TP-LINK Omada SG3452XMPP

10/100/1000/2500 Mbps ports - None
10G support Network - Yes
Access Control List (ACL) Security - Yes
Accessories included -
AC input frequency Power - 50/60 Hz
AC input voltage Power - 100 - 240 V
Application - Medium and large companies
ARP inspection Management features - Yes
ARTIKEL1 - 48-PORT 1G L2+ MANAGED SWITCH
ARTIKEL2 - 4X10G SFP+ + 40XPOE+ + 8XPOE++
Authentication Security - Auto VLAN, Guest VLAN
Basic switching RJ-45 Ethernet ports quantity Ports & interfaces - 48
Basic switching RJ-45 Ethernet ports type Ports & interfaces - Gigabit Ethernet (10/100/1000)
BPDU filtering/protection Security - Yes
Brand - TP-Link
BrandPartCode - SG3452XMPP
Breite - 0
Broadcast storm control Network - Yes
Cables included Packaging content - AC
Category - Network Switches
Category 1 - Netzwerk
Category 2 - Switching Hubs
Category Code - SWI
Certificates - CE, FCC, RoHS
Certificates - Certification - CE, FCC, RoHS
Certification Certificates - CE, FCC, RoHS
Chassis type - Rack
Cloud-managed Management features - Yes
CnCode - 85176200
Configuring Location Settings (CLI) Management features - Yes
Console port - Yes
Console port Ports & interfaces - RJ-45/Micro-USB
Data transmission - Forwarding rate - 130.9 Mpps
Data transmission - Jumbo frames - 9000
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 16000 entries
Data transmission - Packet buffer memory - 12 MB
Data transmission - Store-and-forward - Yes
Data transmission - Switching capacity - 176 Gbit/s
Depth Weight & dimensions - 330 mm
Description - 4× 10 Gbps SFP+ slots8× Gigabit 802.af/at/bt PoE++ ports (Max 90 W PoE budget for each port)40× Gigabit 802.3af/at PoE+ ports (Max 30 W budget for each port)750 W total PoE budget*Centralized cloud management via the web or the Omada app†Standalone management via web, CLI, SNMP, and RMON
Description - 4× gniazda SFP+ 10 Gbps 8× gigabitowe porty PoE++ 802.af/at/bt (maksymalny budżet PoE 90 W na każdy port) 40× gigabitowe porty PoE+ 802.3af/at (maksymalny budżet 30 W na każdy port) 750 W całkowity budżet PoE Scentralizowane zarządzanie w chmurze przez stronę internetową lub aplikację Omada Samodzielne zarządzanie przez stronę internetową, CLI, SNMP i RMON VLAN, ACL, QoS, IGMP Snooping, OAM i DDM Wytrzymała metalowa obudowa i konstrukcja montowana w szafie rackowej
Design - Form factor - 1U
Design - LED indicators - Yes
Design - Number of fans - 3 fan(s)
Design - Product colour - Black
Design - Rack mounting - Yes
Design - Reset button - Yes
Designation - CE+WEEE
DHCP features Security - DHCP client, DHCP relay, DHCP server
dimension depth - 100 mm
dimension height - 525 mm
Dimensions - 440 × 330 × 44 mm
dimension weight - 6900 g
dimension width - 470 mm
ean - 8885020620870
EAN - 8885020620870
EANCode - 8885020620870
Environment requirements - Temperatura pracy: 0°C do 40°C Temperatura przechowywania: -40°C do 70°C Wilgotność pracy: 10% do 90% RH, bez kondensacji Wilgotność przechowywania: 5% do 90% RH, bez kondensacji
Fan - Yes
Flow control support Network - Yes
Form factor Design - 1U
Forwarding mode - Store-and-forward
Forwarding rate - 130.94 Mpps
Forwarding rate Data transmission - 130.9 Mpps
Gewicht - 7
Gross Weight Kg - 6,2
GRUPPE1 - Network
GRUPPE2 - Switches Managed
GTIN - 0810142820417
GTIN - 810142820417
GTIN - 8885020620870
GTIN - 8885020620887
guarantee - 60
guarantee_type - normal
Head-of-line (HOL) blocking Network - Yes
Heat dissipation Operational conditions - 2169.2 BTU/h
Height Weight & dimensions - 44 mm
HERSTELLER - TP-LINK
Hoehe - 0
HSTNUMMER - SG3452XMPP
IGMP snooping Security - Yes
IP-MAC-Port binding Security - Yes
