D-Link DGS‑1008P 8-Port Gigabit PoE Unmanaged Desktop Switch

Accessories included -
Application - Home and small office
ARTIKEL1 - 8-PORT 10/100/1000 LAYER2 POE
ARTIKEL2 - SWITCH 802.3AF
Brand - D-Link
BrandPartCode - DGS-1008P/E
Breite - 0.19
Category - Network Switches
Category - Root/Electronics/Networks and communication/Switchers
Category 1 - Netzwerk
Category 2 - Switching Hubs
Category_1 - Network and Servers
Category_2 - Network - Switches and Hubs
Chassis type - Rack
Code - DGS-1008P/E
Dane techniczne: Algorytm przełączania - store-and-forward
Dane techniczne: Grupa produktowa - Przełączniki D-link
Dane techniczne: Gwarancja - 2 lata w serwisie zewnętrznym
Dane techniczne: Głębokość - 38 mm
Dane techniczne: Liczba portów LAN 10/100/1000 - 8 szt.
Dane techniczne: Obsługiwane protokoły - IEEE 802.1p
Dane techniczne: Obsługiwane protokoły - IEEE 802.3
Dane techniczne: Obsługiwane protokoły - IEEE 802.3ab
Dane techniczne: Obsługiwane protokoły - IEEE 802.3af
Dane techniczne: Obsługiwane protokoły - IEEE 802.3i
Dane techniczne: Obsługiwane protokoły - IEEE 802.3u
Dane techniczne: Producent - D-link
Dane techniczne: Przeznaczenie - biurkowy
Dane techniczne: Rozmiar tablicy adresów MAC - 4000
Dane techniczne: Szerokość - 190 mm
Dane techniczne: Typ - niezarządzalny
Dane techniczne: Wysokość - 120 mm
Data transmission - MAC address table - 4000 entries
Data transmission - Switching capacity - 16 Gbit/s
Design - Form factor - Desktop
Design - LED indicators - Yes
Design - Product colour - Black
Design - Rack mounting - No
Design > Form factor - Desktop
Designation - CE+WEEE
dimensionalWeight - 1366
dimension depth - 330 mm
dimension height - 190 mm
Dimensions - 190 x 120 x 38 mm
dimension weight - 1758 g
dimension width - 110 mm
Download -
EAN - 790069344176
ean - 790069344176
EAN - 0790069344176
EANCode - 0790069344176
Eans - 790069344176
EAN_code - 0790069344176
Gewicht - 0.96
Gross Weight Kg - 1,57
GRUPPE1 - Network
GRUPPE2 - Switches Managed
GTIN - 790069344176
GTIN - 0790069344176
GTIN - 7900693441766
guarantee - 24
guarantee_type - external
HERSTELLER - D-LINK
HSTNUMMER - DGS-1008P/E
Link - https://eu.dlink.com/de/de/products/dgs-1008p-8-port-gigabit-poe-unmanaged-switch
LongDesc - The D-Link DGS-1008P offers an economical way for SOHO and small to medium businesses (SMB) to benefit from the increased bandwidth of Gigabit Ethernet It provides 8 Gigabit ports for fast server deployment to meet increasing network loads.Gigabit Connection for HomeThe D-Link DGS-1008P 8-Port Gigabit PoE Unmanaged Desktop Switch enables home and office users to easily connect and supply power to Power over Ethernet (PoE) devices such as wireless access points (APs), IP cameras, and IP phones.It also provides the opportunity to add additional Ethernet devices like computers, printers, and Network Attached Storage (NAS) onto a network. This compact PoE switch operates quietly, making it ideal for use in virtually any room or office.Auto MDI/MDIX CrossoverAll ports support automatic MDI/MDIX crossover, eliminating the need for crossover cables or uplink ports.Each port can be plugged directly to a server, hub, router, or switch using regular straight-through twisted-pair Ethernet cables.Conserve EnergyThe DGS-1008P makes use of D-Link GreenTM eco-friendly technology, providing energy savings, reduced power consumption, and a longer product life without sacrificing operational performance or functionality.This switch helps to conserve energy through methods such as Link Status and Cable Length Detection. The Link Status feature automatically powers down ports that have no link, allowing the switch to save substantial amounts of energy by cutting power for unused ports. It can also detect connected cable lengths, and adjust power usage accordingly. In addition, the fan-less design extends the product’s life and also reduces noise.Power Over Ethernet+The first four ports of the DGS-1008P support the IEEE 802.3at PoE protocol.Each of the four ports can supply up to 30 watts, for a total PoE budget of 68 watts, allowing users to attach an IEEE 802.3at-compliant device to the DGS-1008P that requires no additional power. Use PoE+ for applications that are far from power outlets or when you want to minimize the clutter of extra cables.Compact and SilentThe compact design of the DGS-1008P allows placement in most locations, including those where space is at a premium.The desktop form factor provides everything you need to set up a new network or expand an existing network, while the fanless design ensures silent operation even in noise-sensitive workstations and meeting rooms.
