ARTIKEL1 - 2M LC TO LC OS2 FIBER CABLE
ARTIKEL2 - OS2/UPC/DUPLEX/LSZH
Brand - StarTech.com
BrandPartCode - SMDOS2LCLC2M
Category - InfiniBand & Fibre Optic Cables
Certificates - Compliance certificates - CE
EANCode - 0065030902083
Features - Cable length - 2 m
Features - Cable type - LC/UPC
Features - Cladding diameter - 125 µm
Features - Connector 1 - LC
Features - Connector 1 gender - Male
Features - Connector 2 - LC
Features - Connector 2 gender - Male
Features - Connector polish type - UPC
Features - Core diameter - 9 µm
Features - Data transfer rate - 10 Gbit/s
Features - Fiber mode structure - Single-mode
Features - Fibre optic type - OS2
Features - Full duplex - Yes
Features - Insertion loss - 0.3 dB
Features - Jacket material - Low smoke zero halogen (LSZH), Polypropylene
Features - Product colour - Yellow
Features - Return loss - 55 dB
Features - Wavelengths supported - 1260,1280,1300,1310,1383,1490,1550,1590,1600,1625 nm
GRUPPE1 - Cables
GRUPPE2 - Network Ethernet Cab
GTIN - 0065030902083
GTIN - 065030902083
HERSTELLER - STARTECH
HSTNUMMER - SMDOS2LCLC2M
Logistics data - Master (outer) case height - 280 mm
Logistics data - Master (outer) case length - 380 mm
Logistics data - Master (outer) case width - 380 mm
Logistics data - Products per master (outer) case - 300 pc(s)
LongDesc - Enhance the performance capabilities of CWDM applications over an OS2 fiber networkOS2 LC to LC Single Mode Duplex Fiber Optic Patch cable facilitates connectivity across 100G networks. It supports Coarse Wavelength Division Multiplexing (CWDM) across an extended wavelength range of 1260-1625nm, improving channel isolation for optimal signal strength over long distances.CompatibilityThis 9/125µm Single Mode fiber cable supports 1260-1625nm laser-optimized sources and is ideal for critical connections between servers, switches, and data center equipment. It is backward compatible with OS1 networks, ensuring a reliable connection in legacy fiber environments.Engineered for Optimal PerformancePrecision-manufactured ceramic ferrules ensure accurate fiber alignment for an insertion loss below 0.3dB. Ultra Physical Contact (UPC)-polished LC to LC fiber ends greatly improve return loss characteristics over older PC polishing techniques. The Bend Insensitive fiber core is surrounded by a layer of low refractive index material. This material reduces the amount of light that can escape the fiber cable by reflecting the light back into the fiber. The OS2 fiber patch cord is engineered for low attenuation and performance that exceeds ITU-T G652.D/G657.A1 and IEC60703-2-50 type B1.3/B6.a1 industry standards.LSZH Cable JacketHoused in a Low-Smoke Zero-Halogen (LSZH) flame-retardant jacket, the OS2 fiber cable emits low smoke and toxic fumes when exposed to extreme heat or in the event of a fire. This enables safer cable installations in areas with poor ventilation including some industrial settings, self-contained environments such as trains and aircraft, as well as residential settings where compliance with building codes must be considered.Each OS2 fiber cable is individually tested for insertion loss performance and includes a test report, for guaranteed compatibility and 100% reliability.The StarTech.com Advantage
LongProductName - StarTech.com 2m (6.6ft) LC to LC (UPC) OS2 Single Mode Duplex Fiber Optic Cable, 9/125, 100G, LSZH Fiber Jumper Cord
LongSummaryDescription - StarTech.com 2m (6.6ft) LC to LC (UPC) OS2 Single Mode Duplex Fiber Optic Cable, 9/125µm, 100G, Bend Insensitive, Low Insertion Loss - LSZH Fiber Jumper Cord. Cable length: 2 m, Cable type: LC/UPC, Fibre optic type: OS2, Connector 1: LC, Connector 2: LC, Core diameter: 9 µm, Full duplex
Operational conditions - Operating temperature (T-T) - -20 - 60 °C
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Other features - Attenuation (max) - 0.35 dB/km
Packaging content - Quantity per pack - 1 pc(s)
Packaging data - Package depth - 220 mm
Packaging data - Package height - 3 mm
Packaging data - Package weight - 20.4 g
Packaging data - Package width - 200 mm
ProductName - 2m (6.6ft) LC to LC (UPC) OS2 Single Mode Duplex Fiber Optic Cable, 9/125µm, 100G, Bend Insensitive, Low Insertion Loss - LSZH Fiber Jumper Cord
ShortSummaryDescription - StarTech.com 2m (6.6ft) LC to LC (UPC) OS2 Single Mode Duplex Fiber Optic Cable, 9/125µm, 100G, Bend Insensitive, Low Insertion Loss - LSZH Fiber Jumper Cord, 2 m, LC/UPC, OS2, LC, LC
Stck_Kart - 9998
Stck_Pal - 0
Storno - Y
Sustainability - Sustainability compliance - Yes
Title - StarTech.com 2m (6.6ft) LC to LC (UPC) OS2 Single Mode Duplex Fiber Optic Cable, 9/125µm, 100G, Bend Insensitive, Low Insertion Loss - LSZH Fiber Jumper Cord
URL - https://www.startech.com/en-us/
WarrantyInfo -
Weight & dimensions - Bending radius - 1 cm
Weight & dimensions - Cable diameter - 2 mm