Jumbo frames Data transmission - 9000
Jumbo frame size - 9 KB
Jumbo frames support Data transmission - Yes
L2 features -
L3 features -
Laenge - 0
LED indicators Design - Yes
Link aggregation Network - Yes
LongDesc -
LongProductName - 40x 10/100/1000 Mbps RJ45 PoE+, 4x 10G SFP+ Slots, 1x RJ45, 1x Micro-USB, 176 Gbps, MAC 16 K, 440 × 330 × 44 mm
LongSummaryDescription - TP-Link Omada SG3452XMPP. Switch type: Managed, Switch layer: L2+. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 48, Console port: RJ-45/Micro-USB. MAC address table: 16000 entries, Switching capacity: 176 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3af, IEEE.... Power connector: AC-in jack. Power over Ethernet (PoE). Rack mounting, Form factor: 1U
MAC address filtering Security - Yes
MAC address table Data transmission - 16000 entries
MAC address table size - 16000
Management, monitoring, configuration -
Management features - ARP inspection - Yes
Management features - Cloud-managed - Yes
Management features - Configuring Location Settings (CLI) - Yes
Management features - Quality of Service (QoS) support - Yes
Management features - Switch layer - L2+
Management features - Switch type - Managed
Management features - System event log - Yes
Management features - Web-based management - Yes
Manufacturer - TP-Link
Manufacturer Code - SG3452XMPP
Manufacturer Name - TP-LINK
Model name - SG3452XMPP
MPN - SG3452XMPP
Multicast features - Multicast support - Yes
Multicast support Multicast features - Yes
name - Switch SG3452XMPP 48xGE PoE+ 4xSFP+
Name - TP-Link Omada Switch 48x GE SG3452XMPP
Network - 10G support - Yes
Network - Broadcast storm control - Yes
Network - Flow control support - Yes
Network - Head-of-line (HOL) blocking - Yes
Network - Link aggregation - Yes
Network - Networking standards - IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3z
Network - Port mirroring - Yes
Network - Rate limiting - Yes
Network - Spanning tree protocol - Yes
Network - VLAN support - Yes
Network architecture - GigabitEthernet
Networking standards Network - IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3z
Number of 10/100 Mbps ports - None
Number of 10/100/1000 Mbps ports - 48
Number of 10Gb ports - None
Number of COMBO ports - None
Number of fans Design - 3 fan(s)
Number of PoE+ ports - None
Number of PoE ports (PoE & PoE+) - None
Number of QSFP+ ports - None
Number of SFP+ ports - 4
Number of SFP56 ports - None
Number of SFP ports - None
Operating relative humidity (H-H) Operational conditions - 10 - 90%
Operating temperature (T-T) Operational conditions - 0 - 40 °C
Operational conditions - Heat dissipation - 2169.2 BTU/h
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features - Wsparcie SDN Obsługa kontrolera sprzętowego Omada Automatyczne wykrywanie urządzeń Zbiorcza aktualizacja oprogramowania sprzętowego Inteligentne monitorowanie sieci Ostrzeżenia o nietypowych zdarzeniach Ujednolicona konfiguracja Harmonogram ponownego uruchomienia
Other functions -
Packaging content - Cables included - AC
Packaging content - Quick start guide - Yes
Packet buffer memory Data transmission - 12 MB
Port mirroring Network - Yes
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 48
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Ports & interfaces - Console port - RJ-45/Micro-USB
Ports & interfaces - Power connector - AC-in jack
Ports & interfaces - SFP+ module slots quantity - 4
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - Power consumption (max) - 635.7 W
Power - Power source - AC
Power - Power supply included - Yes
Power connector Ports & interfaces - AC-in jack
