Lenovo THINKSYSTEM 2.5IN MULTI VENDOR READ INTENSIVE SATA 6GB HS SSD

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
ID: 1162559 Product code: 4XB7A90874
Goods are not available at the moment We do not accept orders for the delivery of this product. We do not have information as to when this product will be available. Our suppliers currently do not provide information about possible delivery times of the product and the possible price when it is on sale again.

TopPC.fi website provides information about this product for information only, so that customers can see the product and compare it to the products available for sale now.

Warranty: 2 years (Warranty for business entities 1 year)
Main product parameters All parameters
  • Capacity: 960 GB
  • Type: SATA
  • Form factor: 2.5"
  • Interface: SATA III (6Gb/s)
Similar Products
This product Lenovo THINKSYSTEM 2.5IN MULTI VENDOR READ INTENSIVE SATA 6GB HS SSD
Intenso High, 960GB
Micron 5400 PRO, 960GB, M.2 SATA
Lexar NQ100, 1920 GB, SATA III, 2.5"
Lenovo 1TB, Gen4 x4
Show similar specs. Hide similar specs.
1,109.33 €
142.02 €
724.42 €
247.89 €
498.58 €
Basic information
Capacity 960 GB 960 GB 960 GB 1.92TB 1 TB
Type SATA SATA SATA SATA NVME
Read speed (sequential) 520 MB/s 540 MB/s 550 MB/s 5065 MB/s
Write speed (sequential) 480 MB/s 520 MB/s 445 MB/s 4600 MB/s
Functionality
Radiators None None None None
Lighting None None None None
Ports and equipment
Form factor 2.5" 2.5" M.2 80mm (2280) 2.5" M.2 42mm (2242)
Interface SATA III (6Gb/s) SATA III (6Gb/s) SATA III (6Gb/s) SATA III (6Gb/s) PCIe 4.0 x4
Interface SATA SATA SATA SATA M.2
Specification
Memory type TLC (Triple-Level Cell) TLC (Triple-Level Cell) TLC (Triple-Level Cell) Not specified
Random Read IOPS 133K 95K Not specified 690K
Random Write IOPS 122K 33K Not specified 600K
Endurance (TBW) 480 TB 2628 TB 672 TB Not specified
Basic information
Capacity 960 GB
The HDD capacity in Gigabytes indicates how much information can be stored by the HDD. The capacity of the HDD is fixed and cannot be increased after buying the HDD. Therefore, upon buying the HDD you should verify its compliance with your current volume requirements and provides a reserve for future needs.
Type : SATA
Ports and equipment
Form factor 2.5"

Thanks to the small size provided by the SSD technology the standard size of the discs is 2.5", and it is suitable for an average portable computer. It is possible to install the 2.5" disc in the desktop computer if the transition 2.5" -> 3.5" is used, and this transition can be bought at a low cost at TopPC.fi section"Adapteri". The discs with the format 2.5" + 3.5" have this transition included.

1.8" discs are intended for the ultra-compact class portable computers.

PCI-Express SSDs are intended for desktop computers with a free PCI-Express plug available. This technology in most cases is used for ensuring the performance that exceeds the possibilities of other types of connections.

Interface : SATA III (6Gb/s)
Interface SATA

SSDs with SATAII and SATAIII connection are compatible with the connections of both types in the motherboard. Still, it has to be taken into account that the motherboard SATAII connection can provide maximum about 300 MB/s transmission capacity which can reduce the actual transmission capacity of the SSDs whose reading and/or writing speed exceeds this level to the capacity limits of the SATAII.

The situation is similar with the PCI-Express and SATAIII connection slots. Although the SATAIII standard can provide up to 600 MB/s data transmission capacity there are SSDs with the speed exceeding this limit, in this case the manufacturer chooses the PCI-Express connection slot with a higher transmission capacity. The PCI-Express discs cannot be connected to the portable computer.

More detailed specification
Additional information in manufacturers website Lenovo THINKSYSTEM 2.5IN MULTI VENDOR READ INTENSIVE SATA 6GB HS SSD
Additional part number -
ARTIKEL1 - THINKSYSTEM 2.5IN MULTI VENDOR
ARTIKEL2 - READ INTENSIVE SATA 6GB HS SSD
Brand - Lenovo
BrandPartCode - 4XB7A90874
Category - Internal Solid State Drives
Compatible with -
Data Act - Link
Description - ThinkSystem 2.5" Multi Vendor 960GB Read Intensive SATA 6Gb HS SSD v2 drive
Designation - CE+WEEE
dimension depth - 60 mm
dimension height - 130 mm
dimension weight - 200 g
dimension width - 170 mm
Disk type - SSD
Drive type - Internal
ean - 889488712496
EANCode - 0889488712496
Features - Certification - UL
TUV
FCC
CE Mark
C-Tick Mark
BSMI (Taiwan)
KCC (Korea EMI)
Features - Component for - Server
Features - Drive writes per day (DWPD) - 1
Features - ECC - Yes
Features - H/W PLP function - Yes
Features - Interface - Serial ATA III
Features - Mean time between failures (MTBF) - 2000000 h
Features - Memory type - V-NAND TLC
Features - NVMe - No
Features - Random read (4KB) - 81000 IOPS
Features - Random write (4KB) - 28000 IOPS
Features - S.M.A.R.T. support - Yes
Features - SSD capacity - 960 GB
Features - SSD form factor - 2.5"
Features - Uncorrectable Bit Error Rate (UBER) - < 1 per 10^17 bits read
Form factor (width) - 2,5'' (SFF)
GRUPPE1 - Hard Drive/Optical
GRUPPE2 - Solid State Drive
GTIN - 0889488712496
GTIN - 889488712496
guarantee - 12
guarantee_type - external
HDD capacity - 960 GB
HDD interface - SATA III - 6 Gb/s
HERSTELLER - LENOVO
HSTNUMMER - 4XB7A90874
LongDesc - The ThinkSystem Vendor Agnostic Read Intensive SATA SSDs are general-purpose SSDs with an average endurance of 1 drive write per day. Vendor Agnostic SSDs are non-vendor-specific drives which can streamline and simplify the ordering and delivery of SATA SSDs. The drives offered in the Vendor Agnostic SSD program consists of SSDs that are readily available, ensuring the shortest supply lead time.
LongProductName - ThinkSystem 2.5" VA 960GB Read Intensive SATA 6Gb HS SSD v2
LongSummaryDescription - Lenovo 4XB7A90874. SSD capacity: 960 GB, SSD form factor: 2.5", Component for: Server
Model - 4XB7A90874
name - SSD 2,5 960G MV SATA 4XB7A90874
Operational conditions - Maximum operating altitude - 3050 m
Operational conditions - Non-operating shock - 1500 G
Operational conditions - Non-operating vibration - 20 G
Operational conditions - Operating relative humidity (H-H) - 5 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 70 °C
Operational conditions - Storage temperature (T-T) - -40 - 85 °C
Other features -
producer - Lenovo
ProductName - 4XB7A90874
ShortSummaryDescription - Lenovo 4XB7A90874, 960 GB, 2.5"
Stck_Kart - 10
Stck_Pal - 0
Storno - Y
Title - Lenovo 4XB7A90874 internal solid state drive 960 GB 2.5" Serial ATA III V-NAND TLC
URL - https://lenovopress.lenovo.com/lp2191-thinksystem-vendor-agnostic-read-intensive-6gb-sata-ssds
vendpn - 4XB7A90874
WarrantyInfo -
Weight & dimensions - Depth - 100 mm
Weight & dimensions - Height - 7 mm
Weight & dimensions - Width - 70 mm
