Startech TB3/USB-C DOCK - DUAL DP/HDMI 96W PD - 5X USB HUB

ARTIKEL1 - TB3/USB-C DOCK - DUAL DP/HDMI
ARTIKEL2 - 96W PD - 5X USB HUB
Brand - StarTech.com
BrandPartCode - TB3CDK2DHUE
Category - Laptop Docks & Port Replicators
EANCode - 0065030880992
GRUPPE1 - Accessories
GRUPPE2 - Port
GTIN - 0065030880992
GTIN - 065030880992
HERSTELLER - STARTECH
HSTNUMMER - TB3CDK2DHUE
Logistics data - Harmonized System (HS) code - 84733020
Logistics data - Master (outer) case height - 320 mm
Logistics data - Master (outer) case length - 500 mm
Logistics data - Master (outer) case width - 248 mm
Logistics data - Products per master (outer) case - 40 pc(s)
LongDesc - Dual DP 4K 60Hz or Dual HDMI 2.0 Monitors | macOS & Windows®| 5x USB 3.0 Ports | 96W PD | 0.8 m CableA high-performance Thunderbolt™ 3 Certified docking station with USB Type-C compatibility featuring dual monitor 4K 60Hz DSC support from either Dual DisplayPort or dual HDMI 2.0 video outputs, 96W Power Delivery (100W peak power), 5x USB 3.2 Hub with 2x BC 1.2 fast charging ports, gigabit Ethernet (PXE Boot/Wake-on-LAN) & headset ports.Flexible Dual Display OutputsThis universal docking station features both dual DisplayPort 1.4 (Single 8K30 on HBR3 host) and dual HDMI video outputs that can be configured in three different ways:DisplayPort + DisplayPortHDMI + HDMIDisplayPort + HDMIResolutions and video outputs are host-dependent.Thunderbolt 3 or 4 LaptopSingle MonitorDual MonitorsIntel Laptops with 11th Gen or Later8K 30Hz / 5K 60Hz / 4K 60Hz4K 60HzIntel Laptops with 10th Gen or Earlier5K 60Hz / 4K 60Hz4K 60HzApple M1 & M2 Pro/Max MacBooks5K 60Hz / 4K 60Hz4K 60HzApple M1 & M2 MacBooks5K 60Hz / 4K 60HzMirrored Display OnlyIntel Based Macbook's with Thunderbolt 35K 60Hz / 4K 60Hz4K 60HzUSB-C Laptop (No Thunderbolt)Single MonitorDual MonitorsLaptops with Intel 10th Gen or Later(Requires DP 1.4 Alt Mode)4K 60Hz4K 30HzLaptops with DP 1.2 Alt Mode4K 30Hz1080p 60HzMore Downstream USB PortsFeaturing an integrated USB 3.2 hub, this docking station has 5 downstream USB ports:Front Facing:• 1x USB 3.2 Gen 2 Type-C (10 Gbps) with 15W (3A, 5V) Charging• 1x USB 3.2 Gen 2 Type-A (10 Gbps) with B.C. 1.2 Fast-ChargingBack Facing:• 2x USB 3.2 Gen 1 Type-A (5 Gbps)• 1x USB 3.2 Gen 2 Type-C (10 Gbps)Easy to Set Up & ManageThis universal Thunderbolt 3 / USB-C Dock has an automatic driver setup and includes a longer 0.8 meter (2.6 ft) Thunderbolt 3 host cable, front-facing TB3/USB-C host port, front-facing LED indicator, mounting holes for the optional bracket, k-slot for security lock & MAC address changer utility.Enhance Productivity and Device Management with the StarTech.com Connectivity Tools ApplicationDeveloped to improve performance and security, StarTech.com Connectivity Tools is the only software suite on the market that works with a wide range of IT connectivity accessories. The software suite includes:•Advanced Windows Layout Utility : To setup and save custom windows layouts.•Mac Address Pass-Through Utility : To improve network security.•USB Event Monitoring Utility : To track and log connected USB devices•Wi-Fi Auto Switch Utility : Enabling users to quickly access faster network speeds via wired LAN.For more information and to download the StarTech.com Connectivity Tools application, please visit: www.StarTech.com/Connectivity-ToolsTB3CDK2DHUE is backed by a StarTech.com three-year warranty and free lifetime technical support.The StarTech.com Advantage
LongProductName - StarTech.com Thunderbolt 3 Dock w/ USB-C Host Compatibility - Dual 4K 60Hz DisplayPort 1.4 or Dual HDMI Monitors - Single 8K - TB3/USB-C Laptop Docking Station - 96W PD, 5xUSB - 10Gbps (TB3CDK2DHUE)