Power consumption - 913.4 W
Power consumption (max) Power - 635.7 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) power per port - 30 W
Power over Ethernet (PoE) - Power over Ethernet 4PPoE (PoE++) ports quantity - 8
Power over Ethernet (PoE) - Power over Ethernet plus (PoE+) ports quantity - 40
Power over Ethernet (PoE) - Total Power over Ethernet (PoE) budget - 750 W
Power over Ethernet (PoE) Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) power per port Power over Ethernet (PoE) - 30 W
Power over Ethernet 4PPoE (PoE++) ports quantity Power over Ethernet (PoE) - 8
Power over Ethernet plus (PoE+) ports quantity Power over Ethernet (PoE) - 40
Power source Power - AC
Power supply - 100-240 V AC~50/60 Hz
Power supply - External
Power supply included Power - Yes
producer - TP-LINK
Product colour Design - Black
ProductName - SG3452XMPP
QoS -
Quality of Service (QoS) support Management features - Yes
Quick start guide Packaging content - Yes
Rack mounting Design - Yes
Rate limiting Network - Yes
Reset button Design - Yes
Security -
Security - Access Control List (ACL) - Yes
Security - Authentication - Auto VLAN, Guest VLAN
Security - BPDU filtering/protection - Yes
Security - DHCP features - DHCP client, DHCP relay, DHCP server
Security - IGMP snooping - Yes
Security - IP-MAC-Port binding - Yes
Security - MAC address filtering - Yes
Security - SSH/SSL support - Yes
Security - Static port security - Yes
SFP+ module slots quantity Ports & interfaces - 4
Short description - TP-LINK Switch SG3452XMPP 48xGBit/4x 10 GE SFP+ 8x PoE++ (750W) Managed Omada, L2+, Rack Mountable
ShortSummaryDescription - TP-Link Omada SG3452XMPP, Managed, L2+, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting, 1U
Spanning tree protocol Network - Yes
SSH/SSL support Security - Yes
Stackability - No
Static port security Security - Yes
Stck_Kart - 1
Stck_Pal - 3
Storage relative humidity (H-H) Operational conditions - 5 - 90%
Storage temperature (T-T) Operational conditions - -40 - 70 °C
Store-and-forward Data transmission - Yes
Storno - Y
Summary - TP-Link Omada SG3452XMPP. Switch type: Managed, Switch layer: L2+. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 48, Console port: RJ-45/Micro-USB. MAC address table: 16000 entries, Switching capacity: 176 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3af, IEEE.... Power connector: AC-in jack. Power over Ethernet (PoE). Rack mounting, Form factor: 1U
Supported protocols and standards -
Support for Jumbo frames - Yes
Switch class - Managed
Switching capacity Data transmission - 176 Gbit/s
Switch layer - L2+
Switch layer Management features - L2+
Switch type Management features - Managed
System event log Management features - Yes
Throughput - 176 Gb/s
Title - TP-Link Omada SG3452XMPP network switch Managed L2+ Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Black
Total Power over Ethernet (PoE) budget Power over Ethernet (PoE) - 750 W
Unit Box Height - 0.48
Unit Box Length - 0.53
Unit Box Width - 0.1
Unit Calculated Volume - 0.02544 cubm
Unit Calculated Weight - 7 kg
Units per Shipping Box - 1
URL - https://www.tp-link.com/my/business-networking/omada-switch-l3-l2-managed/sg3452xmpp/#specifications
Vendor Homepage - https://www.tp-link.com/my/business-networking/omada-switch-l3-l2-managed/sg3452xmpp/#specifications
vendpn - SG3452XMPP
VLAN -
VLAN support Network - Yes
Warranty - 60 months
WarrantyInfo -
Web-based management Management features - Yes
Weight & dimensions - Depth - 330 mm
Weight & dimensions - Height - 44 mm
Weight & dimensions - Width - 440 mm
Width Weight & dimensions - 440 mm