LongProductName - 8-Port Gigabit Ethernet PoE Switch, 16 Gbits, MDI/MDIX
LongSummaryDescription - D-Link 8-Port Gigabit PoE Unmanaged Desktop Switch. Switch type: Unmanaged, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8. Full duplex. MAC address table: 4000 entries, Switching capacity: 16 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x. DC input voltage: 9 - 54 V. Power connector: DC-in jack. Power over Ethernet (PoE). Form factor: Desktop
MAC address table size - 4000
Management features - ARP inspection - Yes
Management features - Configuring Location Settings (CLI) - Yes
Management features - Quality of Service (QoS) support - Yes
Management features - Switch layer - L2
Management features - Switch type - Unmanaged
Management features - Web-based management - Yes
Management features > Switch type - Unmanaged
Manufacturer - D-Link
Manufacturer Code - DGS-1008P/E
Manufacturer Name - D-Link
Manufacturer_code - DGS-1008P/E
Memory buffer - 192 KB
MPN - DGS-1008P/E
Name - 8P D-Link DGS-1008P/E Metall PoE+
Name - D-Link DGS-1008P
Name - D-Link DGS-1008P PoE 1000/UNM/ 8
name - D-link switch 8-port 10/100/1000Gigabit Meta
Name - D-Link | 8-Port Gigabit PoE Switch (4xPoE) | DGS-1008P | Unmanaged | Desktop | Power supply type External
Network - 10G support - No
Network - Auto MDI/MDI-X - Yes
Network - Copper ethernet cabling technology - 10BASE-T
Network - Copper ethernet cabling technology - 100BASE-TX
Network - Copper ethernet cabling technology - 1000BASE-T
Network - Copper ethernet cabling technology - 1000BASE-T, 100BASE-TX, 10BASE-T
Network - Full duplex - Yes
Network - Networking standards - IEEE 802.1p
Network - Networking standards - IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x
Network - Networking standards - IEEE 802.3
Network - Networking standards - IEEE 802.3ab
Network - Networking standards - IEEE 802.3af
Network - Networking standards - IEEE 802.3u
Network - Networking standards - IEEE 802.3x
Network architecture - GigabitEthernet
Number of 10/100 Mbps ports - None
Number of 10/100/1000 Mbps ports - 8
Number of COMBO ports - None
Number of PoE ports (PoE & PoE+) - 4
Number of SFP ports - None
Operational conditions - Operating relative humidity (H-H) - 5 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage temperature (T-T) - -20 - 70 °C
Other features - Supports IEEE 802.3af
ƒƒSupplies power to PD: up to 15.4 Watts
ƒƒTotal PoE budget: 52 Watts
ƒƒPoE port count/Average PoE watts per port: 4 (Port 1 - 4) / 13
Other features - Warranty period - 2 year(s)
Other features > Power supply type - External
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 100.00 mm
Package features > Gross depth master carton - 380 mm
Package features > Gross height (mm) - 180.00 mm
Package features > Gross height master carton - 370 mm
Package features > Gross width (mm) - 330.00 mm
Package features > Gross width master carton - 350 mm
Package features > Net weight master carton - 9.216 kg
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 291 pc(s)
Package features > Paper/Pasteboard - 150.00 g
Package features > Plastic (No PET) - 10.00 g
Package features > Tare weight (kg) - 0.16 kg
Package features > Tare weight master carton - 0.492 kg
Package features > Volume (m3) - 0.01 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
Packaging content - Quick start guide - Yes
PDF - https://www.blobs.lt/products/1/4/2/5/8/3/a94cc7fc263a905c1921d76c26b4a74c/original.pdf
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 8
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Ports & interfaces - Power connector - DC-in jack
Ports & interfaces > Ethernet LAN (RJ-45) ports - 8
Ports & interfaces > POE - PoE 802.3 af and PoE+ 802.3 at
Ports & interfaces > Predominant port type - 10/100/1000 Mbps (RJ-45)
Power - DC input voltage - 9 - 54 V
Power - Input current - 1,2 A
Power - Power consumption (max) - 66.458 W
Power - Power source - DC
Power - Power supply included - Yes
Power consumption - 63.2 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) power per port - 30 W
Power over Ethernet (PoE) - Power over Ethernet plus (PoE+) ports quantity - 4
Power over Ethernet (PoE) - Total Power over Ethernet (PoE) budget - 60 W
Power over Ethernet (PoE) > Total Power over Ethernet (PoE) budget - 60 W
Producent: Nazwa producenta / importera - D-linkD-Link (Polska) Sp. z o.o.ul. Mysikrólika 11a02-809 WarszawaPolskaEmail: pl-info@dlink.com
producer - D-Link
Producer - D-link
ProducerCode - DGS-1008P
producerCode - DGS-1008P/E
Producer product family - 8-Port Gigabit PoE Switch (4xPoE)
Producer product name - DGS-1008P
ProductName - 8-Port Gigabit PoE Unmanaged Desktop Switch
productName - D-Link 8-Port Gigabit PoE Unmanaged Desktop Switch
productSize - Normal
Safety warning - Warnings - Do not open the case or try to repair it yourself.
