ID: 153066
Product code: 5SC750I
Can be ordered 4 units Availability: 14 days after order approval
Warranty: 2 years
Eaton 5SC750I, 750VA 525W, IEC
Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
-
Posti parcel machineWithin 1-2 working days6.99 € -
Post OfficeWithin 1-2 working days6.99 €
-
Delivery with Posti courier mailWithin 1-2 working days12.99 €
Main product parameters All parameters
- Battery capacity (VA): 750
- Output power (W): 525
Description
This UPS Eaton 5SC750I, 750VA 525W, IEC with an output capacity of 525 W and a battery capacity of 750 VA offers a balanced solution for daily use. The battery backup allows for temporary operation of multiple connected devices.
Display in the UPS device provides a visual representation of the operating parameters. It facilitates the diagnosis of the device's condition and allows the user to promptly assess readiness for operation in the event of power supply disruptions.
The use of a lead-acid battery in a UPS device ensures predictable operation during both short-term and prolonged power outages. This battery technology is characterized by stable output parameters, good compatibility with classic UPS schemes, and clear operating conditions in standard working environments.
The presence of a IEC320 connection type in a UPS device ensures standardized device connection using removable power cables. Such a connector facilitates the replacement and maintenance of connected devices, ensures a secure electrical contact and broad compatibility with server and office equipment.
Warranty
Eaton provides a 2 year warranty for this model at all certified service centres.
All parameters
Model
: 5SC750I
Display characteristics
Display
: Is
Basic information
Battery capacity (VA)
750
The capacity of the battery pack is the index of the long-term operation of the UPS device without a permanent power supply source. This parameter applies to a UPS device with a fully charged battery pack. If you want to verify how big capacity is required for your computer equipment visit www.apc.ru where you will find the UPS capacity determination configuration tool.
Battery type
: Lead acid
Charging time (hours)
: 6
Output power (W)
: 525
Ports and equipment
Number of nests (total)
: 6
Number of sockets (Battery Backup)
: 6
RJ-45
: 0
Socket type
: IEC320
USB
: 0
More detailed specification
AC outlets quantity Ports & interfaces - 6 AC outlet(s)
AC outlet types Ports & interfaces - C13 coupler
Active power - 525 W
Additional information -
Apparent power - 750 VA
ARTIKEL1 - EATON 5SC 750I
ARTIKEL2 - 750/525
Audible alarm(s) Features - Yes
Category Code - UPW
Certificates - IEC/EN 62040-1, UL 1778
Certification Certificates - CE/GS/C-Tick
Chassis type - Tower
Color - Black
Communication - Serial Port (RS-232)
Communication - USB
Depth Weight & dimensions - 340 mm
Description - Eaton 5SC UPS Eaton 5SC UPS provides line-interactive, affordable and reliable protection for small business servers. Complementing our range of industry leading UPSs, the 5SC includes an LCD interface for real-time status and measurements, and provides sinewave output for compatibility with todays most sensitive IT equipment
Description - Eaton 5SC UPS provides line-interactive, affordable and reliable protection for small business servers. Complementing our range of industry leading UPSs, the 5SC includes an LCD interface for real-time status and measurements, and provides sinewave output for compatibility with today’s most sensitive IT equipment.
Designation - CE+WEEE
dimension depth - 300 mm
dimension height - 470 mm
Dimensions - 150 x 340 x 210 mm
dimension weight - 12000 g
dimension width - 240 mm
Display type Design - LCD
ean - 743172045157
EANCode - 0743172045157
Efficiency Features - 97%
Form factor Design - Tower
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
guarantee - 24
guarantee_type - normal
Harmonized System (HS) code Logistics data - 85078000
Height Weight & dimensions - 210 mm
HERSTELLER - EATON
HSTNUMMER - 5SC750I
Input frequency Features - 50/60 Hz
Input operation voltage (max) Features - 276 V
Input operation voltage (min) Features - 184 V
LED indicators Design - Yes
name - 5SC750i 5SC 750i
Noise level Features - 40 dB
Nominal input voltage Other features - 230 V
Nominal output voltage Other features - 230 V
Number of phases input - 1 (230V)
Operating altitude Operational conditions - 0 - 3000 m
Operating temperature (T-T) Operational conditions - 0 - 35 °C
Output operation voltage (max) Features - 240 V
Output operation voltage (min) Features - 220 V
Output power capacity Features - 0.75 kVA
Output power Features - 525 W
Power plug Ports & interfaces - C14 coupler
Power protection features Features - Overload
producer - Eaton
Product colour Design - Black
RS-232 ports Ports & interfaces - 1
Safety Safety regulation & standards - IEC 62040-1, CB Report (TUV)
Stck_Kart - 1
Stck_Pal - 5
Storage temperature (T-T) Operational conditions - -15 - 40 °C
Storno - Y
Summary - Eaton 5SC750i. Output power capacity: 0.75 kVA, Output power: 525 W, Waveform: Sine. AC outlet types: C13 coupler, Power plug: C14 coupler, AC outlets quantity: 6 AC outlet(s). Typical backup time at full load: 5 min, Typical backup time at half load: 12 min. Form factor: Tower, Product colour: Black, Display type: LCD. Certification: CE/GS/C-Tick
Typical backup time at full load Battery - 5 min
Typical backup time at half load Battery - 12 min
Unit Box Height - 0.303
Unit Box Length - 0.47
Unit Box Width - 0.237
Unit Calculated Volume - 0.03375 cubm
Unit Calculated Weight - 11.6 kg
Units per Shipping Box - 1
UPS Architecture - line-interactive
USB 2.0 ports quantity Ports & interfaces - 1
Vendor Homepage - https://powerquality.eaton.com/5SC750i.aspx?CX=26
vendpn - 5SC750i
Video -
Warranty - 24 months
Waveform Features - Sine
Weight - 10.4 kg
Weight Weight & dimensions - 10.4 kg
Width Weight & dimensions - 150 mm