LongSummaryDescription - StarTech.com USB C Docking Station for Macbook Pro/Air-M1/M2/M3/M4, Thunderbolt Compatible, HDMI/DisplayPort, Dual 4K 60Hz/Single 8K, USB Type-C Laptop Dock, 96W Power Delivery, USB 10Gbps. Connectivity technology: Wired, Host interface: Thunderbolt 3, USB Power Delivery up to: 96 W. Product colour: Black, Grey, Data transfer rate: 40 Gbit/s, Maximum digital resolution: 7680 x 4320 pixels. AC input voltage: 100 - 240 V, Input current: 2.5 A, Output voltage: 20 V. Windows operating systems supported: Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10..., Mac operating systems supported: Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur,..., Linux operating systems supported: Ubuntu 18.04 LTS, Ubuntu 20.04 LTS. Width: 220 mm, Depth: 80 mm, Height: 30 mm
Network - Ethernet LAN - Yes
Network - Ethernet LAN (RJ-45) ports - 1
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 35 °C
Operational conditions - Storage temperature (T-T) - -20 - 70 °C
Other features - Chipset - C-Media - CM6533, Genesys Logic - GL3590, Genesys Logic - GL3523, Realtek - RTD2184, Titan Ridge - JHL7440, Cypress - CCG5C
Packaging content - AC adapter included - Yes
Packaging content - Cables included - AC, Thunderbolt
Packaging content - Manual - Yes
Packaging data - Package depth - 160 mm
Packaging data - Package height - 110 mm
Packaging data - Package weight - 1.1 kg
Packaging data - Package width - 305 mm
Performance - Cable lock slot - Yes
Performance - Cable lock slot type - Kensington
Performance - Card reader integrated - No
Performance - Data transfer rate - 40 Gbit/s
Performance - Maximum digital resolution - 7680 x 4320 pixels
Performance - Number of displays supported - 2
Performance - Product colour - Black, Grey
Ports & interfaces - Combo headphone/mic port - Yes
Ports & interfaces - Connectivity technology - Wired
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - DisplayPorts quantity - 2
Ports & interfaces - HDMI ports quantity - 2
Ports & interfaces - Headphone connectivity - 3.5 mm
Ports & interfaces - Headphone outputs - 1
Ports & interfaces - Host interface - Thunderbolt 3
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 2
Ports & interfaces - USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity - 1
Ports & interfaces - USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity - 2
Ports & interfaces - USB Power Delivery (USB PD) - Yes
Ports & interfaces - USB Power Delivery up to - 96 W
Power - AC input voltage - 100 - 240 V
Power - Compatible power plug types - EU, UK
Power - Input current - 2.5 A
Power - Output current - 8.5 A
Power - Output voltage - 20 V
ProductName - USB C Docking Station for Macbook Pro/Air-M1/M2/M3/M4, Thunderbolt Compatible, HDMI/DisplayPort, Dual 4K 60Hz/Single 8K, USB Type-C Laptop Dock, 96W Power Delivery, USB 10Gbps
ShortSummaryDescription - StarTech.com USB C Docking Station for Macbook Pro/Air-M1/M2/M3/M4, Thunderbolt Compatible, HDMI/DisplayPort, Dual 4K 60Hz/Single 8K, USB Type-C Laptop Dock, 96W Power Delivery, USB 10Gbps, Wired, Thunderbolt 3, 96 W, 3.5 mm, Black, Grey, 40 Gbit/s
Software - Linux operating systems supported - Ubuntu 18.04 LTS, Ubuntu 20.04 LTS
Software - Mac operating systems supported - Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Software - Windows operating systems supported - Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Stck_Kart - 6
Stck_Pal - 18
Storno - Y
Title - StarTech.com USB C Docking Station for Macbook Pro/Air-M1/M2/M3/M4, Thunderbolt Compatible, HDMI/DisplayPort, Dual 4K 60Hz/Single 8K, USB Type-C Laptop Dock, 96W Power Delivery, USB 10Gbps
URL - https://www.startech.com/en-us/TB3CDK2DHUE
WarrantyInfo - 3 Years
Weight & dimensions - Depth - 80 mm
Weight & dimensions - Height - 30 mm
Weight & dimensions - Weight - 250 g
Weight & dimensions - Width - 220 mm
