harmonized System (HS) code - 85176990
LongDesc - The DXS-1210-28T/28S 10 Gigabit Ethernet Smart Managed Switches are a cost-effective 10Gigabit switches capable of servicing a range of network needs in any business environment.The DXS-1210-28T is equipped with 4 x 10/25G SFP28 ports, enabling this series to serve aseither an aggregation/access switch in large enterprise environments or deployed at thecore of an SMB network. With high performance and low latency, these 10G smart-managedswitches fulfil the needs of virtualisation, cloud services, and server-to-server applications.The DXS-1210-28T/28S comes with a complete line-up of L2 features, including port mirroring,Spanning Tree Protocol (STP), and Link Aggregation Control Protocol (LACP). At the same time,inter-VLAN static routing helps by reducing the pressure of routers and backbone networks,improving overall network efficiency. The free D-Link Network Assistant utility allows multipleD-Link devices within the same L2 network to be discovered and managed. These switches alsoprovide management through the multi-lingual web UI, a full command-line interface (CLI)through Telnet, a console port, as well as D-View 7 Network Management System.
LongProductName - DXS-1210-28S - 24 x 10G SFP+, 4 x 10GBASE-T
LongSummaryDescription - D-Link DXS-1210-28S network switch Managed L2/L3 10G SFP+ (100/1000/10000) 1U Black. Switch type: Managed, Switch layer: L2/L3. Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000), Basic switching RJ-45 Ethernet ports quantity: 4, Console port: RJ-45. MAC address table: 32000 entries, Switching capacity: 560 Gbit/s. Networking standards: IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3u, IEEE 802.3z. Rack mounting, Form factor: 1U
MAC address table size - 32000
Management, monitoring, configuration -
Management features - Quality of Service (QoS) support - Yes
Management features - Switch layer - L2/L3
Management features - Switch type - Managed
Management features - Web-based management - Yes
Management features > Switch type - Managed L2
Manufacturer - D-Link
Manufacturer_code - DXS-1210-28S
MPN - DXS-11210-28S
Name - D-Link DXS-1210-28S, switch
Name - D-LINK DXS-1210-28S 10 Gigabit Ethernet Smart Managed Switches | D-Link | Gigabit Ethernet Smart Managed Switch | DXS-1210-28S | Managed L2 | Rackmountable
Name - D-Link DXS-1210-28S 24-Port 10G SFP+ Smart Managed Switch
name - DXS-1210-28S Switch Smart 24xSFP+ 4x10G
Network - 10G support - Yes
Network - Auto MDI/MDI-X - Yes
Network - Cable types supported - Cat6, Cat6a, Cat7
Network - Flow control support - Yes
Network - Link aggregation - Yes
Network - Networking standards - IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3u, IEEE 802.3z
Network - Number of VLANs - 4094
Network - Port mirroring - Yes
Network - Spanning tree protocol - Yes
Network - VLAN support - Yes
Network architecture - GigabitEthernet
Number of 10Gb ports - 24
Number of SFP+ ports - 24
Number of VLAN groups - 4000
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - -5 - 50 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -20 - 70 °C
Other features - 4x 10G BASE-T
Other functions -
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 440.00 mm
Package features > Gross height (mm) - 45.00 mm
Package features > Gross width (mm) - 212.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 294 pc(s)
Package features > Paper/Pasteboard - 290.00 g
Package features > Plastic (No PET) - 10.00 g
Package features > Tare weight (kg) - 0.30 kg
Package features > Volume (m3) - 0.00 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
Packaging content - Manual - Yes
Ports & interfaces - 10G Ethernet (copper) ports quantity - 4
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 4
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - 10G Ethernet (100/1000/10000)
Ports & interfaces - Console port - RJ-45
Ports & interfaces - SFP+ module slots quantity - 24
Ports & interfaces > POE - No
Ports & interfaces > Predominant port type - 10 Gbps (RJ-45)
Power - AC input voltage - 100 - 240 V
Power - Power consumption (max) - 85.7 W
Power consumption - 27.7 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - No
Power supply - 100 - 240 VAC
producer - D-Link
Producer product family - Gigabit Ethernet Smart Managed Switch
Producer product name - DXS-1210-28S
ProductName - DXS-1210-28S network switch Managed L2/L3 10G SFP+ (100/1000/10000) 1U Black
Protocols - GARP VLAN Registration Protocol (GVRP) - Yes
Protocols - Management protocols - SNMP v1/v2c/v3
QoS - 802.1p
Security -
Security - Access Control List (ACL) - Yes
Security - Access Control List (ACL) rules - 256
Security - IGMP snooping - Yes
ShortSummaryDescription - D-Link DXS-1210-28S network switch Managed L2/L3 10G SFP+ (100/1000/10000) 1U Black, Managed, L2/L3, 10G Ethernet (100/1000/10000), Rack mounting, 1U
Stck_Kart - 1
Stck_Pal - 0
Storno - N
Supported protocols and standards - IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3ab 1000BASE-T Gigabit Ethernet IEEE 802.3az Energy Efficiency Ethernet (EEE) IEEE 802.3an 10GBASE-T 10 Gigabit Ethernet IEEE 802.3ae 10GbE over fiber IEEE 802.3z 1000BASE-X Auto MDI/MDIX support for 1000/10GBASE-T
Support for Jumbo frames - Yes
Switch class - Managed
Switch class - SMART
Switch layer - L2
Switch layer - L3
Technical details > Gross weight - 3.40 kg
Technical details > Net weight - 3.10 kg
Technical details > Producer - D-Link
Throughput - 560 Gb/s
Title - D-Link DXS-1210-28S network switch Managed L2/L3 10G SFP+ (100/1000/10000) 1U Black
URL - https://www.dlink.com/en/
vendpn - DXS-1210-28S
VLAN - 802.1Q
Warranty - 60
Warranty - 60 month(s)
WarrantyInfo -
Weight - 3.27 kg
Weight - 4,50
Weight & dimensions - Depth - 209.5 mm
Weight & dimensions - Height - 44 mm
Weight & dimensions - Weight - 3.27 kg
Weight & dimensions - Width - 441 mm