Safety warning - Warnings - Ensure the unit is adequately ventilated during operation.
Safety warning - Warnings - The product is not suitable for disposal in the regular waste bin. Take your used electronic equipment to a recycling centre in accordance with local regulations.
ShortDescription -
Short description - D-Link Switch DGS-1008P 8xGBit (4xPoE - 68W) Unmanaged
ShortSummaryDescription - D-Link 8-Port Gigabit PoE Unmanaged Desktop Switch, Unmanaged, L2, Gigabit Ethernet (10/100/1000), Full duplex, Power over Ethernet (PoE), Desktop
sizeX - 330
sizeY - 180
sizeZ - 115
Stck_Kart - 10
Stck_Pal - 20
Storno - Y
Supported protocols and standards - IEEE 802.3 10BASE-T Ethernet
ƒƒIEEE 802.3u 100BASE-TX Fast Ethernet
ƒƒIEEE 802.3ab 1000BASE-T Gigabit Ethernet
ƒƒANSI/IEEE 802.3 NWay Auto-negotiation
ƒƒIEEE 802.3x Flow Control
ƒƒIEEE 802.1p QoS
Support for Jumbo frames - Yes
Switch class - Unmanaged
Switch layer - L2
Technical details > Gross weight - 1.57 kg
Technical details > Net weight - 1.41 kg
Technical details > Producer - D-Link
Technical_details - The DGS-1008P PoE Gigabit Desktop switch provides a cost-effective way for office users to easily connect and supply power to Power over Ethernet (PoE) devices such as wireless access points (APs), IP cameras, and IP phones. It also provides the opportunity to add additional Ethernet devices like
computers, printers, and Network Attached Storage (NAS) onto a network. This compact PoE switch is equipped with Gigabit ports for faster speeds and operates quietly, making it ideal for use in virtually any room or office. In addition, D-Link’s Green Ethernet technology saves power when the switch is active and inactive. Plug and Play Power over Ethernet (PoE)
The first four ports of the DGS-1008P support the IEEE 802.3af PoE standard. Each of these four ports can supply up to 15.4 Watts, making it a very convenient solution for applications that are far away from power outlets, or when it is necessary to minimise the clutter of extra power supplies. The
switch will automatically detect the power that a connected PoE device requires so no configuration is needed. A failsafe mechanism will cut off the power in case of an unexpected PoE overload, protecting both the switch and the connected device. Cable diagnostics function
Every time the DGS-1008P is powered up, it runs a micro diagnostics routine to check the integrity of the connected Ethernet cables. If a failure is detected, the switch will flag it by means of its front panel LEDs, making it easy for the user to troubleshoot wiring problems. QoS (Quality of Service)
Despite being an unmanaged, Plug and Play switch, the DGS-1008P is able to classify network traffic by assessing the existing 802.1p and DSCP fields in the Ethernet frames and IP packets respectively, and forward traffic from its ports depending on their priority. This allows for a smooth integration of video, voice and data traffic without delays or loss of quality. Transfer Rate LAN 10/100/1000 MBit/s LEDs Activity, 8x Lan, Speed, Power, PoE Max., PoE 1-4 Ports RJ-45 LAN 8 (4 PoE) Power Operating (incl. PoE) 52 watt(s) per PoE Port 15.4 watt(s) Remarks with der integratedn D-Link Green Technology werden der Stromverbrauch and damit auch die operatingskosten maßgeblich gesenkt - without Einbußen hinsichtlich Leistung and functionalität. Features Mechanismus zum Schutz vor Überspannung, cablediagnose zur Prüfung der Netzwerkcable auf Fehlfunction, support Quality-of-Service and Jumbo-Frames bis 9.720 Bytes, 4.000 MAC addresses, Switch-capacity: 16 GBit/s, RAM-Puffer: 192 KB Product dimensions 190 x 38 x 120 mm
Throughput - 16 Gb/s
Title - D-Link 8-Port Gigabit PoE Unmanaged Desktop Switch
URL - https://www.dlink.com/products/?pid=805
vendpn - DGS-1008P/E
Warranty - 24
Warranty - 24 month(s)
WarrantyInfo - 2-Year D-Link Warranty
warrantyLength - 24
warrantyType - G
Weight - 0.96
Weight - 1,66
weight - 1623
Weight & dimensions - Depth - 98 mm
Weight & dimensions - Height - 28 mm
Weight & dimensions - Weight - 383 g
Weight & dimensions - Width - 150 mm
